Infrared 3d scanner

POP 2 High-Precision 3D Scanner | Handheld 3D scanner | 3d portable scanner

TIPS:
1. EU, UK, CA, & AU shipped locally takes 3-5 working days. Other countries, sent from CN takes 5-10 working days.
2. Responsive customer service: Live chat, phone calls, and email.
3. Free shipping for most countries.

POP 2 3D Scanner（Infrared Light丨Precision 0.05mm）

Sale price$868.28

POP 2 3D Scanner（Infrared Light丨Precision 0.05mm）

Sale price$868.28

Perfect

It is awesome! I tried it on a few objects and on a person. I have nothing to complain! It does it's job better than I expected. The softwares (for desktop and the mobile app for iOS) are very helpful and intuitive.

Awesome budget scanner, but with huge features!

I've started using it and wow!
Super easy to use, super nice resolution. ..
I recommend to anyone that is in the market looking for a 3D scanner at this pricepoint.
A huge thumbs up also is the hability to use any OS that you're up to, even on Mobile!

Best scanner I have owned

I would definitely recommend this to other people for the price point as well as the features and capability of the scanner are endless. The fact that you can use a stationary or portable is amazing

Great

For a very long time I was looking for an affordable solution for scanning complex objects and reversing engineering of medium and large sizes. Pop 2 handles these tasks well.
An excellent solution for home scanning or production where you need to scan medium and large objects. Everything is convenient and understandable. The programs work well.
Worked with a dental scanner. The quality of the scans is certainly higher, but the size of the scanned objects is very limited (no more than the size of the jaw), and it costs 5 times more than Pop 2.
I like Pop 2, a good scanner for an adequate price. Now I really want Revopoint mini.

Great

123

Take a look >

What's in the box?

POP 2 Standard Package
POP 2 Premium Package

POP 2 3D Scanner

Tripod

Phone Holder

2-in-1 Mobile Cable

Calibration Board

USB Cable (Type C)

USB Cable (Type A)

Gift( Sample Statue, Glue Tack, Black Sheet and Markers)

POP 2 3D Scanner

Tripod

Phone Holder

2-in-1 Mobile Cable

Calibration Board

USB Cable (Type C)

USB Cable (Type A)

Carrying Case

Power Bank

Mini Turntable

Extended Plate

Reusable Sticky Pad

Gift( Sample Statue, Glue Tack, Black Sheet and Markers)

Infrared 3D scanner: visualizing the hidden

If you look at the small range of visible light compared to the entire electromagnetic spectrum, you can already guess how much remains invisible to the human eye.

It has already been recognized for a long time that valuable information is contained in this spectral range, which is not accessible to us. That ́s why numerous imaging techniques have been developed that work with light in the infrared (IR) range (with a wavelength of 780 nm to 1 mm).

For many examinations of people or objects with infrared light, it is useful to create a 3D model in addition to 2D images in order to get holistic information. Consequently, the possible applications for an infrared 3D scanner are very diverse.

Since this light, unlike short-wave radiation such as ultraviolet radiation, does not have an ionizing effect and therefore does not cause any changes to the genetic material as a long-term consequence, it is well suited for the repeated examination of living cells.

Numerous potential applications for infrared 3D scanners in the health care sector

Since blood, in particular the oxygen-rich hemoglobin found in it, absorbs infrared light very well, fine vessels can be observed at these wavelengths. When the patient is illuminated in suitable IR ranges, fine veins become visible in the recorded reflections, which, together with a 3D scan of the patient, can be documented over the long term and therefore used for future comparisons. Due to the demographic development of the population and the resulting increase in vascular diseases, new treatment and examination methods are particularly relevant in this field.

In pharmaceutical quality testing, various infrared spectroscopy methods are used to check the surface coating of pills and ensure uniform distribution of active ingredients. Here, additional documentation in 3D can also be an advantage, since two-dimensional images always represent only one side of the pill.

Insightful investigations of plants

But it is not only the health care sector that can benefit from spectral examinations in the IR range. Since chlorophyll strongly reflects infrared light, this examination method is ideally suited for plant analysis within the development and use of new pesticides and fungicides.

In the context of precision farming, it is possible to investigate exactly on which parts of the plant diseases appear first, since affected areas have less chlorophyll than healthy parts of the plant – in this way, pests can be targeted immediately.

In this way, infrared examinations can help to make the use of these potentially unhealthy substances more selective and eco-friendly. Currently, in-depth research is being carried out in this area. A botspot employee was also involved in the development of plant cameras.

Highly efficient and sustainable management of land areas will be absolutely essential in the future in order to ensure the nutrition of the world’s growing population – intensive research is the basis for this.

Additional information from cultural artifacts using infrared 3D scanners

Infrared radiation in the range of 780 nm to 3.5 μm is used to visualize underdrawings in paintings: the canvas is illuminated with this spectrum and the reflections are captured by a photographic sensor that is blocked for all wavelengths below this spectrum.

Since underdrawings have different color pigments than the actual paint, they also have different reflective characteristics and become visible that way. With a 3D scanner, also vases and other art objects can be examined for underpaintings and digitized as a 3D model.

Customized solutions from botspot for examinations in the infrared spectral range

This is not more than a small overview of the application areas where important information can be extracted from the infrared range of a texture.

Due to this variety of possible applications, it is important for our research and development work to operate with other wavelengths in addition to the visible light to make the spectral fingerprint of objects and persons even more examinable.

With a custom scan solution from botspot, it is possible to capture high-precision 3D data of persons and objects in visible light as well as additionally in the infrared frequency range.

In this hybrid scan system, first an image is taken that captures the object in visible light for a true-to-scale 3D model with texture in true colors. In the subsequent second exposure within just one initiated scan, special spotlights irradiate the object with IR radiation in selected bandwidths and the reflections are detected by modified camera sensors.

‍

Hybrid Infrared Handheld Color 3D Scanner Einscan H

Get a quote

Please fill out this form to receive a free quote within 24 hours (during working days).

AfghanistanALAND ISLANDSAlbaniaAlgeriaAmerican SamoaAndorraAngolaAnguillaAntigua And BarbudaArgentinaArmeniaArubaAustraliaAustriaAzerbaijanBahamasBahrainBangladeshBarbadosBelarusBelgiumBelizeBeninBermudaBhutanBolivia, Plurinational State OfBosnia And HerzegovinaBotswanaBouvet IslandBrazilBritish Indian Ocean TerritoryBrunei DarussalamBulgariaBurkina FasoBurundiCambodiaCameroonCanadaCape VerdeCayman IslandsCentral African RepublicChadChileChinaChristmas IslandCocos (Keeling) IslandsColombiaComorosCongoCook IslandsCosta RicaC?te D'IvoireCroatiaCubaCyprusCzech RepublicDenmarkDjiboutiDominicaDominican RepublicEcuadorEgyptEl SalvadorEquatorial GuineaEritreaEstoniaEthiopiaFalkland Islands (Malvinas)Faroe IslandsFijiFinlandFranceFrench GuianaFrench PolynesiaFrench Southern TerritoriesGabonGambiaGeorgiaGermanyGhanaGibraltarGreeceGreenlandGrenadaGuadeloupeGuamGuatemalaGuernseyGuineaGuinea-BissauGuyanaHaitiHeard Island And Mcdonald IslandsHoly See (Vatican City State)HondurasHong KongHungaryIcel andIndiaIndonesiaIran, Islamic Republic OfIraqIrelandIsle Of ManIsraelItalyJamaicaJapanJordanKazakhstanKenyaKiribatiKorea, Republic OfKosovoKuwaitKyrgyzstanLao People'S Democratic RepublicLatviaLebanonLesothoLiberiaLibyan Arab JamahiriyaLiechtensteinLithuaniaLuxembourgMacaoMadagascarMalawiMalaysiaMaldivesMaliMaltaMarshall IslandsMartiniqueMauritaniaMauritiusMayotteMexicoMicronesia, Federated States OfMoldova, Republic OfMonacoMongoliaMontenegroMontserratMoroccoMozambiqueMyanmarNamibiaNauruNepalNetherlandsNetherlands AntillesNew CaledoniaNew ZealandNicaraguaNigerNigeriaNiueNorfolk IslandNorthern Mariana IslandsNorwayNORTH KOREAOmanPakistanPalauPalestinian Territory, OccupiedPanamaPapua New GuineaParaguayPeruPhilippinesPitcairnPolandPortugalPuerto RicoQatarReunionRomaniaRussian FederationRwandaSaint BarthélemySaint HelenaSaint Kitts And NevisSaint LuciaSaint MartinSaint Pierre And MiquelonSaint Vincent And The GrenadinesSamoaSan MarinoSao Tome And PrincipeSaudi ArabiaSenegalSerbiaSeychel lesSierra LeoneSingaporeSlovakiaSloveniaSolomon IslandsSomaliaSouth AfricaSpainSri LankaSudanSurinameSvalbard And Jan MayenSwazilandSwedenSwitzerlandSyrian Arab RepublicTaiwan, Province Of ChinaTajikistanTanzania, United Republic OftestThailandTimor-LesteTogoTokelauTongaTrinidad And TobagoTunisiaTurkeyTurkmenistanTurks And Caicos IslandsTuvaluUgandaUkraineUnited Arab EmiratesUnited KingdomUnited StatesUruguayUzbekistanVanuatuVenezuela, Bolivarian Republic OfViet NamVirgin Islands, BritishVirgin Islands, U. S.Wallis And FutunaWestern SaharaYemenZambiaZimbabweMACEDONIASOUTH GEORGIADemocratic Republic of the Congo

* Which product are you interested in？* Desktop 3d scanner* Hybrid light source handheld 3d scanner* Multifunctional handheld 3d scanner* Multiple scan range 3d scanner* Other Products and Service

submit...

Handheld 3D scanner EinScan H

Handheld Color 3D Scanner - Hybrid and Infrared LED Light

With more than a decade of technical accumulation in 3D digitizing field, Shining 3D now releases its newly developed handheld full color 3D scanner, EinScan H. Based on hybrid LED light technology and invisible infrared light, EinScan H makes scanning a person without strong light more comfortable. With a built-in color camera and large field of view, EinScan H delivers high quality 3d data with full color ready to use in minutes.

Watch video here

Features

Hybrid Infrared and Patterned Light

Hybrid Light Source technology integrates LED patterned light and invisible infrared light into one device, and adding advanced smart presets in various scanning modes, enables 3D scanning in a wide range of applications and promotes popularization portable 3D scanning technology.

The era of hair scanning

Invisible infrared light source provides a reliable solution to black and dark color, making hair scanning possible.

Invisible light 3D scanning experience

Face Scan mode uses invisible infrared light to make scanning people safer and more comfortable.

Fine details

Impressively high resolution as low as 0.25 mm, EinScan H captures the full geometry of objects such as art, furniture with fine details. High accuracy of scanned data up to 0.05 mm and volumetric accuracy of 0.1 mm/m increase the accuracy of 3D modeling in dense point clouds or polygonal meshes.

Fast scanning

Scanning speed up to 1,200,000 dots/s and a large FOV scan of 420*440 mm enable fast 3d scanning of large objects.

Full color reproduction

With a built-in color camera, it supports full color texture capture and texture tracking.

Portability and ease of use

The software is intuitive and user friendly. Easy to operate for professional users as well as novices. Easy to own, easy to use.

Weight 703g

Specifications

Scan Mode	White light mode	IR mode
Light source	White light, visible	Infrared light, invisible
Security	Eye safe	Class I (eye safe)
Scan Accuracy	up to 0.05mm	up to 0.6mm
Volumetric Accuracy*	0.05+0.1mm/m	/
Scan Speed	1,200,000 points/s, 20 frame	720,000 points/s, 20 frame
Camera Frame Rate	55fps
Alignment Method	Geometry, marker, texture, hybrid	Geometry
Working Distance	470mm
Depth of Field	200-700mm	200-1500mm
Max. FOV	420*440mm	780*900mm
Distance between points	0.25-3mm	0.5-3mm
Integrated Color Camera	Yes
Texture Scan	Yes
Connection Port	USB 3.0
File Format	OBJ;STL;ASC;PLY;P3;3MF
Dimensions	108110237mm
Weight	703g
Certificates	CE，FCC，ROHS，WEEE，KC
System requirements	OS: Win10，64bit；Video card: NVIDIA GTX1080 or above；Video memory: ≥4GB；Processor: I7-8700；Memory: ≥32GB

*Volume accuracy refers to the ratio between the accuracy of 3D data and the size of the object; accuracy is reduced by 0.

Technology	Dual camera infrared structured light	Light Source	Class 1 Infrared Laser
Dimensions	154. 6 x 38.2x 25.6 (mm)	Single-frame Precision	0.05mm
Alignment	Feature, Marker	Printable Data Output	3D printing ready models
Point Distance	0.15 mm	Output Format	PLY, OBJ, STL
Compatible with	Windows 8\10\11 (64-bit), Android, iOS, MAC	Single Capture Range	210mm x 130mm
Textured Scan	Yes	Wi-Fi	2. 4GHz
Working Distance	150 ~ 400 mm	Special Object Scanning	For the transparent and highly reflective objects, please use scanning spray.
Connector Type	Micro USB	Minimum Scan Volume	20×20×20 (mm)
Scanning Environment	Indoor and outdoor, but not in direct sunlight.	Scan Speed	Up to 10 fps
Scanner Weight	195g
Notes	Note: Accuracy was tested in a standard lab environment. Results might vary depending on the operating environment. Windows 7 is not supported
