My Personal Guide to 3D Printing Battletech Minis

FIRST AND FOREMOST: If you decide to 3D print, STILL SUPPORT CATALYST / IRON WIND METALS - they are the reason this game still exists! (and if you can spend $ on a 3D printer, you can buy some box sets / minis.)

SECONDMOST: This process requires a few things to be a viable endeavor:

A degree of technical ability - you will need to use basic hand tools (allen wrenches, screw drives, craft knives, etc)
A willingness to work with (somewhat) hazardous materials - you won’t be handling spent nuclear fuel rods or uncleaned medical testing equipment from a foreign virus lab (wink wink), but you will be handling concentrated isopropyl alcohol, and resin that can be very irritating to skin / eyes. Gloves are a must, goggles / mask strongly encouraged.
Some spending money - I’ve spent about $500 (USD) so far, though it CAN be done cheaper (printers have gone down a lot recently, and a lot of things I bought are optional or you may already have. ) The actual cost of materials per mini is about $0.25-0.50, most of the cost is setup.

So onto the guide!

There are many great general guides to 3D printing, and r/3Dprinting has an awesome beginners guide. So I won’t repeat them here. Instead, I will provide insights specific to Battletech.

There are two main types of 3D printers available to hobby-level consumers: Filament (FDM), and Resin (SLA/DLP). For Battletech (or any tabletop miniature, really) Resin is better - higher resolution and clarity of details. See: https://www.windowscentral.com/resin-or-filament-3d-printing-which-best-you for more in-depth info.

There are many great resin printers available for under $300. I personally bought an AnyCubic Photon Mono (not the X or the SE, just plain mono - their product naming kind of sucks) which is a great deal for the $.

MY PROCESS:

Begin with the “Seven P’s”: “Prior Proper Planning Prevents Piss Poor Performance” - setting up a semi-permanent workspace, and doing all your design work ahead of time.

STEP 1 - ACQUIRE STUFF

You will need:

A 3D printer (duh)
Liquid resin (I prefer Elegoo to AnyCubic, there are a lot of posts about this debate, but the Elegoo Standard Grey works fine for BT minis.)
Isopropyl Alcohol (most sites say use 99%, I’ve been using the 91% available at Walmart. Works well.)
Safety Goggles / Mask (optional, but strongly recommended)
Medical Gloves (Nitrile are the best, about $20/box, nylon are ok, but can’t really be reused. Haven’t tried latex, some people are allergic.)
A UV-lamp (optional, but recommended. The “official” ones are like $100, I bought a cheap one with a rotating stand for like $20. Or you can use sunlight, but it takes a while and winter is coming.) (Second note: UV barely travels through glass, so can't be indoors, that why you don't get a tan through the window.)
A LOT of paper towels (there are some things you shouldn’t use these on, but for everything else…)
A few microfiber rags (for the stuff you can’t use paper towels on. )
Some paint filters and funnel (most printers come with a few, and if you follow this guide, you won’t need a ton.)
A plastic pickling container with strainer (completely optional, but makes cleaning models a lot easier)
X-acto / craft knife.
“Nippers” (precision wire cutters.)
A level workstation away from kids / pets / other disturbances.

STEP 2 - ACQUIRE MORE (digital) STUFF

Before you print something, you need a blueprint. For 3D printing, they use files called STLs. If you have 3D modeling experience you can design your own. But for the rest of us:

Piranha Games has made the 3D models used for Mechwarrior Online open source, this has created some great opportunities with a few caveats: They are free for PERSONAL USE, you CANNOT SELL BATTLETECH prints.

Some great places to search for .stl files are MyMiniFactory.com, and Cults3D.com. Thingiverse is the biggest repository of STL files, but has had some issues. Search for “American Mecha” if you are having trouble finding what you want. You will have to find hex bases separately. The official bases are 29.5mm across. Most files are about 50mb. I downloaded a LOT of them :)

You also need the software to edit / slice them. Anycubic printers come with a software that has a few very useful features, but isn’t the best overall. Personal I use three different programs for each mini: Anycubic Photon Workshop (comes with printer, also avail free), PrusaSlicer (free version), and ChituBox (free).

STEP 3 - GET EVERYTHING READY

Setup your printer according to instructions. If you want some how-to videos, I found “3D Print Farm” on youtube especially helpful. My setup is pictured here: https://imgur.com/a/NEKjzBx

For the mini’s STL files: Firstly, I open the STL in ChituBox and before anything, “slice” it. (there are lots of guides on what this means, and should show up in your instructions also.) This isn’t to print, but to find out the volume of the mini. While almost all the minis I’ve found are ‘good enough’ size wise, I wanted more, and using the Wolverine WVR-6R as a baseline (Because I have the 3rd edition, beginner box, and Syllogy’s STL to compare) reached the conclusion that models should be almost exactly .1ml per ton (the 55-ton WVR is 5.49ml).

I included a comparison image here: https://imgur.com/a/NEKjzBx

You can use a volumetric formula to figure out exactly how much to increase or decrease size to get to that, but trial and error works for me. A discussion on this from a few years ago is available here : https://www.reddit.com/r/battletech/comments/9w2kyd/battletech_miniature_sizes_3d_printing_need_help/

Then using ChituBox I added the base, and save the file as an STL (NOT save project).

Then I open it with Anycubic Photon Workshop software, because it has a very convenient feature to add text. I found that font size 2 (if you type 2, it will default to 20, so you have to fix it) and font height of . 5 works perfect to type on the bases. Re-save the file.

Next I open it with Prusa Slicer, because it has the best (and frankly only good) auto-support tool. This guy has a great 10-min video about it: https://www.youtube.com/watch?v=S4KRazqrMjE

Export the STL with supports, and save (I save using a different filename in case I don’t like the job the auto-supports did.)

Finally, I open the supported STL back with ChituBox. I have found that, to save time, I could fit THREE mechs on my printer at a time, and since it only matters how tall the print is, not how much material it uses, this saves a TON of time (and wear on the printer.)

STEP 4 - SLICE IT AND PRINT IT!

Do what step 4 says.

There’s a bunch of post printing clean-up, and touch-up stuff, but that should be covered easily in the instructions, and other beginner guides.

Pro Tip: plan to print en masse - my printer takes about 2.5-3 hours per print (at three mechs per), you don't have to stand over it, just be ready with the files to start the next one each time. As long as the resin in the printer keeps getting topped off, you don't have to worry about filtering it back, or having it separate from sitting too long. Filter and clean the VAT only when it's going to sit unused for several days.

STEP 5 - PRIME, PAINT, SEAL

I am still working on painting techniques, but it seems like this community already has that part down!

STEP 6 - FIND FRIENDS AND PLAY!

Thank you guys for reading this! I will keep this updated with any feedback or corrections people have!

Happy Hunting!

-DaCrazyJamez

3D Printed BattleTech Models: Miniatures and Large-Scale Mechs

Fans of tabletop gaming enjoy numerous war games that could feature 3D printed BattleTech warriors. From Warhammer 40K to the original BattleTech and D&D, the rules might be different. Still, the characters can easily intersect with each other. Thus, you can 3D print your most beloved BattleTech miniatures and large-scale models and prepare your mechs for armoured combat on a battlefield.

3D printing has already revolutionized both miniature sculpting and large-scale models’ creation. With a 3D printer, it is possible to build multiple highly detailed BattleTech models that could replace figurines in your tabletop game or decorate your shelf. All you need are premium 3D printing files, your 3D printer, some creativity, some painting skills and some free time for your hobby.

BattleTech 3D Models with Files for Your 3D Printer

You will find many great MWO BattleTech 3D models with STL files on Gambody – Premium 3D printing marketplace. The impressive level of detail will show off in all 3D printed large-scale BattleTech models, as seen on numerous images of finished mechs shared by talented enthusiasts from across the world.

You can also 3D print BattleTech miniatures for your tabletop games and surprise your friends with a unique mech team ready to battle. So, get inspired by the 3D printed mechs and turn the best 3D models into real masterpieces.

Large-Scale BattleTech Models

Fans of large-scale BattleTech models will find many impressive mechs for 3D printing on the Gambody marketplace. The level of detail and remarkable likeness of each piece to the original character will genuinely impress every 3D printing enthusiast.

Hobbyist Chris Corsello, for example, used silver PLA to 3D print Cyclops on his Anycubic i3 Mega 3D printer. This action assembly model boasts many impressive details as well as movable parts. Would you also like to add one to your collection? Download the Cyclops STL files for 3D printing on Gambody marketplace.

Cyclops model 3D printed by Chris Corsello

Timber Wolf is one of the most iconic characters in the BattleTech universe. This mech is very aggressively looking. The model has a twisting body and movable arms and legs, making the Timber Wolf STL files a candy for every 3D printing hobbyist, including Darren Hadland. This maker added life-like rockets with the wow FX effects.

Life-like 3D printed Timber Wolf model made by Darren Hadland

A popular bipedal vehicle from the BattleTech universe, MWO War Hammer, is another example of an impressive mech with armour and deadly weaponry. Maker Thomas Cate showed how detailed the 3D printed War Hammer is even without paint. And hobbyist Keith Kosmal chose grey and bright yellow colours to complete this model. You can 3D print it as well after downloading the BattleTech War Hammer STL files.

War Hammer models made by Thomas Cate and Keith Kosmal

Enthusiast Scott Murphy 3D printed a large-scale BattleTech model UrbanMech on his Creality Ender-3 using UrbanMech STL files. He made sure to paint the mech with bright green decor over a metallic body. In addition, the maker showed the BattleTech mech next to miniatures to demonstrate the impressive model’s size.

Large-scale BattleTech UrbanMech model 3D printed by Scott Murphy

Besides, Scott Murphy recreated Jenner Oxide. He modified the original Jenner STL files and added some tubes and armour parts to the national pride of the Draconis Combine.

Jenner Oxide created by Scott Murphy

Matthias Schotten 3D printed a mighty BattleTech Shadow Hawk model. Then he planned to sand and paint it, but even unpainted, his project wows with a high level of details. Moreover, all the limbs are movable; thus, the maker can pose his mech. You can do this as well after getting the Shadow Hawk model STL files for 3D printing.

Shadow Hawk made by Matthias Schotten

3D printing is not only about bringing to life your most beloved characters. It is also about creativity. Different hobbyists make different versions of the same model and amaze with stunning ideas.

Fans of BattleTech models will enjoy the large-scale Archer mechs 3D printed and painted by Tony Adkins and Scott Murphy. These two machines impress with one-of-a-kind looks, and you can fantasize too once you download the Archer STL files.

Archer mechs 3D printed by Tony Adkins and Scott Murphy

Gambody hobbyists created many fantastic BattleTech Catapult 3D prints. Still, the work by Alexei Bruton truly stands out and is a must-see. The maker recreated the mech in 1/64 scale and showed how giant this large-scale project appears when compared to the 28mm miniatures standing next to it. You can also further extend your BattleTech universe by 3D printing the Catapult STL files.

Catapult made in 1/64 scale by Alexei Bruton

Enthusiast Nawaf Bunashi presented his version of a 3D printed BattleTech Mad Cat MkII model. The creative maker added a shark smile to the bottom of the mech’s cabin. Therefore, this piece of art looks unique and can decorate your shelf as well. Of course, you would need to download the Mad Cat MkII STL files to 3D print this project in its original 1/60 scale or at a larger size.

Mad Cat MkII model 3D printed by Nawaf Bunashi

Hobbyists know how incredible it is to finish 3D printing all the parts of the project. And many believe that it is equally essential to paint 3D printed models. Still, not everyone has enough time to complete this task right after 3D printing.

Luckily, the large-scale BattleTech models you can find on Gambody have many intricate details and features. Therefore, your mech will look stunning even without paint, just like the Hellbringer made by Buddy Magsipoc. You can get the Hellbringer model STL files to 3D print this mech warrior for your collection.

Hellbringer made by Buddy Magsipoc

Talented Buddy Magsipoc also painted his Hellbringer mech and brought to life the BattleTech Raven model (which STL files are available here). Both mechs look like real masterpieces.

Hellbringer and Raven models 3D printed by Buddy Magsipoc

The stunning BattleTech Mad Dog model can also inspire every fan of mechs for new creations. Hobbyists McGuigan Michael and Greg Mason have already built these spectacular machines. You might wish to download Mad Dog STL files to add this 3D printed mech to your backyard scene or shelf display too.

BattleTech Mad Dog model 3D printed by Greg Mason and McGuigan Michael

Enjoy the photos of 3D printed large-scale BattleTech models and get MWO STL files for recreating the best projects on your 3D printer.

Read also: Fantastic MechWarrior 3D Print Collection of 25 Models

3D Printed BattleTech Miniatures

Usually, the large-scale BattleTech models are offered at 1/60 scale, or you can make them way bigger. But you can also 3D print BattleTech miniatures in 1/144 scale if you love MWO games or 1/285 scale if you are a fan of BattleTech games. You can find many mini-versions of war machines online.

Of course, the size of the 3D printed BattleTech miniatures mainly depends on the size of the terrain you are using for tabletop games. Some hobbyists love to build giant terrains where even 1/100 scale mechs would look relatively small.

This stunning 16-cm BattleTech Rifleman, for instance, was made in 1/100 scale on an Anycubic Photon Mono X 3D printer by Nicolas Reiser. Adore all the beautiful details and download the Rifleman STL files to do a similar project.

Rifleman model 3D printed by Nicolas Reiser

Hobbyist Alan Murray built an impressive collection of 1/100 scale resin 3D printed BattleTech models. His every project adores eyes with bright colours, great details and fantastic paint job. As for you, it is easy to find all these and many more BattleTech models for 3D printing on the Gambody marketplace.

Cataphract, Marauder, Stalker and Shadow Cat 3D prints by Alan Murray

Alan also 3D printed Locust models and shared a photo that allows comparing the 1/60 scale DLP 3D print and 1/100 scale resin mech.

Locust models in 1/60 and 1/100 scale made by Alan Murray

But if you are a big fan of 3D printed BattleTech miniatures, you can make even smaller mech models of 40mm, 35mm, 28mm and less using your 3D printer. Such tiny projects will fit on your palm. In addition, you can use them in your tabletop and board games.

Below are great examples of small 3D printed mechs. You can also 3D print BattleTech miniatures at a bigger scale than the ‘standard board’ size as done by Thingiverse makers hungryspacelizard and clandaith.

3D printed BattleTech miniatures by clandaith and hungryspacelizard

Or you might wish to design your one-of-a-kind 3D printing BattleTech models in 1/144 or 1/285 scale making the tiny 6mm-10mm figurines for a standard terrain.

It is now time to 3D print BattleTech miniatures and large-scale mech models. Build your machine army using a 3D printer, and join Gambody 3D Printing Community to showcase your stunning ‘iron’ warriors. May your 3D printed mechs encourage other creators for new activities.
