Removing 3d print from bed

6 Easiest Ways How To Remove 3D Prints From Print Bed – PLA & More – 3D Printerly

You’ve finished your 3D print and come back to a lovely looking model, but there’s one problem, it’s stuck down a little too well. Many people have faced this problem, including myself.

Fortunately, there are some easy ways to help remove 3D prints from your print bed, whether made of PLA, ABS, PETG or Nylon.

The easiest way to remove 3D prints stuck on your 3D print bed is to heat up the bed temperature to 70°C then use a good quality scraper to get under the print and lift it off. You can use liquid solutions to weaken the bond between the print bed and the plastic to help remove 3D prints.

There are some details that I will describe in the rest of this article to help you remove 3D prints from your bed, as well as help you prevent it happening in the future. Keep on reading to get clued-up on some useful info.

Easiest Ways to Remove Finished 3D Prints Stuck to Bed

The method in the video below works for several people, which is a simple combination of 50% water & 50% alcohol sprayed on the troublesome 3D print.

If it doesn’t work, rest assured, there are many other methods and techniques that will solve your issue, as well as preventative measures so it doesn’t happen again.

When 3D prints stick down to the bed too much, you run the risk of actually ruining your build platform.

I remember watching one video of Joel Telling (3D Printing Nerd) breaking the glass bed of a $38,000 3D printer because the PETG literally bonded with the glass and couldn’t be separated.

There are several ways to remove stuck 3D prints, but we will list down some for you which we find the easiest and most convenient.

Apply Some Force

The most tried method of removing 3D prints from the build surface is to just use a little force, whether that is slightly pulling, twisting, bending, or just grabbing the 3D print.

In most situations, if you have a respectable setup, this should work fine, but if you are reading this article, it might not have worked so well!

Firstly, before trying to remove the print, let the print bed cool down for a considerable amount of time then try removing it manually by applying some force.

You can also use some kind of rubber mallet to dislodge the 3D print, just enough to weaken the adhesion. After it has weakened, you should be able to apply that same force and remove your print from the print bed.

Use a Scraping Tool

Next up would be using some tools, such as the spatula that usually comes with your 3D printer.

A little bit of pressure set underneath your 3D print, with additional force in multiple directions is usually enough to remove a 3D print from your print bed.

I’d use my spatula, with my hand on the 3D model itself, then wiggle it side-to-side, diagonally, then up and down, until the adhesion weakens and the part pops off.

Disclaimer: With any sharp print removal tool, watch where you put your hands! If you slip, you want to make sure your hand is not in the direction of force.

Now, not all scraping tools and spatulas are created equal, so that stock one that comes with the 3D printer isn’t always the best.

Getting yourself a proper print removal kit from Amazon is a great idea if you are having issues removing prints. I’d recommend the Reptor Premium 3D Print Removal Tool Kit.

It comes with long knife with a beveled front edge, allowing for gentle sliding underneath prints, as well as a smaller offset spatula with a black ergonomic rubber grip and safe rounded edges.

They are made of stiff, hardened stainless steel blades which are flexible, but not flimsy. It can remove larger prints with ease and is very highly rated on Amazon at 4.8/5.0 stars at time of writing.

Reviews show amazing customer service and top functionality to remove prints smoothly without scraping your bed surface, the perfect tool for 3D printer users.

Use Dental Floss

Usually, a small force is sufficient to dislodge it however if that’s not possible, use a piece of dental floss.

Simply hold the dental floss between your hands and place it at the back of your print, close to the bottom, then slowly pull it towards you. Many people have had success using this method.

Heat your Print Bed

You can also reheat your print bed to about 70°C, at times heat can also make the print pop off. Using temperature changes to manipulate the print is a great method since we know these print materials react to heat.

Higher heat can soften the material enough to decrease adhesion to the print bed.

Freeze the Print Bed Along With Your Stuck Print

By spraying compressed air onto your stuck prints, you can make them easily pop off due to temperature changes also.

Placing your print and bed in the freezer also causes the plastic to contract a bit resulting in the print bed loosening its grip on the print.

This isn’t a common method because once you do the proper preparation, prints should come off fairly easily in the future.

Dissolve the Adhesive Using Alcohol

Another way of removing stuck prints from the base is to dissolve adhesive with the help of isopropyl alcohol. Put the solution near the print’s base and allow it to sit for 15 minutes.

Using a putty knife you can then easily pop the stuck print off the edges.

You can also use hot water to melt the adhesive as an alternative, but make sure it’s not boiling so it doesn’t bring the print material to its glass transition temperature, which could deform the print.

How Do You Remove a Stuck PLA Print?

To allow the easy removal of a stuck PLA print, it’s best to heat the heat bed around 70°C which results in PLA getting soft. As the adhesive will be weakened, you can remove your prints off the glass bed.

Since PLA has a low level of heat resistance, heat is going to be one of the better methods to remove a stuck PLA print.

You may also use a high quality spatula or a putty knife to help twist the print from the sides and allow it to detach completely.

Dissolving adhesive using alcohol won’t work for PLA. PLA has a lower glass temperature, and hence it is best to heat it up and remove prints.

This method has been popular among users because of its effectiveness and speed.

Check out my article on How to 3D Print PLA Successfully.

How to Remove ABS Prints on a 3D Print Bed?

Many people have trouble removing ABS prints due to reasons such as a glass print bed expanding and shrinking which creates tension on the interface layer.

If your ABS print is really stuck down to the print bed, an ideal way to detach ABS prints is by refrigerating or freezing them.

Place your print bed along with the prints in the freezer for some time. The freezing air will cause plastic to contract and this result will loosen the grip on your stuck print.

The glass surface expands and shrinks according to the ABS under specific temperature.

Allowing the glass bed to cool will shrink it, and create tension on interface layer that can then be exploited using a thin scraper.

Moreover, putting the bed along with the print into the refrigerator increases the tension to a certain point at which the bonding eventually breaks.

This results in the print popping free in several areas and even sometimes completely- easing the removal.

When your ABS print finishes, another good idea is to turn on the fan to cool it down quickly. This has the effect of quick contraction, resulting in prints popping off.

A good preventative measure to stop ABS prints sticking to the print bed is to use an ABS & acetone slurry mix on the print bed beforehand, along with some cheap tape. If the print is a smaller one, you probably won’t need the tape.

Simple glue stick is still widely used today because it works so well also. It’s easily cleaned and helps most prints stick to the bed, as well as with removal afterwards.

Check out my article on How to 3D Print ABS Successfully.

How to Remove PETG Print From Print Bed?

PETG prints stick too much to the print bed at times or the build surface, preventing easy removal and even at times come off in bits when removed.

You should opt in to using glue stick or hairspray to help remove PETG prints from the print bed. Another tip is to avoid printing directly on build surfaces like BuildTak, PEI, or even glass.

You would much rather 3D prints come off along with the adhesive, rather than with pieces of the build surface.

Here is the video of the glass print bed which got ripped off along with a finished 3D print!

Check out my article on How to 3D Print PETG Successfully.

How to Prevent 3D Prints Sticking to Print Bed Too Much

Rather than have to deal with the problem of a print stuck down too much to your print bed, you should take a preventative approach to tackle this problem.

Using the right build platform is one of the most essential tools you can implement to make 3D prints easy to remove from the print bed.

Flexible, magnetic build plates can easily be removed from the 3D printer, then ‘flexed’ to pop off 3D prints.

Several users who have the flexible build surfaces love just how easy it makes remove 3D prints. A great flexible build surface you can get from Amazon is the Creality Ultra Flexible Magnetic Build Surface.

If you have a glass build plate rather than the flexible one, many people will use materials such as blue painter’s tape, Kapton tape, or apply glue stick to the print bed (also prevents warping).

Borosilicate glass is a build surface designed to not shatter easily, as opposed to tempered glass, which is similar to car windshield glass.

You can get a good borosilicate glass bed on Amazon for a good price. The Dcreate Borosilicate Glass Print Platform is highly rated and gets the job done for several 3D printer users.

How to Remove 3D Print From Ender 3 Bed

When looking at removing 3D prints from an Ender 3 bed, there isn’t really much difference compared to the information above. You want to follow the process of having a good bed, good adhesive substance, high quality scraping tool, and good quality filament.

When a 3D print has finished on your Ender 3, you should be able to either pop it off with the flex build plate, or scrape it off with a print removal tool like a spatula or even a thin blade.

Larger prints can be harder to remove from the print bed, so you can also incorporate the water and alcohol spray mixture to try and weaken the bond between your print and the print bed.

If your 3D print is stuck down a little too hard, either heat up the bed and try remove it again, or put the build plate along with the print in the freezer to make use of temperature change to weaken the adhesion.

How to Remove a Resin 3D Print From Build Plate

You should use a thin, sharp razor or blade to insert underneath your resin 3D print, then insert a palette knife or spatula underneath this and wiggle it around. This method is one of the most common ways to remove a resin 3D print because it is so effective.

The video below shows this method working.

Other things you can try is when printing with rafts, to give it quite a high rim with a small angle, so a print removal tool can slide underneath and use a lever motion to remove the resin print.

Adding angles to the base of miniature prints makes removing them a lot easier.

Again, make sure your hand is not in the direction of the print removal tool so there aren’t any injuries to yourself.

A rotating motion under a resin 3D print on your build surface is usually enough to remove the print.

Some people have found luck after adjusting their base height, finding a sweet spot to where you get good adhesion, while not being a struggle to remove the print.

A good process that people follow is to clean the aluminum build surface with IPA (isopropyl alcohol) then use 220-grit sandpaper to sand the aluminum in small circles.

Wipe off the sticky gray film that comes off with a paper towel and continue this process until the gray film stop appearing. Clean the surface one more time with IPA, let it dry, then sand the surface until you only see dust coming off.

After this, do one final cleaning with IPA and your printing surface should give you amazing adhesion, while being able to remove the prints with ease after printing.

How Do You Clean a Magnetic Build Plate?

It’s best to clean your magnetic build plate with the help of 91% isopropyl alcohol. This will not only act as an effective disinfectant but also a good cleaner. Wipe the surface clean and dry preferably using a lint-free piece of cloth.

If you don’t prefer using alcohol, you can also clean the build plate using dishwashing soap/liquid and hot water.

For ease, you can make up this cleaning solution in some spray bottle. You can then spray it as per requirement and wipe the surface dry using a lint-free piece of cloth.

How Long Should I Let 3D Prints Cool Between Prints?

For some reason people think they should wait a certain amount of time to let their prints cool between prints, but realistically you don’t have to wait at all.

As soon as I notice my 3D print has finished, I work towards removing that print, doing a quick clean of the bed, and getting on with the next 3D print.

Prints are usually easier to remove when you catch the finishing moments of the print, but using the techniques in this article, you should easily be able to remove prints after they have cool down.

It may be a little harder when it cools down on a glass bed, depending on whether you used some substances on the print platform beforehand.

In other cases, prints can be removed easier when they have cooled down, so it really depends on your build platform, printing materials and adhesive substance. After you get into a routine, you can dial in your process to make life easier.

The contraction of the plastic after cooling down might be enough to pop off the print from the print bed without having you to move it.

Conclusion

The aforementioned hacks are quite promising when it comes to removing your stuck prints from the print bed. The tips are totally flexible and you can easily decide which one best matches your printing needs and requirements.

Tips on Removing your Finished 3D Print from the Bed

3D Insider is ad supported and earns money from clicks, commissions from sales, and other ways.

Can you imagine working on a project for several hours, painstakingly adjusting settings to get the best results, only for something to go horribly wrong when it’s almost finished? This is exactly the case when something snaps off your 3D print just when you’re removing it from the bed – a situation that is familiar to anyone who has ever dabbled into 3D printing. What can you do to prevent this from happening? Here are some of the best tips and techniques that we have tried.

Before you print

Even before the print starts, you can take a few measures to prevent your print from sticking to the bed. If you’re printing on a glass bed without any tape or adhesives, make sure to clean the surface of the bed thoroughly with some isopropyl alcohol. This removes any residual adhesives from your previous projects.

Some users also find that setting the nozzle height at a too low Z-setting for the first layer tends to make the base stick to the bed too well. As a rule of thumb, set the home position of the nozzle at a Z-setting that is about 70% to 80% of the height of the first layer. This is a pretty good middle ground that ensures that the base layer sticks to the model during printing but can still be removed when the print bed cools.

After printing

When your print has finished, and you’re satisfied with its quality, it’s worth the time to take it slow and deliberate to make sure that you get the finished print off the bed. There are two objectives to this part: remove the print without the print getting damaged, and without the bed itself getting damaged. Here are the step-by-step procedures we suggest you take:

1. Cool it down

Right after printing, the best thing you can do to make sure that the print comes off cleanly is to leave it be. Let it cool down to room temperature from several minutes up to an hour. Not only does this help the print solidify and become more durable, but it also results in a slight contraction in the filament material. This contraction should too small to have any effect on the print’s visual appearance but should help it lift off from the print bed.

In most cases, the cooling effect is enough for a print to pop right off the bed. This method typically works with PLA and with other filaments that don’t require the use of any adhesives.

2. Use a bit of force

If the print has already cooled down but does not pop right off, then you might need to apply some force to it. Depending on how big or how sturdy your print is, you’ll have to exercise some care on how much force you apply. Most prints can be pushed, pulled, or twisted to some degree. Even if this does not fully remove the print from the bed, it should result in even the slightest allowance on the base, which will help you do the next step.

3. Tap with a screwdriver

Many experienced 3D printing professionals swear by this method. Once your print bed has cooled down to room temperature, simply take a flat head screwdriver, place it near a corner of the base of the print, and give it one sharp tap on the handle. The print should come right off in most cases. If you print with some tape on your bed, this method is really useful in preserving the tape, so you won’t need to reapply it for your next print.

4. Scrape it off

If you’ve reached this point and still cannot remove your print from the bed, then it’s best to remove your print bed from the build platform. The next steps could damage the clamps that hold the print bed in place.

Use a thin, flat object and insert it on any clearance that you can find between the base of the print and the bed. For this purpose, most 3D printing professionals keep a flat-edged steel scraper on hand. You can also use a razor blade with a handle (which you can print yourself with this design). Use a combination of a sliding and lifting motions to gradually lift the bed off the print. Again, be sure not to apply too much force, as you can still easily damage the print.

Just a word of warning: this method has the potential of damaging your print bed. If you print on an untreated glass surface, doing this method repeatedly can result in the surface getting progressively more uneven. If you print on a BuildTak, you’ll probably need to replace that BuildTak surface for your next print.

5. Cool it down even more

Cooling is your friend when it comes to removing the print from the bed. If you can cool your print down even lower than room temperature, then it should contract more and self-lift off the print bed.

The easiest way to do this is to place your whole print, including the bed, inside a refrigerator. You can leave it there for an hour or so, and it should be much easier to remove after. If your print is way too big for your refrigerator, then you can also use a couple of ice packs and place it on the underside of the print bed right below the base of the print.

6. Rinse with warm water

This method mostly works if you used an adhesive on your print bed, such as glue stick, ABS slurry, or hairspray. Lukewarm water – anything below 50 °C – should work well enough to rinse off the adhesive without damaging the filament material.

7. Use alcohol

If warm water doesn’t do the trick in rinsing off the adhesive, then some isopropyl alcohol should be a foolproof alternative. This works particularly well if you used blue painters’ tape to get your print to stick onto the print bed. The downside of this method is that you’ll have to remove all the tape afterward and apply a new layer before your next print project. Nobody likes the process of applying tape to a print bed, so consider this method a last resort.

For this method, simply pour some alcohol on the edges of the print. You’ll have to use a liberal amount since you’ll need the tape to soak up the alcohol and dissolve the adhesive. The print should come right off with a little bit of prodding.

Final thoughts

It can be really frustrating to come so close to the finish line and still mess things up. In 3D printing, if you’re not careful during the print removal step, you can end up ruining your finished print or damaging your glass print bed. Either way, it’s one of the most frustrating things that can happen to you in your 3D printing career.

Fortunately, this is a problem that just about all 3D printing professionals have gone through, so there is a wealth of good advice online. By taking the necessary measures before the printing starts and by following a deliberate and thoughtful approach to print removal, it shouldn’t be much of an issue. Do you have a method that works for you that isn’t listed here? Let us know in the comments below.

Warning; 3D printers should never be left unattended. They can pose a firesafety hazard.

High-tech bed - punchboard

Technician

Subscribe author

Don't want

My second printer was UP! 2 plus. You can endlessly sing odes to him, he suited me with everything except a small area of \u200b\u200bprint. What about Afinia (Tiertime)? He has a unique bed - punchboard. It is a perforated textolite. The raft settings in the 3D printer were such that the first layer was slowly and calmly poured partially into the holes. This is the best, simplest, most reliable and fastest way to hold a part that I have seen. The part is removed simply - with a sharp knife or spatula we hook the edge and drive it under the part - it will fly off.

If the plastic remains in the holes after removing the part, it does not matter, the next time you print, the new layer will be firmly welded to the old plastic.

After buying a new printer, I wondered where to get such a platform. It was not possible to do it, but on Ali I saw options - what is in the photo is an ordinary circuit board 15x20cm, with drilling of not very good quality. Only it has 4K holes. Checked out: it's holding up well. In the next photo, the reverse side of the raft shows traces of fastening in the holes - spikes.

You can separate the model with a spatula sharpened on one side, such a 'Japanese leather knife' is best suited, searched on Ali.

Pluses:

+ quick detachment of the model

+ quick start of printing - no need to smear anything

+ no smell (except for the initial smell from the textolite) UP, circuit boards, punch boards from Aurora 3D printers, homemade punch boards.

+ no matter the type of plastic - everything sticks. Checked ABS, PLA, nylon.

Cons:

- the initial stench of the textolite (if not a branded perforated board)

- printing only with a raft

- when printing a large part, it requires a longer warm-up time so that the textolite warms up evenly.

Features:

- degreasing is mandatory after touching with hands (this is not a minus - there is nothing to touch the bed)

- the need to fine-tune all slicer profiles to the maximum thickness of the first raft layer

- separation requires a flat knife or sharpened spatula

Happy printing everyone!

Follow author

Don't want

Cleaning the 3D printer table. Tips and Tricks.

3D printing is a very unstable process, I think everyone who is at least slightly familiar with plastic filament printing technology will agree with this. Unpleasant crashes in the 3D printer can occur for various reasons, and one of the most common reasons is the detachment of the model being grown from the desktop surface. And as a rule, this happens in the middle of printing, when you are already convinced of the stability of the press and are distracted by another activity. It is precisely for this reason that ensuring good adhesion of the first layer to the platform is very important for the successful completion of 3D printing.

Today there are many ways to improve the adhesion of the first layer to the bed. A lot of articles and recommendations have been written about this, so we will not talk about them. It is worth noting one of the simplest methods - is keeping the desktop of a 3D printer clean . Regular and thorough cleaning of the platform will not only improve adhesion, but will make printed models more beautiful and smooth.

In this article we will look at the best way to clean the 3D printer table, using the example of popular coatings:

Glass top ;

PEI (polyephemeris) - rather expensive, but extremely effective, rough material;

Various adhesive tapes ;

Remember to use caution when using the methods below as spilled liquid may damage the 3D printer. We recommend removing the bed from the printer before cleaning (if possible).

PEI sheet surface cleaning

Recently, PEI sheet has become a very popular material for improving adhesion in 3D printers. It provides excellent adhesion to various materials, and when it cools down, the printed model lags behind it very easily. The sheets are very simple and not fussy to use, and most often it does not require additional application of glue or adhesive tape.

Unfortunately, in order to achieve maximum efficiency, the PEI surface also requires regular and high-quality cleaning. If PEI is touched frequently, it can develop greasy spots that reduce adhesion to the material. Rough cleaning can also damage the surface and reduce sticking. Regular cleaning and maintenance of PEI will ensure that your models do not come off.

How to clean the surface of PEI

To clean this surface, we recommend using isopropyl alcohol (Chemical pure, odorless) with a concentration of more than 70%. You can use it with a smell, but it is very caustic and unpleasant, the room will need to be ventilated.

Wait for the platform to cool, then liberally soak a dry cloth or paper towel with alcohol and wipe the surface. This will remove a significant portion of the fats and oils from the bed.

Acetone is also good at dissolving plastic residues on the surface. In the same way, liberally moisten the cloth with liquid, then gently wipe the surface of the 3D printer desktop. We strongly recommend doing this work in a well-ventilated area, as acetone is highly flammable and its vapors can penetrate the electronics of the device

If you have been using PEI sheet for quite a long time, and its resource is visually exhausted, then we recommend using fine grit sandpaper (1500+). With gentle, circular motions, sand the surface until light scratches and depressions are removed.

When should I clean?

Most manufacturers recommend cleaning the surface with isopropyl alcohol every 2 to 3 prints. After a few months of use, sand the surface and wipe thoroughly with acetone. If it is no longer possible to restore the surface by the listed methods, then replace it with a new sheet from PEI. The lifespan of such material varies depending on the brand and frequency of use of the 3D printer.

Cleaning the glass surface

Glass is another very common 3D printer desktop material. Much more durable than PEI and similar surfaces. The glass plates provide a smooth and level surface at the bottom of the model.

This surface is usually used in combination with other aids (eg glue stick or hairspray) to improve the adhesion of the first layer. Such products are especially popular on tables that are not equipped with heating. Therefore, regular cleaning of the glass is necessary to prevent adhesive or varnish from sticking.

How to clean the glass platform

The easiest way to clean a glass plate is to use a scraper or a non-metal spatula. If the table is heated, then heat it until the material remains soft, after which they should be easily removed with a scraper.

Be careful when scraping. Depending on the scraper, the blade can be very sharp, so be careful not to scratch the surface. We recommend that you put your hand on the handle of the scraper, and with the other hand press down on its middle, so that the greatest force is directed downwards.

If this does not work, try wiping the glass with warm soapy water. Although simple, this method is very effective for removing hairspray, glue, and other adhesives. Keep in mind that this method is only recommended if the 3D printer allows you to remove the platform. Spilled water can seriously damage the heating element, power supply or other electronics of the device.

Dirt can also be removed with specialized cleaning products. For example, wet alcohol wipes, window cleaner, isopropyl alcohol will also effectively wash away adhesive residue and restore the glass surface. However, do not take too strong cleaners. Such substances can severely damage the surface or even the 3D printer. In order to be sure to select a cleaning agent for your particular 3D printer, it is best to contact its manufacturer. Most often, they willingly make contact with users and willingly give advice.

When to clean the glass surface

Again, this will depend on how often you use the printer. We recommend cleaning the surface after each print to prevent buildup of glue or varnish. Such a procedure will not take much time, but the print will be more stable, and the resulting prints will have a beautiful and even surface. Once the models stop sticking (usually after a month), try washing the surface with soap and water. After about two to four months, you will have to resort to isopropyl alcohol or other specialty drugs. substances.

Cleaning adhesive tapes

Adhesive tape is another proven way to increase adhesion to the print bed. Today, this method is more common on 3D printers without the function of heating the desktop. Masking tape is the most common remedy, but so are Kapton and others.

One of the reasons for the popularity of such linens is their ease of use and relatively inexpensive cost. They are easy to stick to the surface and are available at almost any hardware store. However, there are also disadvantages: the tape quite often peels off when the printed model is removed, so it must be reapplied regularly.

How to clean?

Unfortunately masking tape is one of the most difficult to clean due to its fragility. however, we have found that gentle scraping is one of the most effective ways to clean it. With light pressure, evenly scrape off the remaining plastic thread from the surface, being careful not to tear it.

If the tape does break during cleaning, replace this area with a new strip. The main thing is not to overdo it and do not apply a thick layer, this can adversely affect the quality of the print. If the tape is full of holes and looks like Swiss cheese, then it needs to be completely replaced. Strip and scrape the old tape from the surface.
