Best 3d scanner for jewelry
guide and top 6 scanners
What is jewelry 3D scanning?
3D scanning is the process of digitally analyzing an object to obtain 3D information about its shape. A popular use of 3D scanning technology is jewelry 3D scanning.
This is the process of 3D scanning jewelry, precious metals, and gemstones with the goal of creating a digital copy of the original object. The digital copy can be used for many purposes, such as repairing or duplicating a valuable item.
3D scanners have been adopted as a supplementary tool by traditional jewelers, but the technology has also allowed newcomers to enter the field, many of which have combined 3D scanning with jewelry 3D printing.
This guide looks at some of the best jewelry 3D scanners on the market, in addition to discussing the various applications and benefits of 3D scanning jewelry.
A 3D scanned ring by B9 Creations. Source: B9 CreationsThe best jewelry 3D scanners in 2023
| Brand | Product | Accuracy | Country | Price Approximate starting prices based on supplier-provided information and public data. | |
|---|---|---|---|---|---|
| Shining 3D This brand is a certified partner from our network. | AutoScan Sparkle | 0.01 mm0.000394 in | China | $ 14,00014 000 €11,605 £1,886,752 ¥ | Quote |
| B9Creations | B9 Scan 350 | 0.015 mm0.000591 in | United States | $ 15,00015 000 €12,434 £2,021,520 ¥ | Quote |
| Polyga | HDI Compact C506 | 0.012 mm0.000472 in | – | $ 16,99015 994 €14,083 £2,289,708 ¥ | Quote |
| Medit | Solutionix D700 | 0.01 mm0.000394 in | South Korea | $ 25,00023 535 €20,723 £3,369,200 ¥ | Quote |
| Artec 3D | Micro | 0.01 mm0.000394 in | Luxembourg | $ 29,30027 583 €24,287 £3,948,702 ¥ | Quote |
| Evatronix | eviXscan FinePrecision | 0. 006 mm0.000236 in | Poland | $ 35,00029 000 €29,012 £4,716,880 ¥ | Quote |
Expand to see more specs
The products in the table are ranked by price (low to high).
| Brand | Product | Accuracy | Max resolution | Country | Price Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, …). | |
|---|---|---|---|---|---|---|
| Shining 3D This brand is a certified partner from our network. | AutoScan Sparkle | 0.01 mm0.000394 in | 0.05 mm0.001969 in | China | $ 14,00014 000 €11,605 £1,886,752 ¥ | Get a quote |
| B9Creations | B9 Scan 350 | 0.015 mm0.000591 in | 0.052 mm0.002047 in | United States | $ 15,00015 000 €12,434 £2,021,520 ¥ | Get a quote |
| Polyga | HDI Compact C506 | 0. 012 mm0.000472 in | 0.02 mm0.000787 in | – | $ 16,99015 994 €14,083 £2,289,708 ¥ | Get a quote |
| Medit | Solutionix D700 | 0.01 mm0.000394 in | 0.01 mm0.000394 in | South Korea | $ 25,00023 535 €20,723 £3,369,200 ¥ | Get a quote |
| Artec 3D | Micro | 0.01 mm0.000394 in | 0.029 mm0.001142 in | Luxembourg | $ 29,30027 583 €24,287 £3,948,702 ¥ | Get a quote |
| Evatronix | eviXscan FinePrecision | 0.006 mm0.000236 in | 0.028 mm0.001102 in | Poland | $ 35,00029 000 €29,012 £4,716,880 ¥ | Get a quote |
How jewelry 3D scanning works
Most jewelry 3D scanners are enclosed or partly enclosed desktop machines that offer ideal lighting conditions. Desktop jewelry 3D scanners almost always feature an automatic turntable, or auto-rotating table, on which the piece of jewelry is placed to be scanned.
Basic turntables only rotate at 360°, while more advanced, multi-axis turntable systems are able to tilt from side to side with multiple degrees of freedom. Hence, minimal manual input is required, and jewelers can 3D scan their objects at the click of a button.
In terms of technology, the majority of jewelry 3D scanners use structured light 3D scanning methods.
Structured light 3D scanners feature a light-emitting device (often a blue LED light) that projects a series of patterns onto the surface of the piece of jewelry. These patterns visibly deform according to the object’s surface and contours.
Meanwhile, a camera captures these deformed patterns, which are then processed by the scanner’s software to determine the jewelry’s precise geometry. The result is a 3D CAD model that can be modified, re-used, sliced for 3D printing, etc.
To recap, most jewelry 3D scanners feature the following characteristics:
- Desktop format with an enclosed or partly enclosed scanning area
- Automated thanks to a rotating table with one or multiple axes of movement
- Structured light technology with blue LED patterns
- High precision for complex details
Typical 3D jewelry scanning workflow
Put simply, a piece of jewelry is 3D scanned thanks to blue structured light technology. Then, the 3D scanner’s software creates a 3D model, which can then be exported to specialist CAD software suites for jewelers.
A typical workflow goes like this:
A typical 3D jewelry scanning workflow combined with 3D printing and casting methods. Source: eLUXE3DHere’s a deeper look into the major steps linked to 3D scanning jewelry.
1. Prepare jewelry
Left untreated, jewelry is difficult to scan, because a 3D scanner’s optical hardware has trouble processing shiny or reflective surfaces. Structured light patterns become distorted if reflected by the metal object.
This problem can be mitigated by spraying the jewelry with a temporary or washable matte coating (3D scanning spray).
2. Position jewelry
Most jewelry 3D scanners use an automatic rotating table (a.k.a. automatic turntable, multi-axis turntable), allowing the scanner to view the piece of jewelry from as many angles as possible.
The most detailed side of the piece should face upwards, where there is no physical contact with the turntable. In most cases, the user will have to flip the piece over in order for the scanner to capture the previously hidden surfaces.
3. Begin 3D scanning
Jewelry 3D scanners are packaged with 3D scanning software on which the user can launch 3D scans, operate the automatic turntable, and adjust scanning parameters (e.g. resolution).
Many of them enable one-click 3D scans and, thanks to auto-rotating tables, there is very little need for manual intervention.
4. Manipulate 3D model with CAD software
When a jewelry 3D scanner has completed scanning, its software creates a 3D mesh file (in STL file format, for example) of the piece of jewelry.
3D jewelry models are then commonly exported to a CAD software platform where the jeweler can edit or rework the piece, share it online, or simply store it digitally for future reference.
5. 3D print model
3D models obtained via jewelry 3D scanning can be 3D printed with the help of Stereolithography (SLA) 3D printing. SLA 3D printers are compatible with castable resins, which act as an alternative to wax in the direct investment casting process.
A jeweler can 3D print jewelry in castable resin, before surrounding the printed model with an investment material to make a mold. The 3D printed model is burnt out, leaving a cavity in the mold shaped like the original piece of jewelry.
Finally, the jeweler can pour molten metal — gold, silver, or bronze, for example — into the mold to create a new piece of jewelry.
In some cases, it can be possible to skip the casting process and print the piece of jewelry directly with a metal 3D printer.
Overview of the best jewelry 3D scanners in 2023
Here we provide a deeper look into each jewelry 3D scanner from our list.
Artec 3D, a Luxembourg-headquartered company with offices in Moscow and California, has been developing handheld and portable 3D scanners since 2007.
Their Artec Micro is an easy-to-use, high-precision desktop 3D scanner built for jewelry scanning, though it also has uses in dentistry and machine part scanning. A fully automated machine with one-click functionality, the Artec Micro scans with a point accuracy of up to 0.01 millimeters.
Artec’s versatile desktop 3D scanner scans items of jewelry using structured light technology: twin color cameras (6.4 megapixels) and a blue LED projector are complemented by a circular platform with a dual-axis swing-and-rotate system.
Real-time digital capture and previsualization is achieved using Artec’s dedicated software package, Artec Studio.
Contact manufacturer Get a quote Add to comparison
South Korean 3D scanner manufacturer Medit has been in the business for two decades, providing solutions mainly destined for industrial and dental customers.
The Solutionix D700 is a fully automated desktop 3D scanner targeted at non-industrial users such as jewelry specialists who need to scan very small objects. The D700 is the most advanced 3D scanner in the Solutionix D-Series range of products, with a higher resolution than the D500.
The D700 scans items of jewelry with structured light technology that Solutionix calls “phase shifting optical triangulation.” This involves scanning from multiple angles to capture the entire profile of the object, then using those images to create a triangle mesh.
The D700’s two 6.4 megapixel cameras can capture details in full color.
Contact manufacturer Get a quote Add to comparison
B9Creations is a 3D printing and 3D scanning company based in South Dakota.
It has been creating 3D printers since 2011, and 3D scanners since 2018.
Designed specifically for the 3D scanning of jewelry and other small objects, the B9Creations B9 Scan 350 is an entry-level structured light scanner with 2-axis turntable rotation and an accuracy of 0.015 millimeters.
B9Creations states that the B9 Scan 350 can 3D scan any ring in less than five minutes. It achieves this using an LED projector with a brightness of 100 ANSI-lumens and a camera with a resolution of 1.3 megapixels.
Contact manufacturer Get a quote Add to comparison
The Polyga HDI Compact C506 is a professional plug-and-play 3D scanner made by Polyga, a manufacturer from Canada.
It is part of Polyga’s HDI Compact C series of three professional 3D scanners. Polyga HDI Compact 3D scanners use blue LED structured light 3D scanning technology to capture objects in less than a second. They are the next generation of HDI 100 3D scanners.
The HDI Compact C506 is ideal for 3D scanning very small parts in high resolution and accuracy. Indeed, it features two 5.2 monochrome MP cameras.
Contact manufacturer Get a quote Add to comparison
Shining 3D is part of the 3D scanning industry’s market leaders, producing 3D scanners (and 3D printers) since 2004. Their AutoScan series caters to a range of applications, with the AutoScan Inspec for metrology and the Sparkle version for jewelry.
This automated 3D scanner for jewelry features one of the largest scanning volumes of its category, and offers three degrees of freedom with its integrated turntable.
The AutoScan Sparkle comes with Shining 3D’s Ultrascan software for mesh exports but will require additional software for design purposes. Shining 3D namely lists Geomagic Design X, ZBrush, and Polyworks as suitable solutions.
Contact manufacturer Get a quote Add to comparison
The eviXscan FinePrecision is a desktop 3D scanner produced by Evatronix.
Evatronix is a 3D scanner manufacturer based in Poland.
The Evatronix eviXscan FinePrecision uses structured light technology.
Contact manufacturer Get a quote Add to comparison
Alternatives (other 3D jewelry scanners)
Here are a few other jewelry 3D scanning solutions from lesser-known manufacturers:
- Vylo Falcon3DX (South Korea)
- EGSolutions JScan 3 (Italy)
- eLUXE3D Gold 6.4 (United States)
3D jewelry software
After obtaining a 3D model from a 3D scan, jewelers may need to reverse engineer the mesh file into a new CAD format.
This is because mesh formats like STL interpret 3D models as an assortment of polygons, whereas actual pieces of jewelry tend to contain smooth, curved surfaces — not dozens of tiny triangles. CAD geometries like NURBS surfaces are better at representing these curves and are easier to edit.
The process of converting meshes into NURBS or subdivision surfaces is sometimes called retropology, and common tools for the practice include 3D Systems’ Geomagic X suite and the Mesh3Surface plugin for Rhino.
Once the scan has been converted, the jeweler can edit and rework the model.
Common CAD platforms used for jewelry design include 3Design, Rhino, and Matrix, while there are also a handful of jewelry-specific software suites such as Stuller’s MatrixGold and Gesswein’s JewelCAD, which provides features like automatic stone setting.
A brief look at file formats and 3D jewelry/design software suites. Source: D3D-SKey specifications for jewelry 3D scanners
There are several specifications to look into before purchasing a 3D scanning solution for metrology.
Knowing the important specifications of 3D scanning technology makes choosing the right jewelry 3D scanner much easier.
Terms you will frequently encounter include:
Scanning volume or field of view
The scanning volume of a 3D scanner is the size of the envelope in which it can detect the scanned object.
The larger the volume, also called the field of view, the larger the objects it can scan.
Most jewelry 3D scanners have small scanning volumes.
Scanning resolution
Measured in millimeters or microns, the resolution is the smallest possible distance between two points of a 3D scan. It is also called point-to-point distance or points per scan. A smaller number, therefore, represents a higher resolution and a greater level of detail in the finished 3D model.
There are two different kinds of resolutions: measurement resolution and mesh resolution. Mesh resolution is the most important kind to consider, as it will be the resolution of your final 3D model. Manufacturers are sometimes unclear about which resolution they are referring to.
Camera resolution
The scan resolution is directly affected by the resolution of the scanner’s camera since the camera is what captures the light deformation.
Camera resolution is measured in megapixels, and a higher number of megapixels means higher resolution.
3D scanners often have dual cameras.
Accuracy
Accuracy is the degree to which the dimensions of the digital scan match those of the physical object. It is measured in millimeters or microns, with a lower number translating into better accuracy.
Speed
In 3D scanning, speed is the amount of time it takes to 3D scan an object. It can be measured in seconds per scan or in measurements per second (number of 3D points captured in one second).
However, the chosen resolution, object size, and other parameters affect scanning speed.
Degrees of freedom/movement
A 3D scanner’s number of degrees of freedom is the number of directions in which its scanning bed can move by rotating and tilting from one side to another.
More degrees of freedom allow the scanner to automatically capture the object from a greater number of angles, resulting in a more accurate and more complete scan. This also allows professionals to save time, requiring less manual manipulation.
Jewelry 3D scanner price
Jewelry 3D scanner prices start at around $8,000 and can go up to over $30,000 for the most advanced systems. Resolution, accuracy, amount of movement axes,, and other factors all contribute to the scanner’s pricing.
It is also important to keep in mind that 3D scanning software always requires powerful laptops in terms of RAM, graphics card, etc. If you are not well equipped, you may need to allocate several thousand dollars of your budget to a new PC.
A metal ring made with a castable 3D printed model. Source: FormlabsApplications of jewelry 3D scanning
Jewelers use 3D scanners for many reasons. Some of the more common uses of jewelry 3D scanning include:
Heirloom reproduction
Using a 3D scanner, it is possible to create a 3D model of a valuable piece of jewelry, which can then be used to create a replica using 3D printing and casting techniques.
Customers may wish to create copies of a family heirloom to give to other family members, or so they can wear the duplicate while keeping the original safe.
Matching wedding bands
Many customers demand wedding bands that match the scale of their engagement ring. By 3D scanning the engagement ring, it is easy to create a matching wedding band using the digital model.
Stone setting
Jewelers often need to create new rings and settings for existing precious stones. By 3D scanning the gemstone, the jeweler can use the 3D model to create a setting that perfectly fits the stone.
Quality control
Even jewelers committed to traditional techniques may find 3D scanning useful as a tool for quality control. By scanning finished pieces, the jeweler can accurately measure overall dimensions and detailed features (a.k.a. metrology).
Reverse engineering and repairs
3D scanning jewelry allows jewelers to take an existing piece and build on the digital model in various ways. They may use the 3D model to create a new piece with modifications or to repair a damaged piece.
Archiving, concept showcasing, distribution
Once a jeweler has obtained a 3D scan of an item of jewelry, the digital file can be stored on a hard drive for safekeeping or uploaded to the internet.
Some modern jewelers sell their creations as digital files, allowing the customer to print the design themselves or through a 3D printing service.
Unique advantages of 3D jewelry scanning
3D scanning jewelry has benefits for both jewelers and customers when compared with traditional methods of jewelry creation, jewelry repair, and jewelry commerce.
- Speed: The speed that 3D scanning provides is vital for jewelers, who might otherwise spend many hours manually designing a piece to a similar level of detail.
- Accuracy: If a scanner is properly calibrated, it can reach a high level of accuracy. This is especially important with, for example, custom rings designed to fit the customer, or for perfect-fit gemstone settings.
- Permanent record: 3D scanning produces a permanent digital record of a piece of jewelry which can be revisited at any future point.
- Efficiency: Scanning is efficient because it only needs to take place once, even if thousands of duplicates will be made with the resulting digital file.
- 3D printing: 3D scanners can export files into a 3D printable format such as STL. Jewelers can use a 3D printed wax model to create a functional metal cast.
Current limitations of jewelry 3D scanning
Jewelry 3D scanning is still a new and developing process, and there are several areas where it could — and will — improve.
- Post processing: Even high-end 3D scanners produce partially incomplete models, and it is almost always necessary to fine-tune the resulting model (hole filling, smoothing, etc.)..
- Reflective surfaces: The shiny surfaces of metal objects reflect LED projections and lasers, confusing the data received by the scanner. Applying matte spray, which is the most common solution to this problem, is not always feasible with delicate or fragile pieces.
- Material recognition: A scanner cannot yet differentiate between metal and a precious stone. This means, for example, that a diamond ring is processed as one solid shape, not as one object (diamond) within another (ring).
- Formats: Exported file formats like OBJ and STL may present compatibility issues, since they are not easily editable like a CAD file.
- Conversion: Converting a mesh or point cloud into a 3D model is much more difficult than converting in the opposite direction.
FAQ
How do you scan jewelry?
For professional-quality jewelry 3D scanning, you need a dedicated jewelry 3D scanner or a scanner designed to scan small objects.
Which 3D scanners are best for jewelry scanning?
Most dedicated jewelry 3D scanners are structured light scanners, which use high-resolution cameras and LED projectors.
Will all jewelry be 3D printed in the future?
Combining 3D scanning with 3D printing allows jewelers to create new pieces using the traditional investment casting process. 3D printing is not yet used to print the actual piece of jewelry, although there are a few exceptions (plastic pendants, for example).
Can you 3D scan a wedding ring?
Jewelers frequently use 3D scanning to create wedding bands that match an engagement ring in size and style.
Wedding rings can also be saved as digital files or duplicated.
The Best Jewelry 3D Scanners [2022]
Jewelry 3D scanners have revolutionized how jewelers approach the task of repairing, reproducing, and designing rings, bracelets, fittings, mounts, and so much more, saving both time and money in the process.
Fast, efficient, and incredibly easy to use, they are arguably one of the most critical advancements in the industry in recent years.
You’ve come to the right place if you’re looking to level up your jewelry service with some bleeding-edge technological help. This guide will highlight a curated selection of the best jewelry 3D scanners currently available.
We’ve covered a range of price points to suit both solo jewelers and larger setups with cash to throw around, but all these are strong picks regardless of their price tag.
Why 3D Scan Jewelry
Jewelers can obtain highly-accurate, quick, and relatively cheap digital models of existing jewelry pieces and gemstones thanks to a 3D scanner.
This digitization of jewelry has many benefits and uses for jewelers, chiefly replication, adjustments, design, and repairs, or to fast track the creation of high-resolution resin, silicone, or wax molds for traditional molding and casting.
Uses of 3D Scanning Jewelry
Replication/Duplication: Using a jewelry 3D scanner to create a digital model of an antique, custom, or heirloom piece allows a jeweler to quickly and easily create a duplicate.
This can be done both as insurance for precious items or to create a copy for customers to wear while the original remains under lock and key for safekeeping.
Repairs: An editable and modifiable 3D model of a broken piece of jewelry allows jewelers to create modified, custom molds to cast a replacement.
With a 3D model, jewelers can also quickly take stock of what needs repairing without dismantling the piece.
Design: 3D scanning opens new opportunities in the jewelry design phase.
With the ability to scan objects from the world around them, jewelers can quickly and cheaply experiment and prototype new designs and ideas.
From personalized pieces for specific customers to radically new designs, jewelry 3D scanners blow the creative possibilities wide open.
Setting: By scanning stones, jewelers can create settings, rings, and designs perfectly sized and shaped to fit.
Similarly, 3D scanning existing engagement rings to capture fit and design details greatly simplifies the creation of matching wedding bands.
Quality Inspection: 3D scanning pieces or even molds to obtain exact measurements allows jewelers to pick up on discrepancies or faults and implement adjustments before committing to an entire production run, saving time and money.
Archiving: 3D scanning jewelry is a cost-effective way to create a digital archive for valuation, insurance, or the conservation of degraded old pieces prone to decay.
How Jewelry 3D Scanners Work
Jewelry 3D scanners employ structured light technology, much like traditional 3D scanners.
The scanner beams a light pattern, usually an LED, onto the object’s surface. A rotating turntable ensures the light hits the object from all angles.
A set of cameras record how the object distorts, deforms, and reflects the light, translating it into a 3D model matching the object’s dimensions and shape via software.
Aside from placing the object on the turntable and triggering the scan, the process is often completely automated.
Jewelers can then edit and modify that 3D model in design software such as a CAD suite for replication, repairs, 3D printing, wax/resin castable models, etc.
Best Jewelry 3D Scanners
Artec Micro
- Price: $29,000-$30,000
- Accuracy: 0.01 mm
- Resolution: 0.029 mm
- Max Scan Volume: 90 × 60 × 60 mm
- Technology: Structured light
The Artec Micro is a professional, fully-automated desktop-sized 3D scanner with usability and precision at its core.
The Artec delivers pristine models up to 0.01 mm accuracy and a sharp, detailed 0.029 mm resolution with one simple click.
The Artec Micro comes housed in a single all-in-one semi-enclosed shell, fitted with a height-adjustable dual-axis turntable that both pitches and rotates to capture an object’s intricacies.
There are two dual-color cameras, and a blue LED light source capable of scanning in full color.
The Artec Micro has an automatic mode that chooses the optimum scanning path and frame count to keep both scan times and 3D model file sizes to a minimum.
Artec Studio, the software suite that comes with the Micro, offers useful functions such as real-time in-progress scan preview and easy model exporting to all the most popular CAD software.
Though the Artec Micro is suited to various applications, it hits its stride with jewelry thanks to the ability to take an intricate piece such as a brooch, ring, or single gemstone and create a high-precision digital equivalent in minutes.
From there, jewelers can tinker and modify the 3D model for repairs, replication, refitting, and more.
Medit Solutionix D700
- Price: $24,000-$25,000
- Accuracy: 0.01 mm
- Resolution: 0.029 mm
- Max Scan Volume: 90 x 60 x 60 mm
- Technology: Structured light
Designed and manufactured by Medit, the Solutionix D700 is a professional-grade semi-enclosed 3D scanner particularly well suited to jewelry.
It specializes in the scanning of small objects with complex geometries.
The Medit Solutionix D700 excels at capturing the surface intricacies of a gemstone, fine details and all, at the high level of precision required by jewelry applications.
It does this thanks to a crisp 0.029 mm resolution allied to a 0.01 mm accuracy, powered by a duo of 6.4 MP cameras and a blue LED light source.
Like the Artec Micro, the Medit Solutionix D700 aims to deliver effortless scanning. Firing up a scan is as hands-off as it gets, requiring you to position the object on the turntable and click once to start scanning.
The scanner automates the rest of the process, scanning objects from multiple angles to create a complete triangle mesh with vivid color texture, exportable to CAD software.
Other notable features include automatic calibration, a scanning path generation tool, and active synchronization.
B9 Scan 350
- Price: $13,000-$15,000
- Accuracy: 0.015 mm
- Max Scan Volume: 90 x 80 x 55 mm
- Technology: Structured light
With the B9 Scan 350, B9 Creations are solely focused on providing a 3D scanner suited from the ground up for jewelry.
It’s a desktop-sized option that ships in a compact, fully-enclosed body designed to provide the perfect environment to capture every facet and angle of a piece in great detail.
On the technology side, the B9 Scan 350 combines a blue LED 100 ANSI-lumen structured light, dual 1. 3 MP cameras, and a two-axis turntable for 360° scans.
The machine pushes a 0.015 mm accuracy – a bargain considering it costs nearly half the price of market-leading options like the Artec Micro.
It requires minimal setup and the bundled Leios 2 software works a treat, processing high-quality scans in minutes.
Whether you’re reproducing heirloom jewelry, scanning gemstones, or repairing, the B9 Scan 350 is a solid and relatively affordable choice.
Shining 3D AutoScan Sparkle
- Price: $13,000-$14,000
- Accuracy: 0.01 mm
- Max Scan Volume: 100 x 100 x 75 mm
- Technology: Structured light
Another scanner designed exclusively to capture the intricacies and detail of jewelry, the AutoScan Sparkle comes from Shining 3D, one of the leading brands of industry-grade handheld scanners.
With that know-how transferred to the AutoScan Sparkle, the company has created a compact desktop machine that, through a combination of AI scanning algorithms, one-click scanning, and powerful JewelScan software, makes easy work of creating digitized versions of even the most complex jewelry pieces.
The AutoScan Sparkle features a three-axis multi-angle scanning turntable, blue LED light source, dual 5.0 MP cameras, 0.01 mm metrology-grade accuracy, and, unusually for jewelry 3D scanners, an above-average 100 x 100 x 75 mm scannable area.
A sleek, compact design with a hinged front panel sees it meld seamlessly into any jewelry workshop or design studio.
Like the B9 Scan 350, the AutoScan Sparkle hits a price point that’s appealing to jewelers on a tight budget, especially considering you won’t find a three-axis turntable on those pricier alternatives.
Aurum LT
- Price: $17,000-$18,000
- Accuracy: 0.01 mm
- Resolution: 0.086 mm
- Max Scan Volume: 110 x 95 mm
- Technology: Structured light
With a focus on capturing highly-detailed scans of small, complex objects such as jewelry, Open Technologies’ Aurum LT is another jewelry 3D scanner well worth adding to your shortlist.
It easily captures all the fine detail of even the most complex gemstones.
The Aurum LT boasts one of the largest scannable areas on the market, hitting a roomy 110 x 95 mm.
While not the best out there, the 0.086 mm resolution is sufficient for producing detail-rich scans of everything from bands to odd-shaped gemstones.
It also features a 360° turntable, two 2.62 MP cameras, one-click scan triggering, and the Open Technologies’ Optical RevEng software, which is stacked with mesh repair options, alignment profiles, and exportable formats for CAD editing.
D3D-s 3D Jewelry Scanner
- Price: $6,000-$8,000
- Resolution: 0.010 mm
- Max Scan Volume: 100 x 130 mm
- Technology: Structured light
Born of a successful Kickstarter campaign, the D3D-s 3D Jewelry Scanner is one of the most affordable jewelry 3D scanners available.
D3D-s offers such a low price by producing in small batches to keep costs down without sacrificing the quality of the scanned models.
Instead of the industry-standard light pattern scanning method, the D3D-s Jewelry Scanner uses LED-line technology to create a more uniform capture.
The scanner has six degrees of freedom, meaning it can tilt and rotate to capture every aspect of an object for a complete scan with next to no user input.
It features a 5 MP camera capable of a 0.010 mm resolution, a roomy 100 x 130 mm scan area, and compatibility with in-house D3D-s-developed software that allows export to popular CAD suites like Blender, Maya, ZBrush, and many others.
FAQs
Can you 3D scan a wedding ring?
Yes, absolutely.
Scanning both wedding rings and engagement rings is a service a steadily growing number of jewelers are starting to offer, whether to create custom-fitted wedding bands or produce a striking ring at a much lower price.
Additionally, 3D scanning allows jewelers to create 3D models of heirloom wedding rings passed down through the generations for repairs, replication, insurance against loss or irreparable damage, or replacing an aging fitting.
How to choose a 3D scanner for jewelry?
When choosing a jewelry 3D scanner, consider specifications such as accuracy and resolution.
These largely determine what jewelry you can scan and the quality and precision of these scans. We recommend at least a 0.01 mm accuracy and a 0.2 mm resolution for solid results.
Price is also a significant consideration. You can expect to pay anywhere from $8,000 for the lowest cost professional jewelry 3D scanner to $30,000 for the most advanced, high-precision options.
How easy is it to 3D scan jewelry for 3D printing?
Extremely so.
Most jewelry 3D scanners feature one-touch scanning. The process is automated, leaving you with a 3D model that you can quickly process into a format compatible with a high-resolution resin SLA 3D printer.
Choose your object, place it on the scanner, trigger the scan, then process the results via software to obtain the model.
Although we recommend some experience, the process is unlikely to overwhelm first-timers thanks to clear instructions, user-friendly functionality, and intuitive controls.
Other articles you may be interested in:
- The Revopoint POP 2 hands-on review
- The best cheap 3D scanners
- DIY 3D scanners and 3D printable 3D scanners reviewed
- The best 3D scanner apps
we choose the best in 2022 in our direction
In order to expand the user audience, SHINING3D offers universal solutions - the same 3D scanner is able to satisfy the needs of ordinary consumers and large businesses and be in demand in the conditions of industrial production of products. Based on the feedback, comments and reviews of device owners, taking into account their needs, the developers have improved the line of models, making 3D digitization and additive technologies even more accessible. 9Ol000 Transcan C
EinScan Series 3D Scanners
For Beginners, Designers or Education
th The application of scanning relatively small objects requires precision and advanced settings in the snapshot processing program. The first thing users are guided by is the scanning area. With the help of two models - EinScan-SP and EinScan-SE - it will be possible to scan an object from 30 × 30 mm. Very important for the buyer and their price, as well as mobility and ease of movement.
EinScan-SP and EinScan-SE are useful for beginners, designers and educational users. Desktop scanners SE and SP are the easiest to learn.
Key benefits:
- Easy scanner setup with Plug and Play technology;
- Russian software interface;
- the ability to scan objects of different sizes - from small to large;
- texture tracking.
- one scan time - 4-8 seconds;
- Russified software;
- automatic and fixed operation;
- Align scanned data with marks.
- 8 seconds per scan;
- time required for 360 degree scanning in Auto Scan mode - 2 minutes;
- Russified software;
- automatic alignment of multiple scans;
- API access service for 3D printers of any brand.
Scanners for objects of different sizes
Due to their large dimensions, some parts need to be scanned from a distance of several meters - in this case, portable devices are used. In this category, models with the “H” index successfully demonstrated their capabilities: EinScan H , EinScan HX from the line of mobile hybrid devices. If you choose by price, the most affordable is the portable EinScan H.
Two of these models stand out from the list of products that SHINING3D produces by the presence of hybrid light sources:
- EinScan H - an invisible infrared emitter spectrum has been added to the LED backlight;
- EinScan HX - white LED light combined with a blue laser.
This high-tech solution makes it possible to use these two professional scanners. Manual mode allows you to scan objects of different sizes - medium and large.
To improve the accuracy of the photographs, glossy surfaces are treated with a matting spray. But with the help of some devices, the digitization of such objects is performed without preliminary application of auxiliary compositions to their surface, which saves a little time.
- Structured radiation from an LED source and a scanner laser projecting crossed laser beams onto the surface.
- In Laser Scan mode, object scan accuracy is 0.04 mm.
- Minimum distance to point is 0.05 mm in laser mode.
- High efficiency in fast scan mode - 1,200,000 points/s.
- Full color reproduction of the part.
Copying accuracy is so great that when scanning objects of works of art, it is possible to obtain an almost perfect replica. For medical institutions, this is also a worthy find. Separately, it should be noted the presence of a built-in color camera.
There is a free download of PC software with many functions for setting up and calibrating the equipment. The installation package is also supplied on a USB stick if you need a stand-alone installation in the absence of Internet access. Even an operator without experience and knowledge can work with the intuitive interface of the program, which saves time on staff training.
3D scanning of people and their faces
If living objects are selected for work, a special scanning technology is required. You can get a digital copy of a fragment of a human body, face and hair using EinScan H hybrid models - thanks to two light sources and a color camera, they produce an ideal 3D model with texture preservation. A special requirement for the model: it must not move.
- Two scanning technologies - LED and infrared light, invisible to the human eye, combined in one device.
- Scanning people (portrait, full-length) and other living objects.
- High accuracy of scanned data up to 0.05 mm and volumetric accuracy of 0.1 mm/m.
- Resolution up to 0.25 mm.
- Fast scanning and large scanning FOV 420 × 440 mm.
According to experts who have been conducting research in the world of additive technologies for many years, specific criteria are set for certain tasks: the more complex the part geometry, the higher the scanner resolution should be. But it will also take more time to digitize, and the file size will increase due to the multiplication of the number of cloud points with a smaller distance between them.
Of the three samples, the HX version is the universal laser scanner model, and the Einscan Pro HD/Einscan Pro 2x 2020 are multifunctional scanners that have the ability to perform tasks in various industries.
The EinScan Pro HD is an upgrade from the older model of the Einscan Pro 2x series, thanks to its ergonomic and high quality design. Models in this range can be used with a special tripod.
This professional 3D scanner provides high precision scanning of objects in both operating modes: up to 0.045+0.3 mm/m.p. in manual mode and up to 0.04 mm. in fixed scan mode.
Manual object scanning has two submodes: Rapid and HD, the latter providing a higher level of detail (resolution). Depending on the complexity of the geometry of the object, the presence of deep holes and 3D scanner parameters, such as resolution (distance between points), the final image may require further processing in the program.
The maximum possible scanning speed for this scanner is 3 million points per second. Even if we ignore the specifications, we can see that this device is extremely fast in real-life scenarios. For example, a 220 x 71 cm low-relief sculpture takes less than one minute to digitize in color.
Scanning of human bodies is also possible with this device, it provides decent quality. Last but not least, using a 3D color scanning camera with the device allows you to get scans with color and texture and realize even more projects. To keep the best price and reduce costs, manufacturers offer such cameras as an additional Color Pack option, which is paid only by those consumers who work with texture models and who really need it.
EinScan HX is more expensive than the EinScan H scanner, and functional professional scanners, which include the EinScan Pro HD, are traditionally more expensive than other classmates and therefore are available to large manufacturers in the field of additive technologies.
EinScan Pro 2X 2020 3D Scanner
This portable and versatile handheld 3D scanner helps you get highly accurate results.
The EinScan Pro 2X 2020 3D Scanner is an excellent option for scanning small, medium and large objects.
3D scanner EinScan Pro 2X 2020The updated scanner model has improved the main characteristics, added new 3D scanning algorithms. Thus, Einscan Pro 2x 2020 has become a more affordable version of Einscan Pro HD, retaining the advantages and features of the old model.
The main improvements of the new model:
- A new principle of 3D scanning of the device in manual HD mode, which allows scanning without the use of markers (as Einscan Pro HD does). The old model could not scan without markers in this mode. The quality and detail of scans have also been improved.
- Higher device scanning accuracy in manual HD mode, improved volumetric accuracy for scanning large objects.
- Higher scanning speed in manual HD mode.
- Increased 3D scan area.
- Added alignment modes in manual HD mode: alignment by markers, by geometry, hybrid alignment. This expands scanning capabilities and efficiency in a wider range of tasks and areas.
Einscan Pro 2x 2020 3D Scanner is compact and lightweight, you can take it with you anywhere. It has a comfortable handle and is light (namely 1.13 kg) and easy to hold in your hand, and if you need HD mode accuracy, put the scanner on a tripod. The scanner is connected via USB 3.0 to a computer or laptop.
According to experts, the latest developments in the field of data capture and optimized algorithms make the 3D scanner Einscan Pro 2x 2020 a truly breakthrough - its scanning speed reaches 1,500,000 points per second (at 30 frames per second) in manual scanning mode.
If you need to expand the functionality of the scanner, Shining 3D offers several optional options:
- Color Pack 3D Scanner is an optional camera that allows you to scan with color and texture.
- Industrial Pack - accessories such as turntable and tripod. Suitable for high quality scanning of small objects in the studio.
Transcan C 3D Scanner
The Transcan C 3D Scanner is a professional grade scanning 3D scanner capable of capturing “superiorly” accurate high-resolution scans of small to medium objects thanks to two 12 megapixel color cameras with adjustable scan range and multi-level switching permits within a single project.
The 3D scanner has a sliding design that allows you to easily switch the scanning range between 150 x 96 mm and 300 x 190 mm when working with objects of different sizes. The multi-resolution fusion algorithm makes it possible to mix high, medium and low resolutions in one project, which makes the scanner much more efficient, and its two cameras can capture a 24-bit color map to capture detailed 3D color data and provide better results.
The Transcan C has a structured light scanning mode with an automatic turntable that, in combination with the scanning software's stitching algorithm, allows efficient 3D model acquisition without manual intervention.
What other indicators you need to look at to choose what you need
The technical characteristics of the devices determine their use in a particular area: in jewelry, high detail is required, in industry - accuracy, in art - the possibility of color digitization, in the field of education - ease of setup and others. Of course, the properties are considered in a complex: the most important parameter is considered as a basic one, the rest are considered as auxiliary, but at the same time mandatory.
3D Scan Accuracy
The degree to which the copy matches the original is perhaps the most important indicator. The technical characteristics of scanners indicate the maximum allowable deviation of the scan size from the real object. The indicator is measured in millimeters or microns (1 micron = 0.001 mm). The smaller the number, the more accurate the 3D scan will be. But the deviation in reality can be larger, since it is quite difficult to create ideal conditions for the device to work, the result is affected by:
- characteristics of the object;
- user qualification;
- scanner settings.
It is important to understand that accuracy and resolution are different characteristics of scanning equipment. Detail is the smallest distance between points, the limitation of which is due to the resolution of the cameras and the principle of the scanner.
Ability to digitize in motion
Triangulation 3D scanners will help to scan moving objects, which can lead to an increased cost of devices of this type. This technology is not usually found in handheld 3D scanners, but among the offerings of the company with a rich history of SHINING 3D is the 2020 model EinScan HX, which at that time implemented triangulation technology.
The use of professional 3D scanners in metrology
3D scanners cope with the processes of measuring sizes and shapes of models in a matter of minutes, unlike traditional coordinate measuring machines, in which coordinates are read by contact sensors. The non-contact mode of operation enables the device to scan and measure surfaces of complex shapes (internal corners and edges), recesses and other hard-to-reach places.
After receiving all the necessary data during the processing of the object, they are transferred to the computer for processing. The program performs a comparison of indicators in order to identify deviations - a mismatch in shape and size, the presence of chips, cracks and other deformations caused by mechanical stress or corrosion processes.
Innovatively adapted blue laser 3D scanning technologyOptimScan-5M, 3M and AutoScan Inspec "scanner-inspector" are designed for metrology purposes for scanning a small object. All these devices, to some extent, belong to the same price niche, are multitasking, provide an opportunity to obtain high-quality digital 3D models for comparison with reference samples, demonstrating:
- the highest scanning accuracy;
- the ability to upload scans to processing programs;
- compatible with CAD/CAM technologies;
- work with objects of various sizes and shapes, including those with complex geometry;
- texture tracking and color imaging.
Professional, they are also industrial, 3D scanners help to perform a wide range of tasks:
- reverse engineering;
- ultra-precise 3D quality control;
- implementation of intermediate stages of the technological chain of creating products using additive technology;
- faster prototyping and other operations.
On the Russian market, you can find interesting offers for the purchase of scanning devices for photogrammetry at a fairly reasonable price. However, you should pay attention to their characteristics, especially such as the resolution of cameras, the distance between points, and some others that are important for measuring instruments, since the accuracy of the results depends on them.
3D scanning in mechanical engineering
Integration of 3D scanning technologies into production processes provides undoubted preferences. Properties of modern industrial scanners:
- high speed;
- ultra-precise measurement and digital copy saving;
- processing of objects regardless of the size and complexity of the form;
- possibility of implementation in automated process control systems.
With the help of 3D scanners and specialized software, numerous processes can be performed:
- reverse engineering, or reverse engineering;
- metrological control;
- test measurements of geometric parameters for the purpose of quality control and detection of defects;
- creation of archives of digital models.
Reverse engineering
Reverse engineering of complex shapes is one of the areas of industrial engineering. A physical sample is translated into a digital copy using a 3D scanner, which can be reproduced on CNC machines and turned into a finished product. To do this, the resulting polygonal model is converted into a popular CAD format. The digital copy is modified and modified to achieve the specified parameters. This allows you to move from traditional design to a new level, when it takes several times less working time to work. The finished object becomes the basis for serial production of products.
With a large selection of laser and optical 3D scanners on the market, there are not so many budget devices in this segment that are used for prototyping and solving other engineering and everyday tasks related to 3D modeling.
Quality control
Metrological 3D scanners make it possible to obtain a point cloud of the test sample, on the basis of which an ultra-precise 3D model of the part is formed. It is compared with a digital copy of a reference sample or with an existing CAD model.
Benefits of 3D quality control:
- Absolutely accurate data for reference comparison;
- measurement of millions of surface points;
- high speed operation;
- possibility of automatic operation.
The obtained data can be used for reverse engineering.
Scanners from the metrological category are recommended for quality control. It can be either stationary or portable.
FreeScan UE Handheld 3D Laser Scanner
Shining 3D FreeScan UE is the latest addition to the FreeScan line of high performance 3D scanners. The device uses the patented blue laser technology and features high accuracy and stable repeatability.
Sunny Wong, product manager of Shining 3D, states: “Innovative adaptation of blue laser 3D scanning technology, high precision and stable repeatability, and easy and convenient operation of hardware and software, allow FreeScan UE to effectively and accurately upgrade digital workflows in engineering and inspection tasks, ensuring the quality of the final product.
The metrology-grade FreeScan UE system delivers 0.02 mm accuracy and 0.02 mm + 0.04 mm/m volumetric accuracy. With a maximum scan area of 510 x 520mm, users get a field of view suitable for large-scale reverse engineering projects.
AutoScan Inspec high-precision stationary 3D scanner
AutoScan Inspec- The interface is immediately clear to the user.
- The accuracy of the 3D model reaches the metrological level with an error of 10 µm (0.01 mm).
- The device can be used for non-contact measurement and quality control.
- The process is fully automated.
Works with native software developed by SHINING 3D programmers for industrial applications. The PC communication program supports STL format output files. This simplifies further 3D printing of parts from various transparent photopolymers on a 3D laser printer and saves time on intermediate data processing.
OptimScan-5M 3D Metrology Scanner
OptimScan-5MProfessional metrological 3D scanner OptimScan-5M shows the best consumer characteristics required just for 3D inspection:
- accuracy - 0.
015 mm;
- two 5-megapixel cameras;
- high processing speed;
- blue light scanning technology.
AutoScan Inspec Desktop Scanner is a two-in-one scanner-inspector that works in automatic mode. The scanner performs 3D scanning with the highest precision and 3D inspection of objects. For working with complex parts and the smallest elements, this is one of the best devices:
Solutions for dentistry
In dental orthopedics, 3D scanners – intraoral and dental – have become indispensable assistants for orthopedists and dental laboratory specialists. The former are used for scanning, creating digital impressions and then manufacturing perfectly fitting prostheses, crowns, veneers and other dental restorations using a 3D model using CAD / CAM technology. The second digitizes plaster casts or abutments with tiny elements.
Aoralscan 3Aoralscan 3 is a compact, powerful device with simple and user-friendly operation and updated algorithm:
- Light weight, only 240 g.
for a full arc.
- 2 tip sizes, suitable for adults and children.
- AI Scan - Speed up the scanning process.
- Powerful software, ortho modeling and oral health report.
AutoScan-DS-MIX Dental 3D Scanner
AutoScan-DS-MIXAutoScan-DS-MIX is an exceptional performance dental scanner with two 5 megapixel cameras and advanced blue light 3D scanning technology:
- scanning speed of one jaw - 13 seconds;
- high accuracy - 7 µm;
- data export to virtual articulator;
- the ability to work with non-separable objects;
- own fully Russified Dental Scan software compatible with most CAD/CAM solutions.
Among the 3D modeling and additive manufacturing products offered by SHINING 3D, at an affordable price, you can easily find the right equipment to solve the tasks in industry, medicine, education and everyday life.
Jewelery 3D Scanner Wide Range of Applications
Jewelery
Experts recommend
Author: Semyon Popadiuk
Author: Semyon Popadiuk
1. Modify existing models | 2. Create an individual design | 3. Ensure the perfect fit | 4. Save your jewelry | 5. Repair damaged jewelry | 6. Identify flaws at the design stage
Have you ever wondered how 3D scanning can improve the design and manufacturing process of jewelry? 3D scanning is a fast, accurate and cost-effective method of capturing detailed information about jewelry and digitizing that information.
By incorporating a 3D scanner into your workflow, you will not only save money and reduce production costs, but also be able to meet a wide range of market demands. In this article, we list only six ways that a 3D scanner can be used by your business in the design and manufacture of jewelry.
1. Modify existing models
By scanning an existing piece of jewelry, you get a base model that is easy to modify with CAD software. This means that you can create an entire line based on this model without having to disassemble the original product. In addition, with a base model file, you can easily modify old jewelry to give it a modern look, or create a single style design that can be seen in a variety of jewelry such as earrings, pendants and charm bracelets.
2. Customize your design
Inspiration can be drawn from everything that surrounds us. However, until recently, bringing many ideas to life was not easy, because some objects are too difficult to measure to use as a starting point in design. Now this problem is in the past. Thanks to 3D scanning, you can digitize literally anything you want when designing, whether it's a piece of rock, a leaf of a plant, or even your pet's paws! Expand your creative horizons and create personalized items for your customers that will become great memorabilia for them.
3. Ensure the perfect fit
You don't have to worry about fitting gemstones to your creations at all. The 3D scanner allows you to create models that are perfectly compatible with the stone, since you can simply scan it in advance. This ensures that the final product will fit the gemstone, meaning you no longer have to worry about fitting or possibly damaging the stone. In addition, you can also scan your client's wedding rings, and their design will then serve as a link between all elements of the wedding ceremony, which will perfectly match the rings.
4. Save jewelry
By keeping a digital copy of your existing jewelry, you can create replicas in different materials, sizes and thicknesses. This means that you can wear an identical copy of the heirloom, keeping the original in a safe place, and not have to worry about damage or loss of jewelry. The digital archive will also be indispensable for recreating jewelry that may be lost (for example, one earring from a pair).
5. Repair damaged jewelry
Even if you don't already have a digital copy of a piece of jewelry, you can still restore a damaged or broken piece by scanning an existing one and remaking it. Thanks to the high precision of 3D scanners, you will get the perfect solution, especially when used in conjunction with a 3D printer to print a custom mold to produce a finished product.
