Objet 3d printer prices

Objet30 Pro 3D Printer Review 2022

4.6

See Price

Stratasys’ ambition with the Objet30 Pro is to offer the precision and adaptability of an industrial-grade fast prototyping printer within a device with physical dimensions nearing those of an inkjet printer or office photocopying machine – a compact workhorse capable of highly detailed prints.

We’ve taken a look at the Objet30 Pro to see how well it lives up to these claims. Here’s our honest opionion.

Printing Area	294 x 192 x 148.6 mm
Layer Resolution	16 to 28 microns
Supported Filament	Rigid Opaque, Transparent, High Temperature, Simulated Polypropylene, FullCure
Printing Tech	PolyJet
Extruders	2

Table of ContentsShow

Design & Features

Touted as a desktop printer, the Objet30 Pro has all the allure of a professional grade printer with a sleek black and white color scheme that shapes a rectangular body that interestingly curves inwards vertically towards the center of the unit. The plastic casing will be familiar to anyone having used a consumer-grade ink printer making it very much at home in a design studio, home office or university alongside similar devices.

The total weight of the printer is a robust 106 kg, which apart from making transportation a hassle, ensures near unwavering stability, even when the print heads are whizzing away at the highest speed setting.

The components are all heavy duty and of the highest quality, positioned for maximized functionality but also a certain aesthetic, mechanical appeal especially when opening the hood and peering inside. The extruder mount can only be described as chunky with one of the most prominent profiles we’ve come across from a printer with this footprint.

The Objet30 Pro employs Stratasys’ patented PolyJet printing technology, which sits somewhere between typical FDM and precision SLA printers. The process resembles the inkjets found in standard printers whereby a jet places drops of liquid photopolymer material onto the build plate and then hardens or cures it by shining UV light onto it. This method is uncommon with results that offer precision unseen in printers using FDM technology.

The build area tallies up to 294 x 192 x 148.6 mm with axis resolutions of 600 dpi, 600 dpi, and 900 dpi for the X-axis, Y-axis, and Z-axis respectively. Generally speaking, the Objet30 Pro attains software to real-world print accuracy levels correct up to around 0.1mm, but this vacillates important waging on the type of model, size, the materials used, and the complexity of the design.

The Objet30 Pro has a dual extruder setup; one for printing material and the other for support material, both sitting alongside the UV light that does the curing work. The configuration allows layer resolutions ranging from 16 to 28 microns depending on whether it prints on the high quality or high-speed setting. The precision makes it one of the most detailed printers on the market regardless of cost and is a world away from the 100 microns best of most consumer models.

The material support of the Objet30 Pro is where the printer comes into its element with different liquid photopolymers endowed with a range of physical properties for all manner of situations, the only real downside being that only materials sourced from Stratasys are compatible.

Rigid Opaque in white, black, gray, and blue allow for high detailed prints that reach the quality level of end products for prototyping. Transparent VeroClear is ideal for fine-modeling used to simulate end-product transparent materials. High-Temperature RGD525 is geared towards functional testing for scenarios where high temperatures, be it air or liquid, are required. Lastly, the printer supports DurusWhite Simulated Polypropylene designed for durability and robust usage for example low tolerance hinges and snap-fit products.

The printer also uses the non-toxic gelatinous FullCure 705 support material that is not only ideal for crafting complex overhangs and the like but is removable via the DT3 Clean Station that ships with the printer.

The materials are housed in a convenient slide out draw sitting below the main printing area. Should any of the liquid photopolymer cartridges run dry, the printer has an inbuilt feature that pauses the building process to allow the user to load in a replacement, when the device picks up where it left off.

Connectivity is limited to a local network via ethernet cable, which is the standard for industrial sized printers that need a connection to multiple workstations.

As for software, the Objet30 Pro functions with Stratasys’ Objet Studio that converts any STL or SLC 3D CAD file into a sliced model that the printer can interpret and render. All controls are managed from Objet Studio with no LCD or controls on the printer itself.

Functionality ranges from automatic support creation, a range of editing tools, material selection, auto-positioning, maintenance, and the like. Compatibility is reserved for Windows systems. Overall, Objet Studio is as intuitive as it is versatile and rivals open source slicers such as Simplify3D.

Assembly

The Objet30 Pro arrives fully assembled with no installation other than fitting the liquid photopolymer cartridges into the loading tray and loading the roller bath/blade assembly into its berth below the build plate.

The package includes the Objet30 Pro waste containers, roller bath assembly, wiper blade assembly, sanding sponge, ethernet cable, nozzle ruler, loupe, tool kit (scraper, Allen key, mirror, spatula), cleaning cloths, transparency sheets, pink paper, nitrile gloves, scale, spray bottle, support cleaning fluid, model cleaning fluid, user guide notebook, USB flash drive, and a stylus pen.

Due to its complexity, the Objet30 Pro does require quite a bit of maintenance from cleaning the innards, replacing printheads, emptying waste containers, but nothing a versed lab or office technician couldn’t handle.

Printing

For a price tag nearing $20,000, we wouldn’t accept anything short of extraordinary, and the Objet30 Pro fits the bill. Prints are more or less immaculate, and the range of printing materials allow a varied selection of models. All our test prints were smooth, precise, and showed a level detail usually found in pre-assembly line models. We encountered no issues whatsoever with the printing process.

The results are suited to all manner of ends from engineering, consumer goods, low tolerance prototyping, end-user small scale manufacturing, dentistry, electronics, medical, and of course design. Virtually any industry can benefit from the quality of the prints generated by the Objet30 Pro.

Objet Studio is packed with choices and is incredibly simple to use even though it controls such a strong beast of a machine.

Support

As you’d expect from Stratasys, the support is of the highest caliber with a rich vault of guides, tutorials, and videos peppering its web site alongside the Stratasys Service Offering which includes on-site technical service and maintenance, part replacement, user training seminars, and discounts on accessories among other benefits.

Additionally, technical support teams are available throughout the world through phone, email or in person support. The printer itself ships with a standard one-year warranty.

Verdict

When reviewing leviathan grade printers with all the bells and whistle it is hard to produce a verdict other than excellent, but then again this is very much expected from the associated price tag.

The Objet30 Pro follows suits, and if you’ve got the budget to match (including maintenance and on-going production costs), then you quite simply can’t go wrong with this model.

It comes highly recommend for any professional context in need of a reliable, versatile, and precision-oriented 3D printer that won’t take up too much space yet deliver the same level of quality as pricier alternatives.

Stratasys F123 FDM 3D Printer Series

SEE CURRENT 3D PRINTING PROMOTIONS

Featuring the F170, F370, and Composite Ready FDM 3D Printers

888-559-6167

Precision 3D Printing

Now there’s a more capable, more affordable professional rapid prototyping solution for your entire office — from the leader in 3D printing. The Stratasys F123 Series combines powerful FDM technology with design-to-print GrabCAD Print software for the most versatile and intelligent solution available. Produce fast, effective prototypes for concept development, as well as highly accurate and robust parts for design validation and functional performance. Share projects between multiple users, get your new product designs to market faster and do it all without the need for dedicated expert staffing. It’s just one more way we shape what’s next.

More Speed

F123 Series 3D printers give designers, engineers, and educators access to affordable, industrial-grade 3D printing. Work faster through concept iterations and component verification. Increase productivity and reach your goals sooner with repeatable results.

Smoother Workflow

F123 3D printers are designed for supreme ease of use and a more streamlined workflow, working seamlessly with the design-to-print GrabCAD Print software. They provide the reliability and simplicity needed to refine designs. This can be done within the workspace, thanks to safety-certified printers that are the quietest on the market.

More Choices

From the affordable F170 through the versatile F370, the choices available with F123 Series printers are unmatched. Work with a wide range of materials including elastomer.* Achieve complex geometries and interlocking components with our unique soluble support material.

30 Years

For companies and schools new to 3D printing and established users alike, Stratasys F123 3D printers are the game-changing choice, with the highest levels of plug-and-print reliability and repeatable accuracy.

F-Series 3D Printers

ABS-CF10
Available with: F170 / F190CR / F370 / F370CR
Potential Applications:
– Tooling
– Jigs and fixtures
– Production and assembly
– Drill guides
ABS-CF10 Combines standard ABS material with 10% carbon fiber by weight . This makes for a 50% stiffer than standard ABS 3D printing material and 15% stronger than standard ABS 3D printing materials.
Learn More >

ABS-ESD7
Available with: F370 / F370CR / Fortus 450mc / F900
Potential Applications:
– End-use components
– Electronic products
– Industrial equipment
– Jigs & fixtures
ABS-ESD7 standard FDM thermoplastic works with soluble support technology, so support removal is hands-free and complex parts require no extra effort.
Learn More >

ABS-M30
Available with: F170 / F190CR / F370 / F370CR / F770 / Fortus 450mc / F900
Potential Applications:
– Conceptual models
– Functional prototypes
– Manufacturing tools
– Production parts
ABS-M30 FDM material enables you to prototype quickly and efficiently. This strong, familiar material lets you explore more ideas, test frequently, work iteratively – and ultimately take better products to market faster.
Learn More >

ASA
Available with: F170 / F190CR / F370 / F370CR / F770 / Fortus 450mc / F900
Potential Applications:
– Conceptual models
– Functional prototypes
– Manufacturing tools
– Production parts
Mechanical strength and UV stability make ASA a great choice for functional prototyping. Ease of use makes it a top pick for iterative design. Outstanding aesthetics and ten fade-resistant colors make it an all-around favorite, even for end-use parts.
Learn More >

Diran
Available with: F370 / F370CR
Potential Applications:
– Tooling
– Jigs & fixtures
Displaying functional properties of chemical resistance, high-impact strength, and a low coefficient of friction this material is well-suited for jigs and fixturing applications where non-marring robust tooling is desired.
Learn More >

nylon CF10
Available with: F190CR / F370CR
Potential Applications:
– Metal forming dies
– Press brakes
– End effectors
– Alignment and assembly fixtures
3D printing with carbon fiber material lets you build strong, stiff, lightweight tools and parts. FDM Nylon CF10 combines nylon and carbon fibers to achieve a high flexural strength and stiffness-to-weight ratio.
Learn More >

FDM TPU 92A
Available with: F170 / F190CR / F370 / F370CR
Potential Applications:
– Hoses, tubes, air ducts
– Protective covers & seals
– Vibration dampeners
– Prototype and end-use parts
Thermoplastic polyurethanes otherwise known as TPU’s are flexible elastomers found in products that require a soft touch, shock absorption, or a comforting grip. They are commonly co-molded or over-molded onto ABS and Polycarbonate substrates in sunglasses and phone/tablet cases.
Learn More >

pc-abs
Available with: F370 / F370CR / Fortus 450mc / F900
Potential Applications:
– Conceptual models
– Functional prototypes
– Manufacturing tools
– Production parts
For functional prototyping, tooling, and low-volume manufacturing that requires superior impact strength, FDM Technology works with PC-ABS thermoplastic. PC-ABS also exhibits excellent feature definition and surface finish.
Learn More >

PLA
Available with: F170 / F370
Potential Applications:
– Low-cost iterations
– Conceptual prototypes
Polylactic Acid otherwise known as PLA is an entry-level grade of thermoplastic material commonly associated with the ‘hobbyist’ FFF based printers because it builds well in systems that do not have closed-loop thermal control of the build chamber.
Learn More >

Request More Information about FDM Materials

GrabCAD Print

Professional 3D Printing Made Easy and Accessible

GrabCAD Print is the most complete solution for Stratasys 3D printers on the planet. The intuitive, easy-to-use software allows for simplified preparation, scheduling, monitoring, and reporting of print jobs. With the ability to read and understand CAD files natively, GrabCAD Print offers an efficient workflow that streamlines job management in shared office and model shop environments.

LEARN MORE

INSIGHT SOFTWARE

OPTIMIZE BUILD OUTPUT FOR 3D PRINTING

(ONLY AVAILABLE ON F370) Insight software prepares your CAD program’s STL output for 3D manufacturing on a Fortus machine by automatically slicing and generating support structures and material extrusion paths. For maximum control, users can manually edit parameters that determine the look, strength, and precision of parts as well as the speed and material use of the FDM process.

Optimize build orientation for maximum strength and smoothest surface finish
Customize supports for fast, easy removal and best use of materials
Program pauses into the build for any reason, such as to embed hardware or circuitry
Manipulate tool paths for advanced control over part properties

Included with Insight is Control Center. This sophisticated software application communicates with user workstations and Fortus systems, to manage jobs and monitor production status. Design, engineering, and manufacturing teams can network and share 3D manufacturing capacity to maximize efficiency and throughput.

*Compatible with GrabCAD Print for use with job reports, scheduling, and remote monitoring.

Request More Information on Insight 3D Printing Software

3D Printing Services

AWARD WINNING TECHNICAL SUPPORT

GoEngineer’s extensive technical knowledge can assist with your additive manufacturing needs. Our Award winning team is ready to help. Reach out and see why GoEngineer is the #1 reseller of SOLIDWORKS and Stratasys systems in the world!

LEARN MORE

ADDITIVE MANUFACTURING TRAINING

Learn to utilize all features and tools of Stratasys commercial 3D printers with GoEngineer additive manufacturing on-boarding training. Take advantage of our 3D printing team of experts to help launch all your 3D printing capabilities.

LEARN MORE

3D Print and Part Design

No matter your size, quantity or complexity of part(s) needed, GoEngineer can help you! Take advantage of our 3D Printing and Part Design Services to help your organization produce the best parts and prototypes available on the market.

LEARN MORE

Additional Resources

Take Advantage of GoEngineer’s Extensive Knowledge Base and Resources

Find a Solution

PROFESSIONAL TRAINING

BLOG

YouTube Channel

ONLINE STORE

FREE SOLIDWORKS Tools

WEBINARS

3D Printing Services

Stratasys Objet 30 Pro | Victoria 3D

Format: desktop
Technology: PolyJet (photopolymer)
Construction area: 294x192x148 mm
Print thickness: 28 µm
Print speed: up to 20 mm/hour
Number of materials: 7
Print modes: 1

The Objet30 Pro is the only desktop 3D printer in the world that can create models from seven different materials. The smallest details, smooth surfaces, moving parts - create incredibly realistic prototypes right in your office, bring any design and creative ideas to life in a form that is convenient for you. The Objet 30 Pro 3D printer is the perfect combination of versatility, low cost, compactness and high print quality. nine0019

High detail and print quality

With the Objet 30 Pro 3D printer, you can create physical prototypes of incredible precision and detail. The thickness of the printed layer of 28 microns guarantees you the maximum correspondence between the computer 3D model and the finished product, as well as the elaboration of even the smallest details. In addition, the surface of your products will be very smooth - they do not require additional processing.

Top 7 Materials

Print objects with a variety of media types, take advantage of each polymer, create designs with multiple materials. Objet 24 allows you to print with four opaque rigid materials and three materials with special properties:

VeroWhitePlus - White opaque hard material;
VeroBlackPlus - Black opaque hard material;
VeroBlue - opaque blue rigid material;
VeroGrey is an opaque grey, rigid material;
VeroClear is a near colorless material used to simulate transparent thermoplastic with excellent dimensional stability;
RGD535 - heat resistant material, typically used in models exposed to hot air and water; nine0004
DurusWhite is an analogue of polypropylene.

More about materials.

Large build chamber

The Objet 30 Pro 3D printer has a large build chamber measuring 300x200x150mm. It is perfect for the production of prototypes and finished products for souvenir production, consumer goods, household appliances, design layouts and much more. Want to see what the Objet 30 Pro 3D printer can do? Order a free trial print from Victoria-3D specialists by calling 8-800-500-13-07. nine0019

Universal Support Material

Support material is needed to print complex elements of your model: fine details, curves, cavities, overhangs, walls with negative angles. The Objet 30 Pro 3D printer fills the voids under such elements with a special FullCure705 Support photopolymer. It securely secures the desired parts of your product, and after printing is easily removed in the cleaning chamber. Thanks to this technology, you can quickly and accurately print even the most complex prototypes. nine0019

Easy removal of support

Objet 30 Pro is equipped with a special cleaning station for auxiliary material. This is a compact camera designed to quickly remove support material from your resin models. With ObjetWaterJet, you can quickly remove excess material, resulting in a ready-to-use prototype with a smooth surface.

Reliability and ease of use

Objet 30 Pro does not require special conditions for operation. This 3D printer is powered by a regular wall outlet. Ergonomic case design, small dimensions and reduced noise level make it easy and convenient to use in the office. Twin cartridges of 1 kg each will provide you with long battery life. By the way, replacing them is as easy as in a regular office printer. nine0019

Convenient and efficient software

The Objet 30 Pro 3D printer uses a dedicated software called Objet Studio. How does it work? You load your virtual model into a program that prepresses it. Objet Studio works with STL and SLC formats and has an intuitive interface. A set of automatic options and custom settings will allow you to quickly and efficiently prepare a file for 3D printing: place the model in the working chamber, automatically generate support, select material and calculate the consumption and time for building the model. Just click the "Print" button and wait. nine0019

Objet 30 Pro Pricing and Usage

The Objet 30 Pro 3D Printer is an easy and affordable solution for any type of prototyping. Its small size and wide possibilities of seven materials are used in various fields: medicine, advertising, design, manufacturing. Planning to buy an Objet 30 Pro 3D printer? You can learn about the price, areas of its application, configuration and delivery from the specialists of Victoria-3D by calling 8-800-500-13-07.

Where 9 is used0025

in conceptual modeling - for the production of visual samples;
in medical and pharmaceutical production;
in functional modeling;
for the production of exclusive souvenirs;
in design studios and architectural offices; nine0004
in schools, colleges and universities as part of teaching laboratories.

For example, the Swedish company Top Notch Design is actively using the Objet 30 Pro 3D printer to develop new enclosures for electrical products.

Objet 30 Pro is not limited to these areas. You can learn more about the areas and methods of use, price and configuration of the Objet 30 Pro from the specialists of Victoria-3D by calling 8-800-500-13-07.

Special requirements

Equipment dimensions

length x width x height

825 × 620 × 590 mm

The weight of the device (without packaging)

106

The device weight 901

Certificate

CE/FCC/RoHS

Warranty

Hardware warranty

1 year

PACKAGE

Only logged in customers who have purchased this product may leave a review. nine0019

Objet 3D printer for large prototyping

Objet1000 3D printer

Professional 3D printer for prototyping large format models. The size of the working chamber is 1000 x 800 x 500 mm.

The printer supports 16 µm layer thickness, as well as PolyJetMatrix technology, which allows the use of several materials at the same time in the manufacture of one model.

Large Prototypes with Impeccable Accuracy

Objet1000 is a large-format 3D printer in the Objet series for the rapid creation of industrial size models and 1:1 scale prototypes.

Featuring an extra large 1000 x 800 x 500 mm build tray, it allows designers, engineers and fabricators to quickly and accurately prototype any 3D CAD object, no matter how complex.

Complete solution for large industrial enterprises

The Objet1000 3D printer can perform a full range of tasks for checking the assembly, shape and functionality of models. The system is easy to use, can work in automatic mode for a long period of time, which is especially important for companies operating in the automotive, defense, aerospace, consumer goods, household appliances and industrial engineering industries. nine0019

What is unique about Objet1000?

Unlike other 3D printers of its size, the Objet1000 is equally well equipped to print both large and small models without sacrificing accuracy. It is possible to print rigid large-sized cases that can be drilled, assembled and twisted together, and at the same time it is possible to print small prototypes from several materials, and at the same time both prototypes are almost indistinguishable from the final product.

This is Connex, but bigger! nine0025

Based on the world's most efficient prototyping technologies, the Objet1000 combines the increased precision of inkjet 3D printing with Connex's well-known ability to build models in multiple materials. Connex Technology offers a choice of over 120 materials, including both standard materials and materials similar to ABS grade plastics. Plus, you can print up to 14 materials at once on a single model, achieving an almost exact visual resemblance to your final product. nine0019

Features

Accurate 3D printing of very large and very small precise 3D models
Very large model building area - 1000x800x500 mm
Connex Multimedia Printing Technology
Wide range of applicability: visualization, assembly and functionality checks.
Printing with industrial plastic imitation material like ABS
Extremely reliable when printing rubbery materials with large cartridges
Effective cost of ownership and fast return on investment
Ideal for automotive, aerospace, defense, consumer goods, home appliances, industrial equipment and service bureau professionals.

Specifications

Objet1000
Technology
Printable area	1000mm x 800mm 500mm
Layer thickness	16 µm (1600 dpi), 30 µm
Approval	X-axis: 600 dpi (42 µm), Y-axis: 600 dpi (42 µm)
Precision	20 -85 µm for parts up to 50 mm; up to 200 µm for full size parts
Number of print heads	8
Consumable supply	6 x 18 kg cartridges
Connection interface	Ethernet 10/100 BaseT
File formats	STL, ODL and SLC files
Power input	1. 5 kW max
Dimensions	2800 mm x 1800 mm x 1800 mm
Weight	1950 kg
Materials	FullCure®720 Model transparent, VeroWhite Opaque material, VeroBlue Opaque material, VeroBlack Opaque material, TangoBlack rubber like flexible material, TangoGray rubber like flexible material, ABS-like (RGD5160-DM). nine0161 On-the-fly digital composite materials
Print modes:	HQ (High Quality) - 16 µm, HS (High Speed) - 30 µm, DM (Digital Materials) - 30 µm

Materials

The Objet1000 3D printer combines high precision 3D printing with Connex multi-material printing technology. Connex technology offers a choice of over 100 materials, including those that mimic ABS plastic.

Objet 3d printer prices

Objet30 Pro 3D Printer Review 2022

Design & Features

Assembly

Printing

Support

Verdict

Stratasys F123 FDM 3D Printer Series

Featuring the F170, F370, and Composite Ready FDM 3D Printers

Precision 3D Printing

F-Series 3D Printers

ABS-CF10

ABS-ESD7

ABS-M30

ASA

Diran

nylon CF10

FDM TPU 92A

pc-abs

PLA

GrabCAD Print

Professional 3D Printing Made Easy and Accessible

INSIGHT SOFTWARE

OPTIMIZE BUILD OUTPUT FOR 3D PRINTING

3D Printing Services

AWARD WINNING TECHNICAL SUPPORT

ADDITIVE MANUFACTURING TRAINING

3D Print and Part Design

Additional Resources

Take Advantage of GoEngineer’s Extensive Knowledge Base and Resources

Find a Solution

PROFESSIONAL TRAINING

BLOG

YouTube Channel

ONLINE STORE

FREE SOLIDWORKS Tools

WEBINARS

3D Printing Services

Stratasys Objet 30 Pro | Victoria 3D

High detail and print quality

Top 7 Materials

Large build chamber

Universal Support Material

Easy removal of support

Reliability and ease of use

Convenient and efficient software

Objet 30 Pro Pricing and Usage

Where 9 is used0025

Equipment dimensions

Warranty

PACKAGE

Objet 3D printer for large prototyping

Objet1000 3D printer

Large Prototypes with Impeccable Accuracy

Complete solution for large industrial enterprises

What is unique about Objet1000?

This is Connex, but bigger! nine0025

Features

Materials

Learn more
