Gambody STL files of Han Solo in Carbonite for 3D Printing

This 3D Miniature consists of files in StereoLithography (.Stl) format that have been optimized for 3D printing.

Before printing the files, we strongly recommend reading the PRINTING DETAILS section.

Version 1 and Version 2 are the files for Han Solo in Carbonite 3D Miniature optimized for 3D printing, the preview pictures of which you see above.

It is recommended:

to print Version 1 STL files on FDM/FFF 3D printers;
to print Version 2 STL files on DLP/SLA/SLS 3D printers.

version: FFF/FDM 1.0 version: DLP/SLA/SLS 1.0
File Name	File Size	Time / Filament	Object Size (x/y/z mm)
1_Han Solo in Carbonite_c ut_1. stl	9.49 MiB	25 h 28 min 15 m	109 x 36 x 134
3_Ge_lock_10S (x6).STL	0.02 MiB	4 min	10 x 18 x 2
2_Han Solo in Carbonite_c ut_2 (repaired). stl	34.53 MiB	27 h 58 min 16 m	108 x 38 x 122
4_Han Solo in Carbonite ( repaired).stl	63.07 MiB	56 h 44 min 33 m	108 x 38 x 254

HISTORY OF HAN SOLO

Han Solo was a famous Corellian to the whole galaxy as a participant in the Rebellion. Khan's parents were Jonas and Jaina Solo, who disappeared when he was no more than two years old. His father was a prince and descendant of King Beretron e Solo, who established a democratic regime in the Corellian Empire. Khan had a difficult childhood, but he managed to break with the past and enter the service in the Empire. The cross on his career Solo set, when he stood up for the slave-Wookie Chewbacca. Together they fled and eventually became partners. Khan purchased the ship "Millennium Falcon" and became a smuggler.

ABOUT THIS 3D MINIATURE

The model is saved in STL files, a format supported by most 3D printers.

FDM version features:
- Contain 4 parts;
- Made divided and as one piece;
- Divided version made with Locks for better fixing. One part of Lock (3_Ge_lock_10S (x6)) you need to print 6 times.
- All parts made in such way that you will print them with the smallest amount of supports.

SLS/SLA version features:
- Same as FDM but made only as 1 part.

All STL files for 3D printing have been checked in Netfabb and no errors were shown.

Note: Before starting 3D printing the model, read the Printing Details for CURA 3.2.1. Software.

There are 4 parts for FFF/FDM version and 1 part for SLS/SLA version.

Scale: The scale of the model was calculated on the basis of the growth of Han Solo is 180 cm. So the size of diorama is 2000 mm. Model made as 1/8 scale.

FDM version dimensions:
After being printed will stand - 254 mm tall, 109 mm wide, 38 mm deep;

SLS/SLA version dimensions:
After being printed will stand - 127 mm tall, 54.5 mm wide, 19 mm deep;
- Has only 1 detail, to keep printing costs down.

WHAT WILL YOU GET AFTER PURCHASE?

- STL files of Han Solo in Carbonite 3D Miniature for 3D printing which consist of 5 parts;
- 2 versions of files for this model for FFF/FDM and SLS/SLA;
- Model fixed by the Locks;
- High-poly detailed miniature of Han Solo in Carbonite;
- Detailed settings that we provide for Cura 3.2.1. for the best print;
- Full technical support from the Gambody Support Team.

Watch the tutorial video on how to assemble Han Solo in Carbonite 3D Printing Miniature at Gambody YouTube channel.

You can get Model of Han Solo in Carbonite for 3D Printing right now! Just click the green Buy button in the top-right corner of the model’s page. You can pay with PayPal or your credit card.

Also, you may like other Space War 3D Printing Miniatures.

_______
FAQ:
Where can I print a model if I have no printer?
How to get started with 3D printing?
How to set up my 3D printer?
How to choose right 3D model print bed positioning?
How to paint printed figurine?

This model was tested in Cura 3.2.1 and printed on an Ultimaker 2 in PLA material.

Recommendations: For all parts of Locks you need to change "Brim" type to "Skirt" in Build Plate Adhesion section.

To avoid printing problems, we recommend the following settings:

Quality
Layer Height: 0.1 mm
Initial Layer Height: 0.3 mm
Line Width: 0.4 mm
Wall Line Width: 0.4 mm
Outer Wall Line Width: 0.4 mm
Inner Wall(s) Line Width: 0.4 mm
Top/Bottom Line Width: 0.4 mm
Infill Line Width: 0.4 mm
Skirt/Brim Line Width: 0. 4 mm
Initial Layer Line Width: 100%

Shell
Wall Thickness: 0.8 mm
Wall Line Count: 2
Outer Wall Wipe Distance: 0.2 mm
Top Surface Skin Layers: 0
Top/Bottom Thickness: 0.8 mm
Top Thickness: 0.8 mm
Top Layers: 8
Bottom Thickness: 0.8 mm
Bottom Layers: 8
Top/Bottom Pattern: Lines
Bottom Pattern Initial Layer: Lines
Top/Bottom Line Directions: [ ]
Outer Wall Inset: 0 mm
Compensate Wall Overlaps: Check
Compensate Outer Wall Overlaps: Check
Compensate Inner Wall Overlaps: Check
Fill Gaps Between Walls: Everywhere
Filter Out Tiny Gaps: Check
Horizontal Expansion: 0 mm
Initial Layer Horizontal Expansion: 0 mm
Z Seam Alignment: Sharpest Corner
Seam Corner Preference: Hide Seam
Ignore Small Z Gaps: Check
Extra Skin Wall Count: 1

Infill
Infill Density: 20%
Infill Line Distance: 4.0 mm
Infill Pattern: Grid
Infill Line Directions: [ ]
Infill X Offset: 0 mm
Infill Y Offset: 0 mm
Infill Overlap Percentage: 10%
Infill Overlap: 0. 04 mm
Skin Overlap Percentage: 5%
Skin Overlap: 0.02 mm
Infill Wipe Distance: 0.1 mm
Infill Layer Thickness: 0.1 mm
Gradual Infill Steps: 0
Infill Before Walls: Check
Minimum Infill Area: 0 mm2
Skin Removal Width: 0.8 mm
Top Skin Removal Width: 0.8 mm
Bottom Skin Removal Width: 0.8 mm
Skin Expand Distance: 0.8
Top Skin Expand Distance: 0.8
Bottom Skin Expand Distance: 0.8
Maximum Skin Angle for Expansion: 90˚
Minimum Skin Width for Expansion: 0.0

Material
Enable Retraction: Check
Retraction Extra Prime Amount: 0 mm3
Retraction Minimum Travel: 0.8 mm
Maximum Retraction Count: 90
Minimum Extrusion Distance Window: 6.5 mm
Nozzle Switch Retraction Distance: 16 mm
Nozzle Switch Retraction Speed: 20 mm/s
Nozzle Switch Retract Speed: 20 mm/s
Nozzle Switch Prime Speed: 20 mm/s

Speed
Print Speed: 45 mm/s
Infill Speed: 50 mm/s
Wall Speed: 22. 5 mm/s
Outer Wall Speed: 22.5 mm/s
Inner Wall Speed: 45 mm/s
Top/Bottom Speed: 15 mm/s
Travel Speed: 120 mm/s
Initial Layer Speed: 30 mm/s
Initial Layer Print Speed: 30 mm/s
Initial Layer Travel Speed: 60 mm/s
Skirt/Brim Speed: 30 mm/s
Maximum Z Speed: 0 mm/s
Number of Slower Layers: 2

Travel
Combing Mode: All
Avoid Printed Parts when Traveling: Check
Travel Avoid Distance: 0.625 mm
Layer Start X: 0.0 mm
Layer Start Y: 0.0 mm

Cooling
Enable Print Cooling: Check
Fan Speed: 100%
Regular Fan Speed: 100%
Maximum Fan Speed: 100%
Regular/Maximum Fan Speed Threshold: 10 s
Initial Fan Speed: 0%
Regular Fan Speed at Height: 0.3 mm
Regular Fan Speed at Layer: 2
Minimum Layer Time: 5 s
Minimum Speed: 10 mm/s

Support
Generate Support: Check
Support Placement: Everywhere
Support Overhang Angle: 60°
Support Pattern: Zig Zag
Connect Support ZigZags: Check
Support Density: 15 %
Support Line Distance: 1. 3333 mm
Support Z Distance: 0.3 mm
Support Top Distance: 0.3 mm
Support Bottom Distance: 0.3 mm
Support X/Y Distance: 0.7 mm
Support Distance Priority: Z overrides X/Y
Minimum Support X/Y Distance: 0.2 mm
Support Stair Step Height: 0.3 mm
Support Stair Step Maximum Width: 5.0 mm
Support Join Distance: 2.0 mm
Support Horizontal Expansion: 0.2 mm
Support Infill Layer Thickness: 0.1 mm
Use Towers: Check
Tower Diameter: 3.0 mm
Minimum Diameter: 3.0 mm
Tower Roof Angle: 65°

Build Plate Adhesion
Build Plate Adhesion Type: Brim (for all parts of locks use "Skirt")
Skirt/Brim Minimum Length: 250 mm
Brim Width: 8.0 mm
Brim Line Count: 18
Brim Only on Outside: Check

Mesh Fixes
Union Overlapping Volumes: Check
Merged Meshes Overlap: 0.15 mm

Special Modes
Print Sequence: All at Once
Surface Mode: Normal

Experimental
Slicing Tolerance: Middle
Maximum Resolution: 0. 01 mm
Flow rate compensation max extrusion offset: 0 mm
Flow rate compensation factor: 100%

Disclaimer: This model will look outstanding if printed on SLA/SLS 3D printer. The accuracy of the model printed on FFF printer can vary from the result shown in the pictures.

Gambody STL files of Han Solo for 3D Printing

This 3D Figurine consists of files in StereoLithography (.Stl) format that have been optimized for 3D printing.

Before printing the files, we strongly recommend reading the PRINTING DETAILS section.

Han Solo 3D Printing Figurine comes in 3 versions for each 3D printer type (FDM/FFF, DLP/SLA and SLS). Files for each version are available for download after the purchase.

Detailed information about this model is available in the DESCRIPTION section.

version: FFF/FDM 1. 0 version: DLP/SLA 1.0 version: SLS 1.0
File Name	File Size	Time / Filament	Object Size (x/y/z mm)
1_Body (repaired).stl	31.63 MiB	n.a. n.a.	51 x 48 x 112
2_Hand_R (repaired). stl	7.09 MiB	54 min	12 x 22 x 50
3_Arm_R (repaired).stl	2.69 MiB	1 h 31 min 1 m	17 x 36 x 62
4_Ge_lock_7SX10. stl	0.02 MiB	3 min	7 x 18 x 2
5_Hand_L (repaired).stl	0.66 MiB	27 min	14 x 9 x 29
7_Pelvis (repaired). stl	14.20 MiB	8 h 42 min 5 m	65 x 36 x 88
8_Foot_R (repaired).stl	3.54 MiB	1 h 30 min 1 m	18 x 37 x 64
9_Foot_L (repaired). stl	3.63 MiB	1 h 35 min 1 m	21 x 36 x 64
10_Platform(repaired).stl	11.46 MiB	n.a. n.a.	206 x 170 x 92
11_Platform_side (repaire d). stl	6.61 MiB	3 h 47 min 3 m	17 x 157 x 15
12_Ge_lock_10SX2.stl	0.02 MiB	4 min	10 x 18 x 2
6_Arm_L (repaired). stl	4.61 MiB	1 h 20 min 1 m	17 x 29 x 68

HISTORY OF HAN SOLO

Han Solo is a famous Corellian, throughout the Galaxy as a participant in the Uprising against the Galactic Empire. Khan's parents were Jonas and Jaina Solo, who disappeared when he was two years old. His father was a prince and descendant of King Beretron Solo, who established a democratic regime in the Corellian Empire. Khan had a difficult childhood, but he managed to break with the past and enter the service in the Empire. The cross on his career Solo set, when he stood up for the slave-wookie Chewbacca. Together they fled and eventually became partners. Khan purchased the ship "Millennium Falcon" and became a smuggler.

ABOUT THIS 3D FIGURINE

The model is saved in STL files, a format supported by most 3D printers.

FDM version features:
- Contain 12 parts;
- Made with Locks. One part of Lock (4_Ge_lock_7S_x10) you need to print 10 times. One part of Lock (12_Ge_lock_10S_x2) you need to print twise;
- Made with a special platform in the form of the part of Millenium Falcon interior;
- All parts are divided in such way that you will print them with the smallest amount of supports.

DLP/SLA version features:
- Same as FDM but smaller, also made as 10 parts;

SLS version features:
- Same as SLA but made as 3 parts for economy your material;

All STL files for 3D printing have been checked in Netfabb and no errors were shown.

Note: Before starting 3D printing the model, read the Printing Details for CURA 3.3.1. or Simplify3D Software.

There are 12 parts for FFF/FDM version, 10 parts for SLA version and 3 parts for SLS.

Scale: Han Solo height is 1800 mm. The scale of this model made in proportion to it. 1/8 for FDM version and 1/16 for SLS/SLA version.

FDM version dimensions:
After being printed will stand - 250 mm tall, 255 mm wide, 227 mm deep;

SLA/DLP/SLS version dimensions:
After being printed will stand - 125 mm tall, 128 mm wide, 114 mm deep;
- Has a few details, to keep printing costs down.

WHAT WILL YOU GET AFTER PURCHASE?

- STL files of Han Solo 3D Figurine for 3D printing which consist of 25 parts;
- 3 versions of files for this model for FFF/FDM, DLP/SLA, and SLS;
- High-poly detailed figurine of Han Solo;
- Detailed settings that we provide for Cura 3. 3.1. and Simplify3D for the best print;
- Full technical support from the Gambody Support Team.

You can get Model of Han Solo for 3D Printing right now! Just click the green Buy button in the top-right corner of the model’s page. You can pay with PayPal or your credit card.

Watch the tutorial video on how to assemble Han Solo 3D Printing Figurine at Gambody YouTube channel.

Also, you may like other Star Wars 3D Printing Figurines.

This model was tested in Cura 3.3.1 and printed on an Ultimaker 2 in PLA material. Below you can find printing recommendations for Cura and Simplify3D softwares.

Cura printing recommendations:

Recommendations: For all parts of Locks you need to change "Brim" type to "Skirt" in Build Plate Adhesion section.

To avoid printing problems, we recommend the following settings:

Shell
Wall Thickness: 0.8 mm
    Wall Line Count: 2
Outer Wall Wipe Distance: 0.2 mm
Top Surface Skin Layers: 0
Top/Bottom Thickness: 0.8 mm
   Top Thickness: 0.8 mm
      Top Layers: 8
    Bottom Thickness: 0.8 mm
      Bottom Layers: 8
Top/Bottom Pattern: Lines
Bottom Pattern Initial Layer: Lines
Top/Bottom Line Directions: [ ]
Outer Wall Inset: 0 mm
Compensate Wall Overlaps: Check
    Compensate Outer Wall Overlaps: Check
    Compensate Inner Wall Overlaps: Check
Fill Gaps Between Walls: Everywhere
Filter Out Tiny Gaps: Check
Horizontal Expansion: 0 mm
Initial Layer Horizontal Expansion: 0 mm
Z Seam Alignment: Sharpest Corner
Seam Corner Preference: Hide Seam
Ignore Small Z Gaps: Check
Extra Skin Wall Count: 1

Infill
Infill Density: 20%
Infill Line Distance: 4. 0 mm
Infill Pattern: Grid
Infill Line Directions: [ ]
Infill X Offset: 0 mm
Infill Y Offset: 0 mm
Infill Overlap Percentage: 10%
    Infill Overlap: 0.04 mm
Skin Overlap Percentage: 5%
    Skin Overlap: 0.02 mm
Infill Wipe Distance: 0.1 mm
Infill Layer Thickness: 0.1 mm
Gradual Infill Steps: 1
Gradual Infill Steps Height: 1.5 mm
Infill Before Walls: Check
Minimum Infill Area: 0 mm2
Skin Removal Width: 0.8 mm
    Top Skin Removal Width: 0.8 mm
    Bottom Skin Removal Width: 0.8 mm
Skin Expand Distance: 0.8
    Top Skin Expand Distance: 0.8
    Bottom Skin Expand Distance: 0.8
Maximum Skin Angle for Expansion: 90˚
    Minimum Skin Width for Expansion: 0.0

Material
Initial Layer Flow: 100%
Enable Retraction: Check
Retraction Extra Prime Amount: 0 mm3
Retraction Minimum Travel: 0.8 mm
Maximum Retraction Count: 90
Minimum Extrusion Distance Window: 6.5 mm
Nozzle Switch Retraction Distance: 16 mm
Nozzle Switch Retraction Speed: 20 mm/s
Nozzle Switch Retract Speed: 20 mm/s
Nozzle Switch Prime Speed: 20 mm/s

Speed
Print Speed: 45 mm/s
    Infill Speed: 50 mm/s
    Wall Speed: 22. 5 mm/s
      Outer Wall Speed: 22.5 mm/s
      Inner Wall Speed: 45 mm/s
    Top/Bottom Speed: 15 mm/s
Travel Speed: 60 mm/s
Initial Layer Speed: 22.5 mm/s
  Initial Layer Print Speed: 22.5 mm/s
  Initial Layer Travel Speed: 30 mm/s
Skirt/Brim Speed: 30 mm/s
Maximum Z Speed: 0 mm/s
Number of Slower Layers: 2

Travel
Combing Mode: All
Avoid Printed Parts when Traveling: Check
Travel Avoid Distance: 0.625 mm
Layer Start X: 0.0 mm
Layer Start Y: 0.0 mm

Cooling
Enable Print Cooling: Check
Fan Speed: 100%
    Regular Fan Speed: 100%
    Maximum Fan Speed: 100%
Regular/Maximum Fan Speed Threshold: 10 s
Initial Fan Speed: 0%
Regular Fan Speed at Height: 0.3 mm
    Regular Fan Speed at Layer: 2
Minimum Layer Time: 5 s
Minimum Speed: 10 mm/s

Support
Generate Support: Check
Support Placement: Everywhere
Support Overhang Angle: 60°
Support Pattern: Zig Zag
Connect Support ZigZags: Check
Support Density: 15 %
    Support Line Distance: 1. 3333 mm
Support Z Distance: 0.3 mm
    Support Top Distance: 0.3 mm
    Support Bottom Distance: 0.3 mm
Support X/Y Distance: 1 mm
Support Distance Priority: Z overrides X/Y
Minimum Support X/Y Distance: 0.25 mm
Support Stair Step Height: 0.3 mm
Support Stair Step Maximum Width: 5.0 mm
Support Join Distance: 2.0 mm
Support Horizontal Expansion: 0.2 mm
Support Infill Layer Thickness: 0.1 mm
Gradual Support Infill Steps: 0
Use Towers: Check
Tower Diameter: 3.0 mm
Minimum Diameter: 3.0 mm
Tower Roof Angle: 65°

Build Plate Adhesion
Build Plate Adhesion Type: Brim (for all parts of locks use "Skirt")
Skirt/Brim Minimum Length: 250 mm
Brim Width: 8.0 mm
Brim Line Count: 18
Brim Only on Outside: Check

Mesh Fixes
Union Overlapping Volumes: Check
Merged Meshes Overlap: 0.15 mm

Special Modes
Print Sequence: All at Once
Surface Mode: Normal

Experimental
Slicing Tolerance: Middle
Maximum Resolution: 0. 01 mm
Flow rate compensation max extrusion offset: 0 mm
Flow rate compensation factor: 100%

Disclaimer: This model will look outstanding if printed on SLA/SLS 3D printer. The accuracy of the model printed on FFF printer can vary from the result shown in the pictures.

Simplify3D printing recommendations:

This model was tested with PLA material.

To avoid printing problems, we recommend the following settings:

Extruder
Nozzle Diameter: 0.4 mm
Extrusion Multiplier: 0.97
Extrusion Width: Auto

Retraction Distance: 5.00 mm
Extra Restart Distance: 0.00 mm
Retraction Vertical Lift: 0.08 mm
Retraction Speed: 5400.0 mm/min

Wipe Distance: 5.00 mm

Layer
Primary Layer Height: 0.2 mm
Top Solid Layers: 8
Bottom Solid Layers: 5
Outline/Perimeter Shells: 2
Outline Direction: Inside-Out

First Layer Height: 90%
First Layer Width: 100%
First Layer Speed: 20%

Additions
Use Skirt/Brim: Check
Skirt Layers: 1
Skirt Offset from Part: 6. 00 mm
Skirt Outlines: 5

Infill
Internal Fill Pattern: Fast Honeycomb
External Fill Patern: Rectilinear
Interior Fill Percentage: 10%
Outline Overlap: 22%
Infill Extrusion Width: 100%
Minimum Infill Length: 5.00 mm
Combine Infill Every: 1 layers

External Infill Angle Offsets: 45/-45 deg

Support
Generate Support Material: Check
Support Infill Percentage: 15%
Extra Inflation Distance: 1.00 mm
Support Base Layers: 0
Combine Support Every: 1 layers

Dense Support Layers: 0
Dense Infill Percentage: 70%

Support Type: Normal
Support Pillar Resolution: 5.00 mm
Max Overhang Angle: 60 deg

Horizontal Offset From Part: 0.50 mm
Upper Vertical Separation Layers: 1
Lower Vertical Separation Layers: 1

Support Infill Angles: 45 deg

Temperature
Extruder 1 Temperature: 210
Heated Bed: 60

Cooling
Increase fan speed for layers below: 45. 0 sec
Maximum Cooling fan speed: 50%
Bridging fan speed override: 100%

Speeds
Default Printing Speed: 4800.0 mm/min
Outline Underspeed: 50%
Solid Infill Underspeed: 80%
Support Structure Underspeed: 80%
X/Y Axis Movement Speed: 10800.0 mm/min
Z Axis Movemen Speed: 1002.0 mm/min

Adjust printing speed for layers below: 15.0 sec
Allow speed reduction down to: 20%

Other
Unsupported area threshold: 20.0 sq m

OBJ file Han Solo DL-44 with stand

E11 - Stormtrooper with stand - optimized for resin 3D printing

~~€12.83~~ -thirty% €8.98

F11D - Attack aircraft with buttstock and stand - optimized for resin 3D printing

~~€18.33~~ -fifty% 9. 16 €

Best 3D printer files in Game category

Tick-Tock Towers

2.33 €

SMARS LOADER DLC

2 €

MK classic scorpion statue

5 €

WW1 Ship (Fleet) Pieces for Diplomacy the Board Game

Free

Head of Emperor Titan with crew

Free

Speddy 65mm. Frame for 7mm. Motors

Free

Bestsellers in the Game category

Chopper motorcycle print-in-place

1 €

Articulated dragon

3. 79 €

Exolotreftes Truescal

5 €

Snake and rattlesnake

3.79 €

Cute flexi unicorn

1.05 €

USS EnterSurprise - printable game container for tiny F14 9 jet fighters0004

€3.79

Articulated snowman

2.84 €

Octopus 2.0

3.79 €

Healer conversion kit SM

6 €

Destroy damaged spaceship for assassination team or boarding action games

~~€14.15~~ -fifty% 7.08 €

Heavily Armored Cataphrac Warriors - Season 9 Weapon Set

3. 10 €

CRAMER Truggy RC 4x4 Full 3D Printed

7,50 €

WARFORGED VOIDWALKER EXOSUIT UPGRADE KIT

9,50 €

Enourmous Imperial heavy tank

10 €

Beaky Boyz Builder: PF_MK-Six

~~€11.88~~ -fifteen% 10.09 €

Off-road vehicle

2 €

Do you want to support Cults?

Do you like Cults and want to help us continue our journey on our own ? Please note that we are a small team of 3 people, so it is very easy to support us in maintaining activities and creating future developments of . Here are 4 solutions available to everyone:

AD: Disable the AdBlock banner blocker and click on our banner ads.
AFFILIATION: Shop online with our affiliate links here Amazon.
DONATIONS: If you want, you can donate via PayPal here.
* INVITE FRIENDS: * Invite your friends, discover the platform and great 3D files shared by the community!

15 epic 3D printable Star Wars models

Yoda, which one will you have on your desk? Laser sword hilt holder? Or a battery powered moving AT-AT? Get these epic Star Wars models with 3D printing.

Looking for a new model of Darth Vader or a roaming AT-AT? After all, a new episode of Star Wars is just around the corner - more precisely, in December - so it's time to prepare for it. What is the best way to do this? Stock up on 3D printed Star Wars items. Below is a list of amazing Star Wars 3D printable models.

1. Thermal detonator

This Star Wars thermal detonator can be 3D printed. The model has four holes for LEDs, allowing you to bring this support to the senses.

2. Darth Vader head

Of course, this head is a 3D printed product. It can be used as a great accessory for any desktop. This model looks best for printing in black.

3. Luke Skywalker's lightsaber

This Star Wars model comes in eight separate parts. “I see that you are constructing a new lightsaber. Your skills are perfect. Surely you are strong, just as the Emperor foresaw." - Darth Vader.

4. Polygonal Yoda

3D printed bust of Yoda. The polygonal design perfectly conveys the character's character. The 3D print should take about seven hours using PLA and 20% infill at 100 microns. Patience must have! This is Yoda.

5. Large R2-D2

A beautiful remake of the R2-D2 droid. But R2-D2 is white, isn't he? An exact copy can just as easily be printed using a variety of colors. Make sure to save the plans for the Death Star in the R2-D2 droid.

6. Star Wars Emblem

When 3D printing the emblem, it is recommended to use two colors, preferably black and yellow, as in the photo.

7. Motorized AT-AT

This is a 3D printed AT-AT that can walk. How cool is that? This part of the movement has 69 parts and is powered by a 9-volt battery and a 90 rpm motor.

8.BB-8

3D printed version of BB-8, the ride droid from Star Wars Episode VII. Model BB-8 is designed for use with Sphero. Sphero is a controlled robot ball app that can roll at speeds up to 7 feet per second.

9. Blaster Han Solo

This blaster is known as the DL-44 blaster pistol. Han Solo used one of these pistols in the Star Wars movies. We suggest printing this Star Wars model with 10% infill and 200 micron quality.

10.K-2SO

3D printable model of the K-2SO robot seen in Rogue One. This is a witty robot who sacrificed his existence for the success of the mission - to steal the plans of the Death Star. "Now close the vault door. Goodbye." ―K-2SO.

11. Case for iPhone 6 Star Wars

3D Printed Case for iPhone 6 Smartphone. We suggest printing this Star Wars model with a thin layer height, so that the thinnest part of the back of the case consists of more than one layer. Use the Force to prevent the phone from getting damaged by falling on the floor.

12. Star Wars snowflakes

These are really cool themed snowflakes. Anthony Herrera did a really good job. Check out his website.

13. Walking AT-TE

AT-TE Walkers were used by the Galactic Republic during the Clone Wars. This Star Wars model has a moving gun and legs.

14. Star Wars Dark Holocron

Hidden Sith markings become visible when the holocron is illuminated from the inside. This Star Wars model was printed at 200 microns.

Han solo 3d print

Gambody STL files of Han Solo in Carbonite for 3D Printing

Gambody STL files of Han Solo for 3D Printing

Cura printing recommendations:

Simplify3D printing recommendations:

OBJ file Han Solo DL-44 with stand

E11 - Stormtrooper with stand - optimized for resin 3D printing

F11D - Attack aircraft with buttstock and stand - optimized for resin 3D printing

Best 3D printer files in Game category

Tick-Tock Towers

SMARS LOADER DLC

MK classic scorpion statue

WW1 Ship (Fleet) Pieces for Diplomacy the Board Game

Head of Emperor Titan with crew

Speddy 65mm. Frame for 7mm. Motors

Bestsellers in the Game category

Chopper motorcycle print-in-place

Articulated dragon

Exolotreftes Truescal

Snake and rattlesnake

Cute flexi unicorn

USS EnterSurprise - printable game container for tiny F14 9 jet fighters0004

Articulated snowman

Octopus 2.0

Healer conversion kit SM

Destroy damaged spaceship for assassination team or boarding action games

Heavily Armored Cataphrac Warriors - Season 9 Weapon Set

CRAMER Truggy RC 4x4 Full 3D Printed

WARFORGED VOIDWALKER EXOSUIT UPGRADE KIT

Enourmous Imperial heavy tank

Beaky Boyz Builder: PF_MK-Six

Off-road vehicle

Do you want to support Cults?

15 epic 3D printable Star Wars models

1. Thermal detonator

2. Darth Vader head

3. Luke Skywalker's lightsaber

4. Polygonal Yoda

5. Large R2-D2

6. Star Wars Emblem

7. Motorized AT-AT

8.BB-8

9. Blaster Han Solo

10.K-2SO

11. Case for iPhone 6 Star Wars

12. Star Wars snowflakes

13. Walking AT-TE

14. Star Wars Dark Holocron

Learn more
