Handy scanner 3d

Design, Rapid Prototyping

Manufacturing

After Sales Support & Servicing

Scan with Confidence

The new HandySCAN 3D performs 25 times faster- the fastest 3D scanner on the market. The device also carries the highest measurement rate among all laser scanners at 480,000 measures per second, allowing it to be 40% more accurate than previous generations.

Improved Ergonomics

The new HandySCAN 3D performs 25 times faster- the fastest 3D scanner on the market. The device also carries the highest measurement rate among all laser scanners at 480,000 measures per second, allowing it to be 40% more accurate than previous generations.

Two Variants

The HandySCAN 3D scanners feature two distinct models to suit the needs of your organization. The HandySCAN 300 is the most efficient device to reverse engineering and/or design, achieve quick and accurate scans from a reliable tool.

The HandySCAN 700 features increased accuracy and resolution and is the most versatile 3D scanner on the market for inspection and reverse engineering.

Speed, Accuracy and Comfort All in One Reliable Tool

VXelements: 3D Software Platform

The HandySCAN 3D scanners come with VXelements, a fully integrated 3D software platform that powers our entire fleet of 3D scanning and measurement technologies. The user-friendly software thrives off a sleek and simple working platform. gathering essential elements, including real-time visualization, it creates the best scanning experience.

Upon completing the scan, an optimized file is automatically created, significantly reducing the time involved in your inspection/design process.

VXscan: Scan Software Module

VXscan is entirely dedicated to the acquisition and optimization of 3D scanning data. It delivers high performance for that specific task, yet it is simple and user-friendly enough to suit any user’s experience level.

• User-friendly interface: VXelements was designed to simplify the whole scanning process to its essential core, through a powerful and simple process.
• Surface optimization algorithm: avoids the creation of multiple scan layers and ensures a more accurate mesh without any post-treatment;
• Direct mesh output: an optimized mesh can be exported in all standard formats, right as you complete acquisition. No complicated alignment or point cloud processing needed;
• No limitation to the scan resolution: you simply need to input a resolution value, independent from the size of the scanned object. Resolution can be changed at any time before/after the scan;
• Real-time visualization: the user can view the 3D surface as the object is being scanned;
• Scan results enhancement: hole filling, smart decimation, boundary filters, etc.
• Compatible Software: 3D Systems (Geomagic), InnovMetric (Polyworks), Dassault Systèmes (CATIA V5, SolidWorks), PTC (ProEngineer), Metrolog X4 and V5, Simens (NX and Solid Edge), Autodesk (Inventor, Alias, 3ds Max, Maya, Softimage)

VXinspect

3D Inspection Software Designed for Article Inspection and Quality Control

Learn More

VXmodel

Seamlessly integrate 3D scan data into your CAD & 3D printing process

Learn More

VXremote

Remote Access Software Application for 3D Measurements in the Field

Learn More

Industries

The versatility of HandySCAN 3D scanners mean that they can be applied to applications across various industries regardless of environments. Explore some of the advantages in your industry or call us to speak with one of our industry experts.

	HandySCAN 300	HandySCAN 700
Weight	0.85 kg [1.9 lbs]	0.85 kg [1.9 lbs]	Weight 0.85 kg [1.9 lbs]
Dimensions	12.2 x 7.7 x 29.4 cm [4.8 x 3.0 x 11.6 in]	12.2 x 7.7 x 29.4 cm [4.8 x 3.0 x 11.6 in]	Dimensions 12.2 x 7.7 x 29.4 cm [4.8 x 3.0 x 11.6 in]
Measurement Rate	205,000 measures/s	480,000 measures/s	Measurement Rate 205,000 measures/s 480,000 measures/s
Scanning Area	225 x 250 mm [8.8 x 10 in]	275 x 250 mm [10.8 x 10 in]	Scanning Area 225 x 250 mm [8.8 x 10 in] 275 x 250 mm [10.8 x 10 in]
Light Source	3 Laser Crosses	7 Laser Crosses (+1 extra line)	Light Source 3 Laser Crosses 7 Laser Crosses (+1 extra line)
Laser Class	II (eye-safe)	II (eye-safe)	Laser Class II (eye-safe)
Resolution	0. 10 mm [0.004 in]	0.05 mm [0.002 in]	Resolution 0.10 mm [0.004 in] 0.05 mm [0.002 in]
Volumetric Accuracy	0.020 mm + 0.025 mm/m [0.0008 in. + 0.0003 in./ft]	0.020 mm + 0.025 mm/m [0.0008 in. + 0.0003 in./ft]	Volumetric Accuracy 0.020 mm + 0.025 mm/m [0.0008 in. + 0.0003 in./ft]
Stand-off Distance	300 m [12 in]	300 m [12 in]	Stand-off Distance 300 m [12 in]
Depth of Field	250 mm [10 in]	250 mm [10 in]	Depth of Field 250 mm [10 in]

Scanform - professional handheld 3D scanners

Our clients

3

Well Technology Company

Manufacture of industrial ventilation equipment

Well Technology

FENDERIST — Vladivostok

Development and production of tuning components

fenderist. com

BoatService – Croatia

Boatservice Group - A network of yacht service workshops operating in Croatia, Slovenia and Montenegro since 2008. Perform almost…

boatservice.eu

Bratuhin Customs - Izhevsk

Production of individual motorcycles and components: 3d scanning, reverse engineering, production and installation of side trailers…

bratukhincustom.com

Physics Racing - St. Petersburg

Quality construction, repair and maintenance of sports cars. Professional approach to work, preparation for exhibitions and competitions…

fizikaracing.vsite.biz

RMM manufacturing — Novosibirsk

Manufacture of downpipes and exhaust systems for Mercedes, BMW, Porsche, Audi, Aston Martin, McLaren, etc.

CAD Engineer

Affordable 3D scanning and CAD design services in Florida, US

facebook.com

KMZ - St. Petersburg

Kingisepp Engineering Plant - a domestic manufacturer of diesel, heat exchange and deck equipment

kmz1.ru

DirTire - Vladivostok

Manufacturing, engine swaps, design, CNC laser cutting, welding, custom work, 3d scanning, 3d printing.

4

"Sport brake systems" - JBT

CTC (Sports Brake Systems) is an official dealer of high-tech brake systems JBT, providing significant . ..

View photo report

4

LLC "TAURUS" - Istra

LLC "Taurus" provides services for clearing land from unwanted trees and shrubs using mulchers.

See photo report

mulcher-taurus.ru

3

Steffi Group - Rostov-on-Don

The company specializes in laser cutting, marking, CNC metal processing, CNC tube and bar bending. 3D modeling, scanning…

View photo report

cnc-services.ru

14

SWAP POINT

The company specializes in engine swaps and car modifications. As the guys say about themselves: “We swap everything that moves, and what ..

See photo report

youtube.com/Swap

5

SVS-Sochi

Russian company for the development and production of tuning components for cars of any class with its own unique design.

See photo report

5

Magic Print

3D printing, 3D scanning, design and modeling in Chechnya

View photo report

6

3D-Cartel — St. Petersburg

3D-Cartel offer a range of services for: 3D scanning, 3D printing, Modeling, Reverse engineering, wax casting and aluminum casting

View photo report

6

Box 3D - Moscow

Specializes in 3D printing: large-scale objects, engineering composites, 3D scanning, modeling, design

See photo report

box3d. ru

4

Auto Concept Studio – Car Audio and Tuning Studio – Yekaterinburg

Installation and adjustment of sound, production of podiums, etc.

See photo report

AUTOCS.ru

VKontakte

technologies, methods and principles of 3D scanners

04/16/2021

• • What is 3D scan and why it is used
  • How 3D scanner
  work as 3D scanner
  • 3D scanning technologies
  • 3D scanning methods
    • Contact 3D scanners
    • Non-contact 3D scanners
  • Types of 3D scanners by usage principle
  • Advantages and disadvantages of 3D scanners
  • What to consider when choosing a 3D scanner
  • Applications

Currently, few people are not familiar with such a concept as 3D printing. Many companies are using modern 3D printers with might and main, recreating layouts of various shapes and sizes with their help. There are also those that recreate whole objects - not only small ones (for example, phone cases, souvenirs, sneakers), but also large ones (houses, engine parts, etc.). But all this would not be possible without 3D scanners. It is they who allow you to accurately copy almost anything - from huge buildings and structures to humans, animals, small objects and much more.

What is 3D scanning and what is it used for

Three-dimensional scanning is a technology that appeared in the 60s of the 20th century. It was created in order to transfer the physical parameters of the object into a digital format in the form of a three-dimensional model. The need for this naturally arose when people around the world increasingly began to use computers both in everyday life and in production.

The first samples of 3D scanners were quite simple and did not have wide functionality. Gradually, they became more complex and improved, making it possible to achieve an ever clearer image of the object. This has become especially relevant with the advent of lasers.

3D scanners allow you to transfer object data into digital format

3D scanning has opened up new opportunities in various areas of human activity - from the automotive industry and the military industry to design, medicine and cinema.

How a 3D scanner works

A 3D scanner is a device that examines an object by digitizing it using sensors and using the information received to create a three-dimensional model. In fact, a 3D scanner creates a digital copy of a physical object of any configuration and complexity. In this, it fundamentally differs from its predecessors - conventional scanners that can only read information from documents and photos.

The scanning process itself can take place in different ways - depending on the type of 3D device and the technology used, as well as on what object you want to process with it - moving or static.

3D Scanning Technologies

There are 2 main types of 3D scanners - laser and optical. Their fundamental difference lies in how and with the help of what the “removal” of data takes place. Let's take a closer look at both.

Laser 3D scanning, as the name implies, uses a laser and can be carried out both at short and long distances from the object.

Laser scanner

For the most part, 3D laser scanners work on the principle of triangulation, when the camera finds a beam on the surface of an object and measures the distance to it, after which a cloud of points is created, each of which has its own coordinates in space, and a 3D model is built. Their "advantages" are affordable price and ease of use combined with high scanning accuracy. Of the "minuses" - there are restrictions on the remoteness and size of the object.

Another type of laser scanner works by measuring the response time of a beam from the surface of an object - the so-called laser range finder. They are widely used where it is necessary to create 3D models of various buildings and structures. It is not advisable to use them at short distances, since in such cases the response time is very short and the accuracy of the data is reduced. Otherwise, this type of scanner is characterized by high scanning speed and the ability to read all the details.

The disadvantage of laser scanners is the impossibility of their use on moving objects. Then optical 3D scanners come to the rescue, which shoot with one or more cameras from different angles an object illuminated by a special projector. Based on the received image, a three-dimensional image is built.

Optical scanner

A "contraindication" for the use of this technology are reflective and translucent surfaces - shiny, mirror or transparent. But when scanning a person, they are simply irreplaceable.

3D scanning methods

Any object can be digitized both by contact and non-contact methods. In the first case, active interaction with the subject is necessary, in the second, accordingly, no. Both of these methods have their advantages and disadvantages.

Contact 3D scanners

They have a mechanical probe with a special sensor that measures parameters and transmits the collected information to the device. To do this, the object under study is placed on a special surface and fixed (if necessary). Such tight physical contact makes it possible to determine and then build a 3D image as accurately as possible, however, there is a small risk of damage to the prototype.

Non-contact 3D scanners

This category includes all devices capable of scanning at a distance. This is especially true for objects located in hard-to-reach places.

Non-contact 3D scanner

A stream of radiation (it can be ultrasound, light, X-rays or a laser) is directed to the object and reflected from it, it is recognized by the 3D scanner. They are similar in principle to a video camera and may require the use of additional devices for better lighting.

Non-contact 3D scanners come in 2 types:

• Active - work with a laser beam or structured light directed at an object, which, when reflected, provide information about the location of the object in the form of coordinates.

• Passive - use time-of-flight rangefinders that read the time and distance that the laser beam travels to the object, and so - for each point in space, which ultimately allows you to accurately recreate its three-dimensional image.

Desktop 3D scanners are very popular and widespread, since they are mostly simple and safe to use, do not require any special technical skills and are quite cheap. The EinScan-SE 3D scanner is one such example. It can be used both at home and in the office. It has access to the API of many popular 3D printers, which makes it possible to immediately print the created three-dimensional model.

Add to compare

Product added to compare Go

Add to compare

Product added to compare Go

Add to compare

Product added to compare Go

Add to compare

Product added to compare Go

Types of 3D scanners according to the principle of use

There is also a variety of species here. Let's highlight the main ones:

• Manual: The are handy and simple models that are easy to use as they are quite compact and do not require special skills. True, their technical capabilities may be somewhat limited.

• Portable: The is mainly used for field work and is convenient to take with you.

• Desktop: have extended functionality and are used to create high-quality 3D models. Most often used in offices.

• Stationary: are used, as a rule, in production, various enterprises, as they can scan a large number of objects of the same type at once. Mounted on special turntables.

Handheld 3D Scanner Calibry

Such a choice of products allows you to select the right model for a specific task. In some cases, scanners independently measure objects, in others - with the help of a person who sequentially moves the device until all the necessary information is collected.

Such options for hand-held 3D scanners as Calibry are in high demand among buyers. Despite the apparent simplicity of execution, it has a high resolution and scanning accuracy, due to which it is able to digitize objects with a length of 0.2 to 10 meters. Objects that have a non-standard surface - dark or shiny, with a large number of corners and small details will not become a problem either. Among other things, its undoubted advantage is its low weight, only 900 grams.

Advantages and disadvantages of 3D scanners

Surely, many of the potential buyers are wondering: do you really need a 3D scanner to invest a lot of money in it? What can this acquisition give and will such an investment be justified?

3D scanning has become an integral part of any modern manufacturing process

In order to understand how much you need this equipment, we will list its advantages and disadvantages.

Benefits:

• They make it possible to scan objects located at a remote distance and in places inaccessible to the presence.

• They have the ability to "read" not only colors and images, but also to convey the texture of the surface.

• Significantly speed up the process of "taking" data from any object, even a very complex one with a large number of planes.

• A variety of models allows you to choose the most convenient version of the scanner, including manual or portable, which can be easily taken with you.

Weaknesses:

• Some scanners are unable to recognize transparent or black and white objects. In this case, their preliminary preparation (treatment with a special composition) is required.

• I do not always display complex objects correctly, with a large number of inserts and partitions.

• To obtain a high-quality result, they require skills and abilities to work with certain computer programs for creating 3D models.

• If the rules of operation are constantly violated, it may become necessary for expensive repairs to the equipment.

If you need high-precision and high-quality three-dimensional copies of objects, then you cannot do without a 3D scanner. It makes it possible to work in almost any conditions - indoors and outdoors, and with any objects by type and size. It is not surprising that now these devices are in great demand, which gives rise to the annual release of a large number of models, from which you can always choose the one that suits you in terms of quality and price.

Things to consider when choosing a 3D scanner

The computer equipment market offers a huge amount of all kinds of equipment, including devices for three-dimensional scanning. Navigating that variety is sometimes not at all easy: some buyers are only concerned about the cost, others are interested in the number of options (sometimes completely useless), but the most far-sighted look at the ratio of the first and second.

Choosing the right 3D scanner is a big deal

It is not always easy to take into account all the technical points that can significantly affect what result will be ultimately achieved. We will tell you what you should pay attention to if you are thinking about buying a 3D scanner.

Focus on the following parameters:

• How high is the accuracy of the 3D scanner. This is one of the most important features. It needs to be targeted first.

• Resolution also plays an important role. It follows from the first, since the accuracy of measurements and the quality of copying depend on the resolution.

• In what range the device operates, how close / far it can be from the scanned object.

• The scanning field is the parameters of that object, thing that it is able to process in 1 session.

• Does the scanner capture various atypical types of surfaces with complex terrain - channels, partitions, holes, etc.).

• Portability, mobility of the device - how easy it can be moved if desired, taken with you, its size.

• The time it takes to prepare for work, as well as the duration of the digitization process itself.

• The range of possibilities in terms of copying: are there any restrictions on shapes, textures, material, as well as operating conditions - temperature, light, etc.

Of course, the better the quality of the 3D scanner, the more expensive it is. However, you should focus primarily on the tasks that you face, and only then take into account everything else.

Applications

Three-dimensional scanners are in demand in many areas of human life. They are irreplaceable both in the industry, and for household needs. The range of their application is so wide that it is possible to list for a very long time. It's easier to say where they are not needed.

The most common areas of use are, of course, medicine, industry, architecture, construction, film industry and design.

For example, in dentistry, these devices allow you to create ultra-precise three-dimensional models of dentures. One type of such a scanner is Shining 3D's AutoScan DS-EX PRO, which does a great job with a variety of tasks while being quite affordable and reliable.

Medical 3D Scanner

In engineering, such technologies are also indispensable.
