Afinia H800+ 3D Printer » Afinia 3D Printer

This product is no longer available. For a comparable model, check out the H+1 3D Printer

View the H+1 Product Brochure Order Now

$1,699

The new Afinia H800+ has a build area 5x larger (10 x 8 x 8 inches) than the h580, and has many additional enhancements:

  • Fully-enclosed system with HEPA filtration
  • Fully-automated platform leveling and height sensing
  • *WiFi Connectivity
  • *Power loss print recovery and “out of filament” pause switch
  • *Customizable nozzle and platform temperatures
  • 30% faster
  • Ultra-fine 100-micron print resolution
  • One button filament color changing
  • *Upgraded printhead and gantry system
  • Smart support material technology
  • Easy filament spool loading

*  New to the H800+

Out-of-the-Box 3D Printing

The Afinia H-Series 3D Printers provide a true “Out-of-the-Box 3D Printing Experience” as the 3D Printers comes fully assembled with easy to install software for both the PC and Mac. The Afinia H-Series 3D Printers can prototype a part or model, within .10mm (4 thousandths of an inch) accuracy, that have 30% of the strength of injection molded parts.

Award-Winning Innovation

The Afinia H800+ 3D printer won the RAPID 2015 Exhibitor Innovation Award, which recognizes the most innovative new products or services exhibited at RAPID that are judged to have the greatest potential impact on the industry. Afinia 3D was selected as the recipient by the Society of Manufacturing Engineers’ (SME) Rapid Technologies & Additive Manufacturing (RTAM) Committee.

TechZone 360 also chose the Afinia H800+ 3D Printer for their 2015 3D Printing Excellence Award, citing Afinia 3D as a leader within the 3D printing industry. The TechZone 360 3D Printing Excellence Award identifies products, services, and applications that are driving the growth and evolution of 3D Printing from niche market hype to mainstream reality.

Easy to Use, Powerful Software

The 3D Printer Software features an easy-to-use interface for laying out, orienting, duplicating, and scaling parts. Simply use the included utility to calibrate the printhead height, and within minutes you are printing. It easily imports STL files, and the output can be customized in terms of the amount of support material and “raft” (base support) printed. Breakaway support material is simple to remove, and tools for aiding the breakaway are included. Design files for 3D printing can be created using online software, professional software such as SolidWorks™, or by downloading from the extensive online 3D printer community for free.

3D Printer Plastic Filament

The Afinia H800+ 3D printer uses inexpensive, high-quality PLA and Premium ABS filament for 3D printing. Afinia offers an array of plastic filament colors including: natural, black, red, blue, yellow and green. The H800+ allows custom temperature setting of both the extruder and the platform to allow for a broader range of filaments to be used such as flexible and PETG filaments.

The Afinia H800+ is now available for purchase. Order yours here.



Specifications

Printing
Print technology: Melted Extrusion Modeling(MEM)
Build volume: 10″W x 8″H x 8″D
(255 x 205 x 205 mm)
Print head: Single
Layer thickness: 0.1(100 micron)/0.15/0.20/0.25/0.30/0.35mm
Supporting structure: Smart Support Technology:automatically generated, easy to remove and fine-tunable
Platform leveling: Automatic nozzle height detection, software-assisted leveling
Build platform type: Heated, with Perforated Print Board or Afinia Flex Print Board
Consumables 1.75mm ABS, PLA, Flexible Plastic Filament, PETG
Additional features: HEPA Air filtration, Active heartbeat mood lighting (provides print status indication), on-board file storage, one-button filament color changing, power loss print recovery, “out of filament” pause switch, WiFi connectivity
Software
Bundled Software: Afinia Studio
Compatible formats: STL, UP3
Connectivity: WiFi & USB, with ability to disconnect from computer when print job starts
Operating system: Windows (XP, Vista, 7, 8, 10) 32/64 bit and Mac OSX 10. 10+, iOS
Mechanical
Power supply: 110-220 VAC,50-60 Hz,220 W; With power loss print recovery
Chassis: Metal frame with plastic case, enclosed
Weight: 55 lbs (20kg)
Dimensions: 19.1″W x 20.5″D x 19.5″H
485 × 520 × 495mm

WARNING: This 3D Printer – when used with a styrene filament (ABS / HIPS / or PC-ABS) – can expose you and others in the same room to styrene, a chemical known to the State of California to cause cancer. www.P65Warnings.ca.gov.

ALWAYS OPERATE THIS PRODUCT IN A WELL-VENTILATED AREA.

3D Plastic Filament » Afinia 3D Printer

Shop Our Filaments
View Our Filament Colors

The Afinia H-Series 3D Printer extrudes plastic filament to create 3D parts and models. The H-Series 3D printer uses high-quality, inexpensive ABS and PLA plastic filament for 3D printing.

The filament specification is 1.75 millimeters. The filament spool is easily fed by the extruder head. ABS filament is extruded at 260° Celsius to .15mm onto a platform heated to 90° Celsius, while PLA filament is extruded at 210° Celsius to .15mm onto a platform heated to 50° Celsius.

Afinia-supplied filaments have been tested to conform with the Afinia 3D printer’s specifications and work best for most applications. Although other filaments may be used, it is not recommended, as some filaments work poorly or can cause damage to the extruder head and machine. Afinia offers an array of plastic filament colors. Visit store.afinia.com to see the full range of materials and colors.

PLA Filament

Afinia Premium PLA filament has been designed specifically for the H-Series 3D printer, the most important being the 200°-210° Celsius extrusion temperature.

Third party-manufactured PLA filaments do not print consistently and have issues with brittleness, nozzle clogging, and bridging or spider webbing that can leave users disappointed with the results. Afinia Premium PLA filament has been engineered to mitigate these common issues to give a great printing experience. One of the biggest problems with PLA is the removal of raft and support material from the model. In the case of the new Afinia Premium PLA, the raft and support comes away clean leaving the user with a beautiful, glossy model.

Advantages of Afinia’s Premium PLA:

  • No pre-heating of the platform required – The H-Series platform quickly heats to a low 50°C which is the platform temperature for printing PLA
  • Reduced warping, lifting, or curling of models – Afinia’s Premium PLA filament has a reduced thermal expansion coefficient than ABS which means the PLA layers are less likely to shrink after printing
  • Less odor – Compared to ABS, Afinia’s PLA has reduced odor and a pleasant, sweet smell like pancakes

The Differences Between Premium ABS and Value-Line ABS Filament*:

The Premium ABS filament has been designed specifically to the specifications of the H-Series 3D printer, the most important being the 260° Celsius extrusion temperature. The Value-Line filament has an extrusion temperature range between 210 and 250° Celsius. This range allows for broad support among a number of different 3D printers on the market.

The lower extrusion temperature on the Value-line filament causes the raft and support material to adhere a bit harder to the model making it slightly more difficult to remove as compared to the Premium filament, but nothing too noticeable. The matched extrusion temperature on the Premium filament and H-Series also has the added benefit of slightly higher tolerance control on the dimensions of the model. Both filaments work well, but the Premium works the best.

The Premium filament comes in a vacuum-packed foil bag with a desiccant pack to keep the ABS dry during storage. The Value-Line comes in a clear plastic bag with a desiccant pack. Although it is sealed, it is not vacuum-packed.

Odor is about the same for both filaments and isn’t terribly noticeable unless you have it running in a small, unventilated room

The Premium ABS filament comes in 6 different colors and Value-Line comes in 19 colors. The same colors between the Premium and Value-Line do vary, but both are colorfast.

If you have any additional questions, please contact us.


Premium PLA Filament

Click a thumbnail to purchase in the online store.

Premium Plus ABS Filament*

1000g reels specifically designed for the H800 and H800+, also compatible with the h580/h579.

Premium ABS Filament*

2x 500g reels specifically designed for the H800, also compatible with the h580/h579.

Value Line ABS Filament*

Click a thumbnail to purchase in the online store.

Filament diameter – 1.75+/-0.10mm
Roundness – 1.75+/-0.07mm
Print temperature – 210 – 250°C

Value Line PLA Filament

Click a thumbnail to purchase in the online store.

Specialty Value Line ABS Filament*

Includes glow-in-the-dark and color-changing filaments. Click a thumbnail to purchase in the online store.

Specialty PLA Filament

Copper and Wood infused PLA filaments. Click a thumbnail to purchase in the online store.

WARNING: This Filament-when used in the operation of 3D Printers or 3D Pens-can expose you and others in the same room to styrene, a chemical known to the State of California to cause cancer. www.P65Warnings.ca.gov.

ALWAYS OPERATE THIS PRODUCT IN A WELL-VENTILATED AREA.
