Konica minolta 3d laser scanner

Laser Scanner - 3D Scanner - 3D Scanning - Scan 3D

Laser Scanners are non-contact devices used to gather 3D digital data from a variety of objects.

A beam of light passes over the object while a camera mounted inside the scanner records the position of the laser. This 3D data is then transferred to the computer and the image is "drawn" in 3D on the screen.

	Mantis Vision's F5 Handheld 3D Video Camera for Scene Modeling Accuracy: up to 0.5mm at a range ≤ 1m Features: High-resolution and accurate 3D modeling of complete scenes in minutes Capable of modeling scenes while in motion Ruggedized for use under demanding environmental conditions Acquiring and visualizing entire 3D environments (analysis/planning, forensics, training) All acquired data is accurate in space - any measurement can be extracted accurately with no need for scale reference object
	Price Range: $60,000 to $45,000 (quantity-based)
	Mantis Vision F5 Brochure
	F5 Featured Product
	F5 Sample Data

	Basis Software Surphaser High-resolution, accurate, long-range, large-volume, portable laser scanner. Accuracy: 0.008" Features: 360° x 270° field of view, up to 800,000 points per second Available in several modifications: short, medium, and long range Ideal for medium to large objects SurphPC - external PC based custom controller that attaches to a tripod and can be remotely controlled by iPad or iPhone
	Price Range: $90,000 to $150,000
	Basis Software Surphaser Brochure
	Basis Software Surphaser 25HSX Spec Sheet
	Surphaser Featured Product
	Surphaser Sample Data

	Dimensional Imaging DI3D & DI4D Instantaneous image capture and automatic post processing to create accurate, high resolution, full-color 3D models. Accuracy: 0. 020" Features: Employs standard off-the-shelf digital still cameras 3D shape and color are captured simultaneously in a single photographic flash Resolution up to 21 mega pixels per captured image (depending on camera used) Does not use structured light projection or scanning Quick and easy to set-up and use
	Price Range: $20,000 to $140,000
	Dimensional Imaging DI3D Brochure
	Dimensional Imaging DI3D Press Release
	DI3D 3D Capture System

	Spherical Laser Scanner - DD510 Phase Shift, Hemispherical Scanner Accuracy: 0.001" Features: Built in scan controller up to 832,000 points per second 2 batteries can each provide over an hour of usage Built in cameras for automatic color data
	Price Range: $120,000 to $140,000
	DD510 Brochure

	Konica Minolta Range7 3D Digitizer Portable, compact, point-and-shoot laser scanner for industrial applications. Accuracy: 0.0015" Features: Two interchangeable lenses Multi-focus mode able to obtain more accurate data Ideal for medium to large objects
	Price (Base): $80,000
	Konica Minolta Range7 Dark Surfaces Brochure
	Konica Minolta Range7 Brochure

	Konica Minolta VIVID 3D Laser Camera Simple to use point-and-shoot laser scanner. Accuracy: 0.005" Features: Can be used to scan people Captures accurate color data Ideal for medium to large objects Other models include the 910 and the 910fw
	Price Range: $25,000 to $55,000
	Konica Minolta VIVID 9i Brochure
	Konica Minolta VIVID 910 Brochure
	Konica Minolta VIVID 910fw Brochure

	LDI SLP Laser Scanner High-accuracy, fast, flexible, portable 3D laser scanning system. Accuracy: 0.00225" Features: 3" to 12" laser line options for varying applications Dual receptor reduces scanning passes, saving time Retrofit easily to FARO Arms
	Price Range: $16,900 to $22,900
	LDI SLP Laser Scanner Brochure
	LDI SLP Probes Brochure

	FARO Laser ScanArm Small, portable scanner can be attached to any articulating arm. Accuracy: 0.002" Features: Can be used as a laser scanner or a digitizer Can digitize without having to remove either component Ideal for small to medium objects
	Price Range: $30,000 to $40,000
	FARO Laser ScanArm Brochure

	FARO Laser Scanner Photon High-resolution, fast, accurate, portable, independent laser scanner. Accuracy: 0.250" Features: Long-range / large-volume scanner Approx. 3mm linearity error at 10m Ideal for medium to large objects
	Price Range: $90,000 to $120,000
	FARO Laser Scanner Photon Brochure

	Kreon Zephyr Laser Scanner High-precision laser scanner for your CMM. Accuracy: 0.001" Features: Can be used as a laser scanner or a digitizer Ideal for very small to small objects
	Price Range: $60,000 to $75,000
	Kreon Zephyr Laser Scanner Brochure

[PDF] Introducing Konica Minolta s VIVID Line of 3D Scanners

1 Introducing Konica Minolta s VIVID Line of 3D Scanners The versatile Vivid line of 3D scanners is the product of choic. ..

Introducing Konica Minolta’s VIVID Line of 3D Scanners The versatile Vivid line of 3D scanners is the product of choice for a wide variety of applications. Each model in the line features camera-like easeof-use, portability, fast scanning time and an unequaled level of priceperformance. Konica Minolta’s Polygon Editing Tool (PET) software is included with each scanner so you can begin creating useful models as soon as you open the box. Konica Minolta is the world’s largest provider of 3D scanning solutions with customers using our products in a wide variety of industries. The list of applications increases every day. • • • • • • • • • • • •

Reverse Engineering Surface Inspection Medical – Hearing Aids, Prosthetic and Orthotic Manufacturing Dental – Orthodontic Appliances Rapid Prototyping Research Applications – FEA Modeling Input. Architectural Applications Forensic Modeling Archaeological / Anthropological Entertainment, Object & Character Modeling E-Commerce / Web Content Sculpture / Jewelry Design & Manufacture

VIVID Line – Features and Benefits Each model in the VIVID line offers outstanding benefits…

Feature Portable

VIVID 9i

VIVID 910

VIVID 910FW

Take your measurement system on the road. Weighing in at 31 lbs. The 9i provides a highly accurate mobile measurement system. The SCSI port allows data to be viewed instantly from a laptop computer.

Incorporates viewfinder and Flash RAM data storage. This gives you the freedom to take scan data without having to bring along your workstation.

At 25 lbs. The VIVID 910 FW has a viewfinder and a quick release base unit. Industry standard photographic tripods can support the scanner. The Vivid can be oriented in any position required for optimal scanning. Both desktop and tripod stands are available as optional accessories.

Fast Scan Time

Easy To Use

Versatile

Color Texture Maps

Utility Software Features

The 9i allows the user total control of scan time and data quality. Scanning times range from 2.5 seconds to 11 seconds per image.

Offers two scanning modes, enabling it to capture 76,800 data points in 0.5 seconds (Fast Mode) or 307,200 points in 2.5 seconds. (High Resolution Mode)

By collecting 75,000 data points in just 0. 3 seconds, the VIVID 910 FW scanner is ideal for human subjects, eliminating the blur caused by movement. The class I laser is completely eye-safe!

The VIVID 9i has been integrated into the most advanced Inspection and Reverse Engineering Software Packages. This allows the user to complete their task in a single application. Three interchangeable lenses and photogrametric scan alignment allow the 9i to maintain accuracy on models ranging from teeth to tractors.

The VIVID 910 scanner is the only inspection scanner with the ease of use of a digital camera. No field calibration required.

Aim and shoot. The VIVID 910 FW is factory calibrated to maintain Accuracy. (Just like the more expensive 910.) No field calibration is required for great results.

Three detachable lenses provide all the flexibility you need to scan entire cars or just the hood ornaments.

With a single lens the 910 FW can capture scan areas from 36X27 up to 910 FW120 cm. The subject can be located from 0. 6 to 2.5 meters form the scanner.

Are most accurate scanner also provides the best color data at 640 X 480 pixels per scan.

Color data is collected at 640 X 480 pixels per scan. These images can be combined for Vivid full-color 3D models.

The VIVID 910 FW utilizes a single lens system to capture texture map images with zero parallax. Full color and B/W images are supported.

All of the VIVID scanners include Konica Minolta’s own polygon editing software suite that allows the user to register (align) and merge multiple scans (both geometry and color data), fill holes, smooth surfaces and export the data to various formats. Installation and training on the software is included with the 9i & 910 packages. Konica Minolta’s new Easy Align Tool (EAT) software utilizes color targets to automatically align scan data as it is taken!

VIVID Line – Specifications by Model VIVID scanners offer the highest performance for their price range… Specification

VIVID 9i

VIVID 910

VIVID 910 FW

Range Resolution (Z-Depth)

0. 03mm at highest resolution

0.05mm at highest resolution

0.336 mm at highest resolution (600mm to object.)

Resolution (X&Y)

0.145mm at highest resolution

0.175mm at highest resolution

1.12 mm at highest resolution

Data Points per Scan

307,200

76,000

Scan Time

User Controlled Fast – 0.3 Sec. Precision – 2.5 Sec. D. R. M. – 11 Sec. 8mm, 14mm and 25mm lenses included

Dual Mode: Fast – 0.5 Sec. Precision – 2.5 Sec.

0.3 Seconds

8mm, 14.5mm and 25.5mm lenses included

8mm Wide-Angle Lens

On-Board Data Storage

Not Available

View Finder

5.7” Color LCD Display

Up to 1GB using Flash Ram and PCMCIA adapter (Optional) 5.7” Color LCD Display

Distance to Object

0.5m to 2.5m

0.6m to 2.5m

Field of View (FOV per scan)

93mm X 69mm up to 1750mm X 1121mm

111mm X 84mm up to 1300mm X 1100mm

Color Resolution (Per Scan) Safety

640 X 480 Pixels

360mm X 270mm up to 900mmX1200m m 640 X 480 Pixels

Class 1 Laser (FDA) Eye Safe.

Power

100 – 240 VAC 50 – 60 Hz Auto Switching

Reliability

With over 1500 units in use world-wide, the VIVID line of 3D scanners has been proven the most reliable in the industry. Produced in compliance with ISO 9001 quality standards.

Optics

5.7” Color LCD Display

Class 1 Laser (FDA) Eye Safe. 100 – 240 VAC 50 – 60 Hz Auto Switching

VIVID Line – Standard Accessories • • • • • • • • •

One-Year Warranty All Models o Protect your investment Interchangeable Lenses (wide angle, mid, telephoto) Vivid 9i & 910 o Increased Versatility Instruction Manuals All Models 6-Foot SCSI Cable (50 to 50 Pin) All Models Konica Minolta’s Polygon Editing Tool Utility Software All Models o Capture, Create and Export your Models 6-Foot Power Cord All Models White Balance Filter All Models o For Improved Color Fidelity VIVID Tripod w/ Pan/Tilt Head Vivid 9i & 910 Field Calibration System Vivid 9i o Maintain Highest Accuracy

VIVID Line – Optional Accessories • Photogrammetric Scan Alignment System (9i Only) o Maintain Accuracy on Large Parts • Rotary Stage / Turntable o Automate the scanning process • VIVID Tripod w/ Pan/Tilt Head o Flexible and portable • Tripod Dolly w/ locking casters o Most useful for large object scanning • VIVID Memory Card (910 only) o Take scan data without a PC • Travel Case w/ Wheels o Safe transport for mobile users • ENSIGN Frame Set o Automated inspection fixture

Photogrametric Scan Alignment System

Ensign – Automated Inspection Fixture.

VIVID Line – The Total Solution Konica Minolta has cultivated many partnerships in the scanning software industry in order to provide our customers with affordable, high-quality solutions. Many of the most popular applications for inspection, reverse engineering and content development will directly import the native scan file format of the Vivid scanners. Several applications have developed direct interfaces to the scanners, enabling the user to remain in a single application to complete a given task. This type of integration vastly improves the ease-of-use of the system and reduces the learning curve for the novice user. For applications that will not directly import the VIVID data, the Polygon Editing Tool software will export a number of industry standard formats. These include: *.STL, *.HRC, *.OBJ, *.DXF, ASCII, VRML 2.0, MGF Both geometry data and texture maps can be exported to file formats that support them. IGES surfaces and other CAD data formats can be obtained by utilizing a reverse engineering application.

Software such as Innovmetric’s Polyworks combine with the VIVID 9i for a powerful inspection solution.

VIVID Line – Pricing The price of a complete Vivid system will depend on the specific accessories and software required for your application. Approximate pricing for several system configurations are shown below. Please contact your Konica Minolta sales representative for a formal quotation.

System Description

List Price

VIVID 910 FW System – Basic Package • VIVD 910 FW Digitizer • Konica Minolta’s Polygon Editing Tool Software • 6-Foot SCSI Cable (M 50 to M 50 Pin)

$23,800

VIVID 910 FW System “Crystal–Faces” Package • VIVID 910 FW Digitizer • Konica Minolta’s Crystal Studio Software • Cabling and Tripod w/ Pan Tilt Head

$29,995

VIVID 910 System – Basic Package • Vivid 910 Digitizer

$44,000

VIVID 910 System – Reverse Engineering Pkg. $65,800 • VIVID 910 Digitizer • Assembled Rotary Stage • Tripod w/ Pan/Tilt Head and Cabling • Advanced Polygon Modeling Package* • Advanced scan to IGES surfaces (NURBS) modeling* VIVID 9i System – R. E. and Inspection Pkg. $75,260 • VIVID 9i Digitizer • Tripod w/ Pan/Tilt Head and Cabling • Advanced Polygon Modeling Package* • Advanced scan to IGES surfaces (NURBS) modeling* • Scan to CAD (or Scan to Poly) Inspection software* VIVID Photogrammetric Scan Alignment Pkg. • Camera, Scale Bars, Targets and Software

$27,500

Although the list pricing for the VIVID scanners is the lowest you will find for laser scanners of this quality, if yours’ is a teaching institution, you may be eligible for Konica Minolta's educational discount. Please ask your Konica Minolta representative for details. * Price depends on software package included. Please consult your Konica Minolta representative regarding the software package best suited to your application.

Konica Minolta 3D Scanner - frwiki.wiki

VI-910
VI-9i

These 3D scanners are designed for use with the Polygon Editing Tool software.

Summary

1 presentation
2 Technical data
3 See also
- 3. 1 External links

Presentation

Since 1997, Konica Minolta has been selling non-contact 3D scanners of the VI series, which allow you to quickly measure 3D shapes with unparalleled ease of use, equivalent to a digital camera.

The 3D VI Scanner is a tool that scans an object using a laser line and sends the resulting 3D data to a computer to back up, manage or copy a digital object.

Data sheet

Table header
Type	Scanner VI-910	VI-9i Scanner

Measurement method	Laser triangulation	Laser triangulation
Objective type	Focal length TELE - f=25, MIDDLE f=8, WIDE f=14	Focal length TELE - f=25, MIDDLE f=8, WIDE f=14
Working distance	0.5 to 2.5 m	0. 6 to 1.0 m (standard mode) 0.5 to 2.5 m (extended mode)
Laser class	Class 1 (FDA) Class 2 (IEC60825-1)	Class 1 (FDA) Class 2 (IEC60825-1)
Min. / Max. Scan area X * Y * Z in mm	1118340/1196897750	936926/149511211750
Accuracy (X; Y; Z) in mm at minimum distance	+/- 0.22; +/- 0.16; +/- 0.1	+/- 0.05" XYZ
Repeatability in mm at minimum distance	+/- 0.008	+/- 0.008
Time of purchase	in fast mode: 0.3 s; in normal mode: 2.5 s; 0.5s for texture	2.5 s; 0.5s for texture
Number of points	3D data / color data: 307,200 dots	3D data / color data: 307,200 dots
Export format	Konica Minolta 3D and STL, DXF, OBJ, ASCII, VRML formats	Konica Minolta 3D and STL, DXF, OBJ, ASCII, VRML formats
Scanner dimensions (w, h, d) in mm	213413271	221412282
Weight	11 kg	15 kg
Temperature, hygrometry and brightness of use	10°C to 40°C, 65% RH or less, non-condensing, 500 lux maximum	10°C to 40°C, 65% RH or less, non-condensing, 500 lux maximum
Storage temperature and humidity	0°C to 40°C, max. 85% relative humidity non-condensing	0°C to 40°C, max. 85% relative humidity non-condensing
