How to design and 3D print letters

We have realized that there are many people who for one reason or another need to generate 3D models of certain letters. From Bitfab we have shown you many alternatives to generate your 3D models without the need to design them yourself. Below we leave you a series of articles that you may want to read after this one:

The best sites to download STL files: in this article we explain where to look for 3D models to download
Convert a 2D image to 3D: Here you can find a tutorial on how to convert a 2D image to a 3D model. We will refer to this article later
Customized keychains, how to make them?: Here we show you a very simple way to generate key rings with text.

Based on these previous articles and new content we will explain a few ways to get 3D letter models you’ll like.

Create 3D letters from an image

In our article Convert 2D images to 3D we show you how to convert any image to a 3D model. The main method described in this tutorial works especially well with high contrast images and well defined geometries. Don’t you think the letters fit perfectly here?

Well, following the article that we have left for you above, you will be able to create in a very simple and fast way your 3D model from an image of the letters that you want. It is possible that you already have the image of the letters you want to convert to 3D, as in the case of a famous logo with text. But we also want to give you the tools to generate an image of any text with the typography you want to create your 3D model. Yes, you heard right: you will be able to generate a text using the most popular font styles and that you like the most using fontmeme. And the best of all is that it is totally free.

It is very easy to use this text generator. All we have to do is go to the aforementioned website and look for a font that you like. At the bottom of the resulting page you will find a window similar to the one we show you, where you can customize the text to your liking, choosing color and font size.

Once the text has been generated, right click on it to save the image. Now we only have to follow some of the methods proposed in our post to convert a 2D image to 3D to create our ready-to-print 3D model. If you are an Avengers’ fan, for sure you love this example, because with this system you can get something as cool as this:

Another positive of using this page, is that it has a font search engine. In it we can search for any type of font we want, and we will get results from fonts that are on the page itself or from other users’ posts linking to external sites. It is quite the powerful tool, since it allows us to access not only the catalogue of this page itself, but it also compiles the knowledge of a lot of users.

Let’s say, for example, that we are looking for the typography of the tremendously awaited Netflix series: The Witcher. If we use the search engine, we’ll see that this font is not in the page’s catalogue, but we find a post by another user where we link to another website where we can find a text generator with this font.

As you can see this method is easy and gives excellent results with very little effort. The truth is that this method is so good that we would love to see what you have created. Don’t hesitate to post a picture of your 3D letter models, because we love to see your ideas come to life. Here’s an example (spoiler: you’ve seen it on the cover) of what can be done with this method:

Create a 3D text with Fusion360

The method proposed in the previous section is great for the vast majority of users, but you may need something more advanced. If this is your case, you are in luck since we are going to show you the steps you have to follow to create 3D text in fusion 360.

First of all, download the font you want to your computer. For this we can use a page like dafont. In this web we must look for (either using the search engine or the filter by categories) a font that we like and click on download.

There are lots of websites to download fonts for free, so try googling the font you want if you can’t find it on dafont.

Install the font in our computer. This step is very easy so don’t panic. Just type “fonts” in the Windows search engine and click on “font settings”. Here we only have to drag the file of the font where it indicates us and the font will be installed.

Once the font is installed, we can use it in any program as if it were another font, such as Arial or Calibri. From here we can use any text editor, such as Word, to write the text we want, save it as an image and proceed as we have done in the previous case.

To use our font in fusion 360 we will have to use the text tool (it appears inside the sketch menu with the icon of an A). We can create text of the size we want, and we can use it as it is or include it in our designs.

Although it is a simple process, here’s a video that explains the process:

This method is quite powerful, and will allow us to integrate any text we want, in a huge variety of typographies in our 3D designs.

Conclusions

In this article we have learned how to create 3D text, either from a photo or using our own generated text. It is very easy and you have seen that you can get very cool results that will be the envy of your colleagues.

Don’t hesitate to share your creations, because we use this method often and we want you to do it too.

Any text on a 3D printer in a couple of minutes

My wife's birthday was approaching. And what's the best gift? That's right, handmade. and I decided to print the text on a 3D printer, something like a topping on a cake. I climbed Singivers and 3Dtoday, but did not find anything interesting. It would seem a simple task, but it is almost impossible to do anything artistic in SolidWorks. I came across an article that described how to solve the problem using CorelDraw and SolidWorks. Using this article, I about ... lost a lot of time, but nothing good came of it. Solid stubbornly did not want to make a boss, complaining about all sorts of problems. There was little time left, spitting on everything, I decided to go my own way. For those who are interested, welcome under cat.

And so, to solve the task, we need CorelDraw and registration on the site https://www. tinkercad.com/ Well, in addition, fantasy. So, let's begin.

Start CorelDraw and create a new document. Corel will ask you to select the dimensions of the document. As dimensions I use the size of the printable area. But this is optional.

Now select the text tool and type the desired text.

Now the magic begins. Select the Block with written text and select the menu item “Object” - “Disconnect curly text, symbols ...” Or use the keyboard shortcut Ctrl + K

Attention. The first time the command is used on a block of text, the text is divided into words. Thus, in order to divide the text into letters, it is necessary to go through all the letters, and if they are selected by several characters, it is necessary to repeat the operation on an undivided block of text and do so until the entire text is divided into individual letters.

Now, after all the text has been divided into individual letters, artistically lay out the letters the way you want them to be printed by a 3D printer. For example like this:

All. The layout of what we will turn into a three-dimensional figure is ready. And now the most important thing begins. We need to export the resulting image to SVG format. To do this, in CorelDraw we do the following: “File” - “Save As”

in the window that opens, give a name to our file and select the file type “SVG”

Now click the “Save” button And the following window opens:

Now we check that the document settings match those that we entered when creating it. So that the units of measurement are in millimeters and Be sure to export the text as curves. Those. We do as shown in the figure. do not touch other parameters. We press OK.

All file saved. Now go to the site https://www.tinkercad.com/. If you are not registered there, register, log in and create a new project.

And now the magic.

in the right corner press the IMPORT button

An import window will open in which you must drag or select your SVG file.

After selecting a file, tinkerkad will start swearing that the workspace size is too large:

There's nothing to worry about. It just seemed to him that the model was larger than it actually was. In the "dimensions" field, we bite off a couple of zeros so that they match the dimensions of your printer's table. For example, I have a table 200x200 mm. So I do this:

and click the "Import" button. All. Our text is not only imported, but also became voluminous.

Now we have a three-dimensional model, which we can adjust in size and thickness, export to an STL file (for this we use the “EXPORT” button). Well, then you know what to do.

Here are some examples of my quick work:

Sorry for the quality of the photo. Made them on the phone. Their goal was to show how it can turn out. I hope the article was useful to you. If the article turned out to be useful for you, share the link to it with your friends on social networks, websites and forums on 3D printing. Thank you!

If you have not got a 3D printer yet and are thinking about which model to choose, I can recommend the following models:

Anycubic i3 Mega 3D Printer

Anycubic Mega-S (Anycubic S) 3D Printer

Anycubic 4MAX Pro 3D Printer

These are links to trusted vendors that sell original printers. They provide technical support and give a one-year warranty.

3D printing (exclusive) to order in Moscow

Description

Branding and advertising are among the widest applications for 3D printing. Most often, additive technologies are used in the manufacture of souvenirs, but little by little this approach is being adapted to the production of large forms: signs, plates, signs. 3D printing is difficult to compete with traditional methods in these areas, but it successfully complements laser cutting and milling where it is difficult or impossible to use sheet materials.

Advantages of 3D printing in advertising

Simplification of production. Many manipulations are performed manually or with the help of expensive equipment (for example, cutting and gluing side plates). The 3D printer immediately prints the body of the product, you only need to supplement it with the front part.
Combination of materials. The equipment can be filled with two threads of different textures, which gives an original effect. The addition of UV-resistant filaments saves on protective treatment of the structure and extends its service life.
Minimization of the human factor. The result of the work does not depend on the skill and well-being of the employee, but on the quality of raw materials and printing.
Making complex shapes. Volumetric structures with a pronounced relief are difficult to make from classic sheet materials. 3D printing provides almost unlimited possibilities for design imagination.

Technologies used

Our production arsenal includes a Diamond-Tech 640 x 640 3D printer that works with PLA and PETg filaments. The equipment with the same success copes both with printing miniature letters up to 5 cm high, and with the production of three-dimensional structures up to 0.6 m high. Among its features:

accurate calculation of the cost of work and the timing of order production - the printer immediately indicates the required volume of polymer thread and the duration of the process;
the ability to print beveled sidewalls - the side parts of the structure with different areas of the front and back;
alternate printing option, which uses threads of different colors;
compatible with many file formats, including ARTCUT, STL, CDR and SVG.

Using Diamond Tech to mold the rims, two to five light strips can be obtained in a variety of combinations. The palette includes 3 opaque options and over 50 translucent shades. This set is sufficient for the production of both classic letters and original designs - for example, signs with luminous sides or contour lighting.

Liquid acrylic 3D printing

The innovative 3D printing technology is best complemented by another modern method based on the use of liquid acrylic. Volumetric letters are printed on a Diamond Tech printer, the back walls are produced by milling, and the front part is treated with a special compound.

How does this happen:

The workpiece prepared for processing is fixed on one of the tables of the drying platform. The working field is presented in two standard sizes: 1200*1500 mm with six Philips UV lamps and 1500*2340 mm with twelve lamps included.
After filling the tank with raw materials, the autosampler is included in the process. Based on the given parameters, he measures the required volume of liquid acrylic and distributes it over the front surface of the workpiece.
Under the influence of ultraviolet lamps, liquid acrylic takes a solid form. The curing of the composition without color pigment takes about 60 minutes. If there is a color pigment in the solution, the time increases to 80 minutes.

The flooded front side perfectly keeps on the surface without additional fastening to the sidewalls. Good adhesion is ensured by the material of the filaments used in the 3D printer and the special paint used to process the inside of the aluminum profile. The latter also provides a uniform distribution of illumination over the entire area of the structure.

Advantages of Liquid Acrylic and Diamond Tech

The technology minimizes the impact of the human factor, speeds up the production process and eliminates the appearance of defects. When cured, liquid acrylic forms a smooth and durable surface without chips or other defects. Ready-made signs are only slightly inferior to neon signs in terms of the spectacular glow.

The milky color of liquid acrylic looks much brighter than the traditional sheet version due to the addition of translutens. To create different shades, the manufacturer offers more than 15 options for pigment pastes, which are mixed in different proportions. The required color scheme is selected according to the factory formula, which eliminates deviations from the specified color.

You can leave an application for the manufacture of a sign using 3D printing technology by calling +7 (495) 645-21-70 in Moscow.

Video

3d printing of three-dimensional letters, filling with liquid acrylic
