3D printer heating pad
Silicone heater mat including thermistor ( 240V / 1000W / 40x40cm ) | 3D printing experts
Overview Description Specifications
Round kapton heater mat with adhesive side
Stock - NL: >100
€ 53.68 excl VAT In stock
Dispatches same business day!
Others also bought:
Power cable with Euro plug EE 7/7 C13 ( 2m )
€ 4.67
Power cable with Euro plug EE 7/7 C13 ( 3m open end )
€ 4.21
Solid State Relay, 10 A, 280 VAC, Panel, Screw, Zero Crossing
€ 22.27
IEC C14 3 Pin Euro Chassis Panel Mount 10A
€ 2.39
Product description
Silicone heater mat including thermistor and sticker to heat up larger bed plates. 1000W guarantees you a quick heating to the desired temperature
The thermistor is a normal 100K version that will work with option 1 in your firmware. Use a solid state relay to control the heated bed from your electronics and optionally a fuse to protect against shorting. Review the following example setup for more information. Connect the thermistor wiring to your electronics board's heated bed thermistor header. The solid state relay low voltage side should be connected to the board's heated bed output, mind the polarization. The high voltage side should be connected to the one of the leads of the silicone mat, the other side to one of the 240V leads. Finally connect the other lead of the mat to the other lead of the 240V input. You can use the C14CHSMNTSW to protect the circuit and have a convenient way to turn off the heater.
Warning: Working with 240V can be dangerous, always take adequate precautions. Don't work with power on.
Specifications
| General properties | |
|---|---|
| sku | HM40CM240V |
| gtin | 8719345008306 |
| Color | Orange |
| Thermistor | |
| Material | Silicone |
| Type | Square |
Max. temperature | 130 °C |
| Dimensions | |
| Length | 400 mm |
| Width | 400 mm |
| Wire length | 100 cm |
| Electrical specifications | |
| Operating voltage | 240 V |
| Current | 4. 17 A |
| Max. Power rating | 1000 W |
Price breaks
| 1 - 4: | excl € 53.68 |
| 5 - 9: | excl € 51 |
| 10 - 29: | excl € 49.65 |
| 30 - : | excl € 48.31 |
| Need a larger quantity? Contact our Sales department. | |
