Best metal 3D printers in 2022: comprehensive overview

What is the best metal 3D printer in 2022?

Over the past few years, there has been a surge in both supply and demand for metal 3D printers.

Manufacturers are launching metal additive manufacturing machines that are faster, easier to use, and more powerful with an increasing number of compatible metals.

Many businesses are adopting these 3D metal printing technologies to produce cost-effective metal parts and prototypes, benefiting as well from increased freedom of design linked to additive manufacturing. They are suitable for a variety of industries such as aerospace, automotive, health, engineering, and more.

Although metal 3D printer prices have been slowly and slightly decreasing, these machines are still relatively expensive acquisitions, mostly ranging from $80K to almost $1M.

With our metal 3D printer selection, we aim to provide a comprehensive overview of what’s available from well-established and distributed brands, at various price points, and with different metal 3D printing technologies.

The best metal 3D printers in 2022

Brand	Product	Build size	Country	Price Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, …).
Markforged	Metal X (Gen 2)	300 × 220 × 180 mm11.81 × 8.66 × 7.09 in	United States	$ 99,500125 000 €88,260 £14,831,072 ¥	Quote
Xact Metal	XM200C	127 × 127 × 127 mm5 × 5 × 5 in	United States	$ 110,000100 000 €97,574 £16,396,160 ¥	Quote
Pollen AM	Pam Series MC	⌀ 300 x 300 mm	–	$ 140,000135 000 €124,186 £20,867,840 ¥	Quote
TRUMPF	TruPrint 1000	100 × 100 × 100 mm3.94 × 3.94 × 3.94 in	–	$ 170,000170 000 €150,797 £25,339,520 ¥	Quote
3D Systems This brand is a certified partner from our network.	DMP Flex 100	100 × 100 × 80 mm3.94 × 3.94 × 3.15 in	–	$ 245,000245 000 €217,325 £36,518,720 ¥	Quote
EOS	EOS M 100	100 × 100 × 95 mm3.94 × 3.94 × 3.74 in	Germany	$ 350,000350 000 €310,464 £52,169,600 ¥	Quote
XJet	Carmel 700M	501 × 140 × 200 mm19.72 × 5.51 × 7.87 in	–	$ 599,000599 000 €531,337 £89,284,544 ¥	Quote
Desktop Metal	Production System P-1	200 × 100 × 40 mm7.87 × 3.94 × 1.57 in	United States	upon request	Quote
Desktop Metal	Studio 2	300 × 200 × 200 mm11.81 × 7.87 × 7.87 in	United States	upon request	Quote
Digital Metal	DM P2500	203 × 180 × 69 mm7.99 × 7.09 × 2.72 in	–	upon request	Quote
Formalloy	L-Series	1000 × 1000 × 1000 mm39. 37 × 39.37 × 39.37 in	United States	upon request	Quote
GE Additive	Arcam EBM Spectra L	350 × 350 × 430 mm13.78 × 13.78 × 16.93 in	United States	upon request	Quote
GE Additive	M2 Series 5	250 × 250 × 350 mm9.84 × 9.84 × 13.78 in	–	upon request	Quote
Renishaw	RenAM 500E	245 × 245 × 335 mm9.65 × 9.65 × 13.19 in	–	upon request	Quote
SLM Solutions	SLM 125	125 × 125 × 75 mm4.92 × 4.92 × 2.95 in	Germany	upon request	Quote
SPEE3D	LIGHTSPEE3D	300 × 300 × 300 mm11.81 × 11.81 × 11.81 in	–	upon request	Quote
TRIDITIVE	AMCELL	⌀ 300 x 350 mm	Spain	upon request	Quote
Velo3D	Sapphire	⌀ 315 x 1000 mm	–	upon request	Quote

Expand to see more specs

Technology: The technologies listed above are main categories of metal 3D printing technologies. Most manufacturers have their own branded technologies, which fall into the main categories that are listed in the table.

The products in the table are ranked by price (low to high).

Brand	Product	Technology	Build size	Country	Price Approximate starting prices based on supplier-provided information and public data. Prices may vary by region, over time and do not include additional products or services (taxes, shipping, accessories, training, installation, …).
Markforged	Metal X (Gen 2)	Extrusion	300 × 220 × 180 mm11.81 × 8.66 × 7.09 in	United States	$ 99,500125 000 €88,260 £14,831,072 ¥	Get a quote
Xact Metal	XM200C	SLM/DMLS	127 × 127 × 127 mm5 × 5 × 5 in	United States	$ 110,000100 000 €97,574 £16,396,160 ¥	Get a quote
Pollen AM	Pam Series MC	Extrusion	⌀ 300 x 300 mm	–	$ 140,000135 000 €124,186 £20,867,840 ¥	Get a quote
TRUMPF	TruPrint 1000	SLM/DMLS	100 × 100 × 100 mm3. 94 × 3.94 × 3.94 in	–	$ 170,000170 000 €150,797 £25,339,520 ¥	Get a quote
3D Systems This brand is a certified partner from our network.	DMP Flex 100	SLM/DMLS	100 × 100 × 80 mm3.94 × 3.94 × 3.15 in	–	$ 245,000245 000 €217,325 £36,518,720 ¥	Get a quote
EOS	EOS M 100	SLM/DMLS	100 × 100 × 95 mm3.94 × 3.94 × 3.74 in	Germany	$ 350,000350 000 €310,464 £52,169,600 ¥	Get a quote
XJet	Carmel 700M	Material Jetting	501 × 140 × 200 mm19.72 × 5.51 × 7.87 in	–	$ 599,000599 000 €531,337 £89,284,544 ¥	Get a quote
Desktop Metal	Production System P-1	Binder Jetting	200 × 100 × 40 mm7.87 × 3.94 × 1.57 in	United States	upon request	Get a quote
Desktop Metal	Studio 2	Extrusion	300 × 200 × 200 mm11. 81 × 7.87 × 7.87 in	United States	upon request	Get a quote
Digital Metal	DM P2500	Material Jetting	203 × 180 × 69 mm7.99 × 7.09 × 2.72 in	–	upon request	Get a quote
Formalloy	L-Series	Directed Energy Deposition	1000 × 1000 × 1000 mm39.37 × 39.37 × 39.37 in	United States	upon request	Get a quote
GE Additive	Arcam EBM Spectra L	EBM	350 × 350 × 430 mm13.78 × 13.78 × 16.93 in	United States	upon request	Get a quote
GE Additive	M2 Series 5	SLM/DMLS	250 × 250 × 350 mm9.84 × 9.84 × 13.78 in	–	upon request	Get a quote
Renishaw	RenAM 500E	SLM/DMLS	245 × 245 × 335 mm9.65 × 9.65 × 13.19 in	–	upon request	Get a quote
SLM Solutions	SLM 125	SLM/DMLS	125 × 125 × 75 mm4. 92 × 4.92 × 2.95 in	Germany	upon request	Get a quote
SPEE3D	LIGHTSPEE3D	Material Jetting	300 × 300 × 300 mm11.81 × 11.81 × 11.81 in	–	upon request	Get a quote
TRIDITIVE	AMCELL	Extrusion	⌀ 300 x 350 mm	Spain	upon request	Get a quote
Velo3D	Sapphire	SLM/DMLS	⌀ 315 x 1000 mm	–	upon request	Get a quote

Main types of metal 3D printing technologies

The four main types of 3D metal printing technologies are:

• Metal Powder Bed Fusion 3D printing (SLS, SLM, DMP)
• Directed Energy Deposition (DED)
• Metal filament extrusion (FFF, FDM)
• Material Jetting and Binder Jetting

There are also some resin-based metal 3D printers, and metal sheet lamination 3D printers, but they are harder to come by.

It is not uncommon to see different acronyms and names for similar technologies. Each brand markets their own, proprietary methods. Some metal 3D printer companies even use a mix of different technologies.

A breakdown of the metal 3D printer market by technology types. Source: Aniwaa database (2019)

Here we provide a deeper look into each 3D metal printer from our list. They are grouped together according to their main 3D printing technology type (powder bed fusion, material/binder jetting, extrusion, and DED).

Extrusion-based metal 3D printer selection (FFF, FDM)

Extrusion consists of heating the material (filament) and pushing it through a nozzle. In the metal 3D printing case, the filament is generally made up of metal particles mixed into a binding agent.

After the part is 3D printed, the result is a raw object or part; it must go through several post-processing steps– such as debinding and sintering– to attain its final form.

Most extrusion-based metal 3D printing processes include these steps. The above illustration is sourced from Desktop Metal (Bound Metal Deposition™ process).

Desktop Metal’s Studio is an office-friendly, end-to-end metal 3D printing system. Aside from the printer, the Studio line also includes a debinding machine and a furnace for sintering. Indeed, parts 3D printed with this Desktop Metal 3D printer are “green”.

The Studio printer, with its proprietary Bound Metal Deposition technology, uses filament that is filled with small, metal rods. During debinding, the binding material (wax and polymer binders) is dissolved thanks to a proprietary liquid substance. The part is left porous, and must go in the furnace for its particles to fuse and densify the part.

Contact manufacturer Get a quote Add to comparison

MarkForged is specialized in continuous fiber 3D printing, but also offers metal 3D printing with their Metal X system, featuring Atomic Diffusion Additive Manufacturing (ADAM) technology.

This MarkForged 3D printer extrudes metal-filled plastic filament to form the part, which must then be washed with a special debinding fluid (Wash-1 Station) and then sintered in a furnace (Sinter-1 or Sinter-2 MarkForged machines).

Available metal 3D printer filament includes various Steels (h23, A2, D2 tool steels, 316L stainless steel) as well as Inconel, Copper, and Titanium.

Contact manufacturer Get a quote Add to comparison

Canada-based Rapidia offers an interesting and unique way to 3D print metal. They use a water-based metal paste, which eliminates the need for chemical debinding. The water evaporates during the 3D printing process, so the part only needs to go through the furnace in order to completely solidify and attain its final form.

Confirmed, available paste types include several Stainless Steels, Inconel, and a few ceramics. Copper, Tungsten Chrome Carbide, Titanium, and various other metals are in development.

The ExOne Metal Designlab, designed in collaboration with Rapidia, works on the same basis.

Contact manufacturer Get a quote Add to comparison

Pollen AM is a French manufacturer that has been producing pellet 3D printers since 2013. Their Pam Series MC is a delta-style 3D printer (cylindrical build volume) that can print metals, ceramics, and thermoplastics.

It extrudes injection-molding-grade pellets instead of metal 3D printer filament, driving material costs down significantly. Pollen AM names their technology “Pellet Additive Manufacturing”.

Contact manufacturer Get a quote Add to comparison

This machine was built with one goal: enable mass production 3D printing of metal parts 24/7. The AMCELL is fully automated, with auto feedstock control, environment control (temperatures, humidity, air filtering), and an ejection system fitted with a conveyor belt.

Rather than providing one, big build volume, the TRIDITIVE AMCELL boasts eight delta-style ø 220 x 330 mm build areas. Its eight “robots” deposit metal-infused filament to create 3D metal parts. TRIDITIVE states that resulting parts are similar to ones produced with traditional MIM (Metal Injection Molding) methods.

TRIDITIVE’s technology is called Automated Multimaterial Deposition®.

Contact manufacturer Get a quote Add to comparison

Metal powder bed fusion 3D printer selection (SLS, SLM, DMP, and more)

At the moment, the most commonly used metal additive manufacturing technology is powder bed fusion 3D printing. Simply put, the 3D printer creates objects out of a bed of powdered metal by using a powerful laser.

3D Systems, a historical actor on many 3D printing fronts, presents the DMP FLEX 100 as a fast, precise, and affordable metal 3D printer. It offers impressive part repeatability and surface finishes, of around 20 μm and 5 Ra μm respectively. DMP stands for Direct Metal Printing.

The printer comes with 3D Systems’ software 3DXpert All-in-One Software Solution for Metal Additive manufacturing. Their LaserForm metal 3D powders are certified.

Contact manufacturer Get a quote Add to comparison

This compact metal 3D printer is destined for the production of small parts in small quantities. Its material portfolio is especially interesting for medical use cases, namely dental crowns and bridges. EOS certified metal powders include Cobalt-Chrome, Stainless Steel, and Titanium.

The EOS M100’s laser spot is precise enough to provide a great level of detail, backed by 200 W of powder.

Contact manufacturer Get a quote Add to comparison

Originally a Swedish company, Arcam was acquired by GE Additive a few years ago. The Arcam EBM Spectra L is up to 20% faster than its predecessors and is able to reduce part costs by around 10%.

This metal 3D printer is dedicated to Titanium 3D printing, but Copper is in the pipeline as well. Its laser beam power is equal to 4.5 kW, partly explaining the printer’s high melting capacity and productivity. Common applications for this printer include orthopedic implants and parts for the aerospace industry.

Contact manufacturer Get a quote Add to comparison

Concept Laser is the company behind GE Additive’s M2 Series 5. It offers an easy, optimized workflow, with a separate processing chamber and handling area that is integrated into the system. This closed-loop material system ensures a safe environment that is free of powder for the operator.

The M2 metal additive manufacturing solution is compatible with a range of metals, from Stainless Steels to Aluminum, Nickel, Titanium, and Cobalt-Chrome.

Contact manufacturer Get a quote Add to comparison

The RenAM 500E is Renishaw’s entry-level metal additive manufacturing solution. It offers a relatively large build volume and powder can be handled via a dedicated glove box to avoid powder from getting free.

This system is also equipped with an oxygen sensor and a proprietary emission-filtering system branded SafeChange™.

Contact manufacturer Get a quote Add to comparison

Officially established in 2006, SLM Solutions has been a historical player in the powder bed fusion industry for many years. The SLM 125 boasts an open software architecture that allows users to tweak the system’s parameters according to specific use cases, materials, and general needs.

Options such as laser monitoring and melt pool monitoring are available for businesses that require full transparency and control over their production series.

Contact manufacturer Get a quote Add to comparison

The TruPrint 1000 is TRUMPF’s most compact metal 3D printing system, with a 100mm-tall cylindrical build volume. It is suitable for the production of small parts and prototypes, and even small production series when equipped with the multilaser option that increases the printer’s speed.

This metal 3D printer can be operated remotely via a tablet application, which also gives access to its onboard camera stream.

Contact manufacturer Get a quote Add to comparison

The Velo3D Sapphire is a high-volume metal 3D printer from the US designed for production series. This metal 3D printer features Velo3D’s Intelligent Fusion technology to allow for complex geometries and 0° overhangs.

The system is also equipped with a range of metrology sensors that measure each and every layer that is 3D printed.

Contact manufacturer Get a quote Add to comparison

The XM200C is Xact Metal’s entry-level metal 3D printing solution. It is suitable for both research purposes and small production series. The XM200C benefits from a proprietary Xact Core gantry system for precise movements with a fusing speed of up to 500 mm/s.

Xact Metal offers their own materials, branded Xact Powder, including various Stainless Steels, Super Alloys, Tooling Steels, Aluminum, Titanium, Bronze, and Copper. Advanced users are able to use their own metal powders if needed.

Contact manufacturer Get a quote Add to comparison

Metal material jetting and binder jetting 3D printers

Material jetting 3D printers are equipped with various inkjet printheads (somewhat similar to 2D printing) that jet material onto a surface. The material then hardens, and another layer of “metal ink” is jetted on top.

Binder jetting is a similar process, but it is a binding agent that is jetted atop a layer of powder.

The Production System by Desktop Metal was designed for mass production. It is advertised by Desktop Metal as being a fast, cost-effective metal additive manufacturing solution, with a cost per part up to 20 times lower than with other metal 3D printing systems.

This Desktop Metal 3D printer is equipped with over 16,000 nozzles that are mounted onto a “print bar” that recoats the build plate with powder at the same time, hence explaining the technology’s name: Single Pass Jetting™.

Contact manufacturer Get a quote Add to comparison

Digital Metal, a Höganäs Group company, creates incredibly detailed metal parts with their DM P2500 system. It is able to print 3D metal parts with an accuracy as high as 0.001mm (1µ), and with a medical-grade surface quality of around 0.006mm (6µ).

Another interesting feat to point out is that almost 100% of leftover powder can be recycled for future prints. This metal AM machine is able to churn out serial production series efficiently and reliably; one of the company’s first DM P2500 printers has been running 24/7 since 2013, according to Digital Metal.

The Digital Metal DM P2500 is a certified metal 3D printer (CE and UL) that is compatible with certified metal materials (ISO 22068).

Contact manufacturer Get a quote Add to comparison

Australian manufacturer SPEE3D has developed an impressively fast metal 3D printing technology called Supersonic Deposition. The technology is based on metal cold spray, using compressed air to “jet” metal powder through a nozzle at high speeds.

This enables the LightSPEE3D to 3D print at up to 100 grams per minute and with a range of metals including copper.

Contact manufacturer Get a quote Add to comparison

XJet developed an impressive, proprietary jetting technology they call NanoParticle Jetting™. This inkjet method disperses millions of tiny droplets that contain nanoparticles of solid metal. The liquid material comes in cartridges that are easy to insert into the printer.

After being printed, the metal parts must go through support removal and sintering processes to attain their final form.

Contact manufacturer Get a quote Add to comparison

DED: Directed Energy Deposition metal additive manufacturing systems

Directed Energy Deposition (DED) is comparable to filament extrusion. The metal material is pushed through a special nozzle, like with FFF/FDM, but a powerful laser beam solidifies the material at its deposition point.

Formalloy produces a range of metal DED 3D printers with up to 5 axes of motion. They can be used to produce metal parts but also to repair or clad existing parts.

Different laser wavelengths are available, as well as different build volumes: 200 x 200 x 200 mm, 500 x 500 x 500 mm, and 1000 x 1000 x 1000 mm. Metal 3D printers from Formalloy can be customized depending on company requirements.

Contact manufacturer Get a quote Add to comparison

Alternative metal 3D printers and special mentions

Hybrid metal manufacturing systems

Some manufacturers are specialized in hybrid metal manufacturing systems. They combine both subtractive and additive manufacturing methods, often with robotic arms that are able to move on more than three axes.

Some of the biggest actors on the hybrid metal AM system market are:

• Gefertec (Germany)
• DMG Mori (Germany)
• Matsuura (Japan)
• Sodick (United States)

XXL-sized metal 3D printers for industrial production

For those that require very large metal parts, there are several huge, industrial machines that offer gigantic build volumes for industrial production. To name a few:

• Sciaky EBAM 300
• Titomic TKF1000
• ADC Aeroswift
• ADIRA AddCreator
• Fabrisonic SonicLayer 4000
• ExOne X1 160PRO
• InssTek MX-600
• BeAM Modulo 400
• Optomec Lens CS 600
• Additive Industries MetalFAB1

Metal 3D printers from China

There has recently been a lot of growth in the metal 3D printer market in Asia, and more specifically in China. Some Chinese brands have been upping their game in that respect, providing industrial-grade metal 3D printing options:

• Farsoon
• ZRapid Tech
• Shining 3D
• Wiiboox

However, we feel that they are not yet playing in the same league as the 3D printers from our main selection, mostly due to a lack of distribution networks, after-sales service and training, and other factors which tend to matter when considering them together as a whole.

R&D metal 3D printers for labs

In certain cases, metal 3D printers are used for research purposes to develop and test new materials. There are a few machines that are specifically designed for this:

• Open Additive PANDA-6”
• Freemelt ONE
• Sharebot metalONE

Pros and cons of metal 3D additive manufacturing

Benefits of 3D printing metal parts

• On-demand production: Metal additive manufacturing offers more flexibility and control over the production line.

• Complex designs made possible: With 3D printing technology, it is possible to create highly detailed and intricate parts that would have to be broken down into several pieces with traditional methods.

• Waste reduction: Compared to CNC milling, for example, metal AM produces much less waste as it only consumes the material needed for a certain part. This is more true for extrusion-based methods than it is for powder-based methods, where it isn’t always possible to re-use 100% of unsintered or unbinded material.

• Lighter parts: Whereas metal parts are usually completely solid infill-wise with other methods, 3D printing allows parts to be more or less hollow without undermining their strength and resistance.

• Cost-effectiveness: All the above benefits of metal 3D printing can inherently reduce costs per part, although high metal 3D printer prices do represent a significant entry barrier. Reaching a positive return on investment can take a while depending on your throughput.

Limits of metal 3D printing

• Metal 3D printing prices: Metal AM systems are still quite expensive, as are metal powders and metal filaments. There are hidden costs, too (e.g. energy consumption, learning curve, etc.).

• Environmental constraints and safety precautions: Most metal 3D printers have a large footprint and require specific operating environments with controlled temperatures, hygrometry, and more.

• Post-processing: In many cases it is necessary for parts to be post-processed, whether it’s debinding and sintering or finishing touches for surface quality.

• Physical properties: It can be difficult to achieve the same physical properties that traditionally manufactured metal parts have. There are a number of factors (e.g. anisotropy) to take into account during the design process and file preparation before even trying to 3D print a certain part.

Metal 3D printing materials

Which metals can you 3D print?

A growing number of metals and metal alloys can be 3D printed. These are the main ones:

• Aluminum
• Titanium
• Nickel, Inconel
• Copper
• Bronze
• Cobalt, Cobalt-Chrome
• Steels (tooling, maraging, stainless)
• Precious metals (gold, silver, platinum)

Which metal 3D printing material formats are available?

Metal 3D printing material can be found in various formats, catering to different metal 3D printing methods. The most common are:

• Powder
• Wire
• Filament

It is also possible to find metal 3D printing resin as well as metal sheets for lamination-based 3D printers.

Metal 3D printer price: how much does a metal 3D printer cost?

Industrial metal 3D printer prices generally range from about $30,000 to over one million dollars for the most premium, industrial-grade metal additive manufacturing systems.

Additional costs to consider are the materials for metal 3D printing, which can cost a few hundred USD/kg, as well as costs linked to post-processing (tools, time, etc.).

Applications for metal AM systems

There are thousands of possibilities and use cases for metal 3D printing in a wide range of industries. A few industries have been incrementally using metal AM:

• Aerospace
• Automotive
• Medical

Whether it’s for tooling, replacement parts, or final products, many businesses can benefit from metal 3D printing.

However, metal additive manufacturing isn’t necessarily beneficial for every single metal part. Although some metal 3D printing systems have a relative capacity for serial production, it is generally cheaper to keep using traditional methods for simple parts.

For cases where complex geometries, rapid prototyping, and mass customization are required, metal AM is convenient and efficient.

Metal 3D printing services: order 3D metal parts online

For professionals with limited office space and human resources, low budgets, and/or few needs of custom parts and prototypes, metal 3D printing services can be an ideal solution.

These additive manufacturing service companies own a variety of high-quality 3D printers with different technologies, and their professionals are experts in 3D printing. It is possible to order metal 3D parts on-demand, without acquiring a 3D printer or having to buy a certain material for one-time use.

Here are some of the most trusted 3D printing service providers that offer metal printing services:

• Sculpteo
• Shapeways
• Hubs (ex 3D Hubs)
• Stratasys
• i.materialise
• Protolabs

Metal 3D printing technologies and acronyms

Many manufacturers develop proprietary variations of existing technologies and label them their own registered names:

• Powder Bed Fusion (PBF): DMLS (Direct Metal Laser Sintering), DMP (Direct Metal Printing), LaserCUSING, LBM (Laser Beam Melting), LMF (Laser Metal Fusion), SLS (Selective Laser Sintering), SLM (Selective Laser Melting)
• Directed Energy Deposition (DED): DMT (Direct Metal Tooling), EBAM (Electron Beam Additive Manufacturing), EBM (Electron Beam Melting), LENS (Laser Engineered Net Shaping), LMD (Laser Metal Deposition)
• Metal Material Jetting (MJ) or Binder Jetting (BJ): Magnet-o-Jet, Nanoparticle Jetting, SPJ (Single Pass Jetting), Metal Jet
• Metal filament extrusion/Fused Filament Fabrication (FFF): ADAM (Atomic Diffusion Additive Manufacturing), CEM (Composite Extrusion Modeling), FDM (Fused Deposition Modeling), FFD (Fused Feedstock Deposition), FMP (Filament Metal Printing), BMD (Bound Metal Deposition), MIM (Metal Injection Molding)
• Lamination: SL (Sheet Lamination), UAM (Ultrasonic Additive Manufacturing)
• Metal resin 3D printing: DLP (Digital Light Processing), FluidFM, SLA (Stereolithography)

Metal 3D printing FAQ

Is 3D printed metal strong?

Metal 3D printed parts can be as strong (or even stronger) as metal parts created with traditional manufacturing processes such as casting. The part’s strength will, however, depend on the metal AM method used and the conditions in which it is 3D printed.

When was 3D metal printing invented?

Metal 3D printing became possible in the 1990s with the development of Selective Laser Melting technology. However, 3D metal printing only started to gain traction and public interest from around 2010 onwards.

How does metal 3D printing work?

There are several ways to 3D print metal. Layers of metal filament can be deposited one after the other, producing a green part that must later go through debinding and sintering steps. It is also possible to fuse metal powder particles together with a laser, or with an inkjet printhead that deposits drops of binding material onto the powder.

10 Best Metal 3D Printers 2022 (Pros, Cons, FAQs & More)

Metal 3D printing has become a hot topic recently mostly due to the fact that the current 3D parts that are being printed are really good quality. So good in fact, some of it is actually better than what is made by normal methods.

Traditional methods tend to be wasteful when it comes to making metal and plastic parts. Often, when metal parts are made, almost 90 percent of the metal material is cut away creating a lot of waste and using a lot of energy. By using a 3D printer to create these same metal parts, manufacturers can use less energy and minimize waste.

Plus, the metal pieces that are printed can weigh up to 60 percent less than those pieces made with traditional manufacturing. Industries such as airlines can save a lot of money in fuel with this type of weight reduction. This has been an exciting new technology to keep an eye on as there can be so much development in a short period of time, things can progress almost within the blink of an eye.

Attempts to print with metal can actually be traced back to the 1880s by welders using carbon electrode arcs to fuse pieces of metal together. It really wasn’t until the development of the laser that 3D printing was brought to the general public and the eventual introduction by NASA of the technique called selective metal melting (SLM) Engineers at NASA has made it successful in producing parts with complex geometry and dimensional accuracy that is beyond what was thought possible with regular fabrication methods.

The fastest method of 3D printing has been discovered through depositing a powder metal matrix that has binders and, after each layer is deposited, the binder is melted and held together temporarily until a final baking in an oven. This process has been streamlined by Shapeways to give the public the fastest process possible from a variety of metal materials.

Industrial Metal 3D Printing

Buying a metal 3D printer for your business is a big and expensive step. It is probably not a wise business decision unless you plan on printing metal every day. The costs of just the printer can run between $100.000 and $500.000, plus you will need to add the additional cost of a salary for someone to not only run the printer, but who can also maintain it.

Instead of investing in your own 3D printer, you should probably look into hiring a 3D printing service that can take care of your needs, and companies like Sculpteo and iMaterialise will actually mail you your metal 3D printed parts right to your door. They currently offer 3D printing in the following metal materials:

• steel
• copper
• aluminum
• brass
• sterling silver
• bronze
• titanium
• gold
• platinum

Professional goldsmiths can also order the wax models that they need for casting custom orders. This has been a rapidly growing service all around the world with the 3D printing metal machines becoming more common at 3D printing services.Big companies have become fond of these services as they can easily create fully automated factories that are producing enhanced parts that allow you to evenly distribute the material in a part so it can be engineered to withstand more stress making it structurally sounder while still reducing its weight.

If you do intent to use one of these companies, they will require special software use like a special CAD Design or Shapeways has specific 3D printing metal guidelines.

Shapeways

Offering two types of services, Shapeways is one of the world’s most popular online 3D printing services allowing you to choose from a wide range of professionally designed items and then customizes them with your printed specifications. Shapeways is comparable to other 3D printing services giving designers the option of a storefront to print and sell their work. It can also provide rapid prototyping allowing customers to benefit from industrial grade printers like EOS and 3D Systems with dedicated technical support.

Shapeways uses the following 3D Printed Metals:

• Aluminum
• Brass
• Bronze
• Gold
• Platinum
• Precious plated metals
• Silver
• Steel

Shapeways can also make castable wax for jewelers.

Sculpteo

Similar to i.materialise and Shapeways, Sculpteo is an online 3D printing service that lets you upload a 3D model and they will then create it from a choice of materials. You can also open a storefront to sell your creations and it uses a lineup of 3D printers including high-end machines like EOS, 3D systems, ZCorp, and Stratasys. Using extensive technical documentation, Sculpteo helps you to find any design flaws and find just the right material you need to create your project.

Sculpteo uses the following 3D Printed Metals:

• Alumide (plastic added with aluminum particles)
• Brass
• Silver

i.materialise

Materialise works primarily with industrial clients to create 3D printed products and prototypes, but its online 3D printing company called i.materialise works with the individuals and the general public to allow them to upload their designs to print them out. After their products have been successfully reproduced, i.materialise allows them to sell it on their gallery or online store.

i.materialise uses the following 3D Printed Metals:

• Alumide (plastic with added aluminum powder)
• Brass
• Bronze
• Copper
• Gold
• Silver
• Steel
• Titanium

3D Hubs

You can also use 3D hubs to find individuals and businesses that provide 3D printing services in your area. You can connect with them directly and upload your STL file for an instant estimate. You can filter by distance, materials, and user rating. No matter what type of product you want printed, there is a good chance you will have someone in your area willing to do it, plus many of the materials can be printed in industrial quality which you can note with an »HD« in the search field.

3D Printed Metals Applications

You probably don’t even know it but 3D printing is being used more and more for average objects like dental and medical implants. Since they can be adapted to an individual’s needs, they are considered the best available option for patients.

Jewelry has also benefited from the improvement in 3D metal printing technology as it enables manufacturers to switch from lost wax casting and resin 3D printing to direct metal 3D printing. The aerospace industry has also seen an increase in use of 3D printing metal objects and the automotive sector is the next industry where the manufacturers are using 3D printing not just for prototypes, but to make actual car parts

3D printing is still overcoming some obstacles, mostly its high cost, as well as its low production speed which can cause problems for printing 3D metal objects. However, many of the issues that metal 3D printers contend with are similar to any 3D printer that consists of limitation with hardware and software, plus materials and material optimization. Most metal parts generated by a 3D printer are just as strong as components made with traditional methods if not above industry standards in some cases.

Metal 3D Printing At Home

For those interested in metal 3D printing at home, there are several obstacles to overcome including the need for very high temperatures to do the printing. This is not a technology that we will see for in home use probably within the next few years. But, as the technology evolves, there will be a lot of growth in these new applications.

It is possible to use added metal powders to a plastic filament that contain a high enough percentage of metal powders but also enough plastic that it can be printed at a low enough temperature that any 3D printer could do it. This combination will still have enough metal to have the feel and look of a metal object. The Dutch company Formfutura has a new metal 3D printing filament that they have increased their ratio up to 85 percent metal powder and 15 percent PLA for more of a metal feel.

If you do plan to try some of these metal 3D printing filaments, you may want to upgrade your 3D printer nozzle depending on your 3D printer’s quality. You may also want to invest in a durable printer hotends that is made of metal and can withstand high temperatures and can be mounted onto most 3D printers. Since metal 3D printing filament can be pretty abrasive, you will have to replace your 3D printer nozzle fairly often. And, don’t forget about investing in a proper finishing process like sand grinding, waxing, greasing, brushing, or coating so that your metal 3D print object can shine.

Available Metal 3D Printing Technology Types

Powder Bed Fusion

Most large companies are using powder bed fusion in their metal 3D printing process meaning that they use an energy source like a laser or another energy beam to fuse atomized, or perfectly round particles, powder to make the layers of the objects.

With eight major metal 3D printer producers in the world, this technology has already made its way into a number of machines and more and more are entering the market all the time. This technology is called DMLS (Direct Metal Laser Sintering) or SLM (Selective Laser Melting).

Binder Jetting

Binder jetting is another professional approach that uses a powder bed where the layers of metal particles are glued together and later sintered or melted together in a high-temperature kiln like with ceramics. Also similar to ceramics is the capability of mixing the metal powder into a metal paste and using a pneumatic extrusion 3D printer to create the 3D objects with the final step being sintered in a kiln. This approach is used by Mini Metal Maker 3D printer which is the only really affordable metal 3D printer on the market.

Metal Deposition

The final method for metal 3D printing is fused filament deposition which is not really possible for a desktop printer. This is a good option for very large industrial metal manufacturers who can deposit metal. The first option is called DED (Directed Energy Deposition) or Laser Cladding that uses a laser beam to fuse slowly released metal powder that is deposited as layers of an object with an industrial robotic arm in a closed chamber.

The second option is called EBAM (Electron Beam Additive Manufacturing) which is a type of soldering process that has a very powerful electron beam that is used to fuse molten metal and a 3 mm thick titanium wire and is shaped into very large metal structures. Only individuals that work for the United States Defense Department will need this type of technology.

Types of Metal Used

Titanium

One of the most commonly used metals for 3D printing is pure titanium, either Ti64 or TiAl4V. Its versatility is an attractive quality as it can print out both light and strong. It is mainly used in the medical industry in creating personalized prosthetics and in the automotive/aerospace industries in making prototypes and parts.

Titanium is used in both binder-jetting and powder bed processes. It does have one catch, it tends to be highly reactive, so it can explode easily in powder form which is why when it is 3D printed, it uses a vacuum or in an argon gas atmosphere.

Stainless Steel

When looking at affordability, stainless steel tends to be the most inexpensive as well as strong metal to 3D print. This is also a versatile metal that is used in many art and design projects as a well as a wide assortment of industrial applications. Because of this type steel alloy, you will find it almost exclusively used in industrial projects due the nickel and cobalt it contains making it have very high elastic properties while remaining hard to break.

Inconel

The superalloy called Inconel is manufactured by Special Metals Corporation. Inconel is made of mostly chrome and nickel and retains a high-temperature resistance which is why it is mainly used for projects in the chemical, oil, and aerospace fields like black boxes on airplanes.

Aluminum

Aluminum is very light and versatile making it a popular metal to use with 3D printing projects. Primarily, it is used as different Aluminum based alloys.

Cobalt Chrome

Containing a very high specific strength, this metal alloy is used mostly to make dental implants, turbines, and orthopedic implants. These are all applications where 3D printing has become a popular manufacturing method.

Copper and Bronze

Mostly used in wax casting processes, copper and bronze are usually not used a lot in powder bed fusion processes as they are not the perfect choice for industrial projects. They are more commonly used in arts and crafts.

Iron

Iron is usually only used as an additive to PLA based filaments like ProtoPasta and TreeD.

Gold, Silver and Other Precious Metals

Precious metals like silver, gold, and platinum are used mostly by powder bed fusion companies. This is a challenging process as the printer must manage the precious powders while maintaining the aesthetic properties of the materials. 3D printing of precious metals is used for medical, jewelry, and electronics applications.

Metal 3D Printer Reviews

1. Sciaky EBAM 300 – Metal Filament 3D Printing

For those needing to print very large 3D metal structures, the Sciaky EBAM 300 has the capabilities of offering up the size you need and is mostly used by the United States defense and aerospace industries. The EBAM 300 is Sciaky’s largest regularly available system that features a build size envelope that measures 228” wide x 48” deep x 48” high.

Sciaky is one of the fastest growing industrial 3D printer commercial companies. The EBAM 300 can create a 10-foot long titanium aircraft structure at a rate of fifteen pounds of metal per hour completely the project in 48 hours. In comparison, it would take forgings between 6 and 12 months to build what this 3D printer can create in two days.

The unique technology that Sciaky’s uses can melt a 3 mm thick titanium filament with a high power electron beam gun providing standard deposition rates that range from 7 to 20 pounds per hour. The EBAM 300 has a maximum work envelope of 19′ x 4′ x 4′ x 8’ which is one of the biggest build platforms of any metal 3d printer that is commercially available.

The EBAM 300 is also the only 3D printer available that produces a metal structure over ten feet long, and it is created to additively manufacture prototypes from high-quality metals like niobium, titanium, Inconel, Tantalum, and other alloys. It also gives a very high level of control over the material composition and geometry of its patented IRISS Closed-Loop Control Technology. It also includes huge savings on raw materials like precious metals with the large reduction of waste.

The EBAM 300 is a full-scale method of production for institution and corporations that need more than just prototypes created. This system can be used to improve, repair, and create next-generation end-use technology in the defense and aerospace industry as well as the metals and energy industries.

The EBAM 300 is truly the largest 3D printing system in the world that is fit for actual use in the commercial and industrial world and not just a mega-scale 3D printer that cannot be used commercially or is only available to a small group of individuals that has few real-life applications. The Sciaky EBAM 300 can actually be used for practical purposes to create functional metal parts.

2. Fabrisonic UAM – Ultrasonic Metal 3D Printing

Using Ultrasound Additive Manufacturing Technology, or UAM, Fabrisonic creates 3D print large metal parts with machines that use three-axis CNC mills with an additional welding head for additive manufacturing. With a build volume of 6” x 6” x 3”, metal layers are cut first cut and then welded together with an ultrasound.

The UAM process uses ultrasonic welding to build up solid metal objects into a three-dimensional shape with a series of metal tapes. The process includes periodic machining operations that create a shape detail of the object. A transducer produces vibrations that are transferred to the disk-shaped welding horn that makes an ultrasonic solid-state weld between a base plate and the thin metal tape.

With a continual roll of the horn, the entire tape is welded to the plate with a series of layers welded together onto to create the height of the object. This repeated process occurs until the finished component is created with a final CNC contour milling used to is then used to accomplish the necessary surface finish and tolerances.

Ultrasonic welding gives Fabrisonic its solid-state bond that has been around since the 1960s. The welding process uses ultrasonic vibrations to generate motion similar to friction between two surfaces that are being held together with pressure which can cause plastic deformation and shearing that can cause contaminants and surface oxides to disperse. As the sharpness disappears, the contact between metal and metal is increased and forms a solid bond between the parts because of the heat and pressure.

Fabrisonic has been working on parts for defense contractors, aerospace companies, and a few other high-tech manufacturing companies. They are also anticipating growth and looking to expand in the future.

3. Concept Laser XLine 1000 – Powder Metal 3D Printing

With a build volume of 630 x 400 x 500 mm, the Concept Laser XLine 1000 is the biggest powder metal 3D printer currently on the market. Similar in size to a single story house, the XLine 1000 is able to build parts that weigh up to 1000 kg and uses a 1,000-watt laser at the core of its system. This build envelope is able to build a standard V6 engine with additive manufacturing and can significantly increase productivity in comparison to other commercially available laser melting systems.

Not only can the X line 1000R increase construction rates, but it also can improve surface quality, system reliability, and higher reproducibility due to its process monitoring and its qualification for using a variety of projects with a wide range of powder materials. It works with a wide variety of metals like nickel-base alloy, stainless steel, cobalt-chromium alloy, hot work tool steels and precious metals like silver and gold alloys and reactive powder materials like aluminum and titanium alloys. The versatility of the XLine 1000 makes it a good choice for many industries like automotive, aeronautics and space, jewelry, and medical and dental.

Of the above industries, the automotive and aerospace industries will benefit the most from the use of lightweight aluminum alloys that replace expensive tool and die casting processes to build a highly ridged structure with weight-optimized geometries into lightweight structures.

As the capabilities of 3D printing hardware rapidly evolve, printers can now build huge components with great precision and fine resolution at faster speeds. As the technology improves, machines like the XLine 1000 can transform industries in new ways that can move the competition advantage to high volumes of low cost production.

4. Desktop Metal Studio

Now, for those of you looking for a metal 3D printer that can sit on your desk, the Desktop Metal Studio isn’t quite small enough, but it is as close as you will get, plus it is a great addition to your workplace. This printer actually comes with a furnace and can print parts that can be ready in just one hub using a process called Microwave Enhanced Sintering. This is actually a pretty inexpensive printer when you consider its many capabilities and features that it offers, plus it can 3D print as fast as 16 cm3/hr.

The Desktop Studio is one of the most inexpensive and fastest metal 3D printing technologies that you can find on the market and is actually around ten times cheaper than its competitors. Instead of selectively using melt metal powder, the Studio 3D printer uses metal rod extruders in a way that is comparable to how a plastic FDM printer works. By eliminating the safety requirements that are normally used with metal 3D printing when you are opening alloys and using new features like closed-cell infill to create lightweight strength.

The Studio System is comparable to Metal Injection Molding (MIM) by using bulk sintering to accomplish densities that are higher than 98% and parts that are created that perform similarly to wrought alloys. The Desktop Metal Studio features a software controlled workflow that has every stage of the process managed and automated by software, plus a proprietary separable supports technology that makes it possible to take out parts by hand.
As the technology grows closer to allowing a metal 3D printer into our homes, the Desktop Studio will be one of the printers that helped us get there. It is only one step removed from at home capabilities and it shouldn’t be surprising if they have an at home model available in the next few years.

5. Markforged Metal X

Revolutionizing 3D technology, Markforged has created Metal X for their metal printing field that can manufacture parts with incredible speed. It has incredible geometrical accuracy when it prints, and the parts it creates uses metals that can be used in the automobile, aerospace, and weapons industries.

The Metal X actually creates real metal parts with its full metal 3D printer out of powdered metal that hardens with massive heat and creates durable and lightweight materials. It has an extruder that creates the initial shape on a build plate that the material is bonded to in small furnace reduce the size of the object but it also has the ability to evaluate any shrinkage and automatically adjust the design as it works.

Using new technology called Atomic Diffusion Additive Manufacturing or ADAM., the Metal X gives you unique design features that include the capability to add honeycomb internal structures that lower the weight of the components. With a build volume of 200 mm x 200 mm x 250 mm and a 50-micron layer height, you can hardly tell the difference between the parts that are printed and those that are cast.

Metal X can print the following metals:

• Stainless Steel 17-4 and 303
• Aluminum (Beta) 6061 and 7075
• Tool Steel (Beta) A-2 and D-2
• IN Alloy (Inconel) 625 (Beta)
• Titanium Ti-6Al-4V (Beta)

Even though the price of this machine is incredibly high, it is one of those machines that is awesome to know is out there and helping to raise the bar for metal 3D printing.

6. Shining 3D’s EP-M100T

On the smaller metal printer side is Shining 3D’s EP-M100T that is perfect for jewelry, dental applications, and education. It uses a 100 to 200 Watt laser that can process a very wide range of powders into a metal object. It uses the selective laser melting 3D printing technology (SLM) that selectively melts metal powder layers.

The Shining 3D EP-M100T has a practical and compact design and has the following features:

• A build chamber that is compact and perfect for printing small parts that can be used in the medical, dental, and jewelry industries.
• A laser with 100W/200W power
• Monitoring through remote control and smartphone
• Eplus 3D printing software

The Shining 3D EP-M100T 3D printer can use the following metals:

• Titanium alloy
• Aluminum alloy
• High strength steel
• Tungsten alloy
• Copper alloy
• Stainless steel

Using Selective Laser Melting technology, the Shining 3D EP-M100T selectively melts fine layers of metal powder directly from a 3D file. With its smaller build chamber, the EP-M100T is great for a lab environment where you need less power and less accessory equipment. And with its open system, the EP-M100T gives you limitless possibility for lab experiments.

With a practical and compact design, the EP-M100T gives you a touch screen with user-friendly controls and a remote control and diagnosis through a phone. There is also a multiple precaution system protecting both people and machine, plus an integrated design that makes maintenance and operation convenient.

The EP-M100T also features high property and high precision printing quality that uses an intelligent powder coating method, plus a quick scanning speed that guarantees a more efficient printing process. It also has a lean design that helps to guarantee a low-cost operation with a compact chamber design and tightness that reduces powder consumption.

The EP-M250 can be used an in a wide variety of applications including education, dental, and jewelry. It also uses a diverse amount of printing materials making it very useful for the workplace.

7. Aurora Labs S-Titanium Pro

Notable for using a Kickstarter campaign to start its production, Aurora Labs S-Titanium Pro uses a wide variety of metallic powders. It uses a hybridization of different metal printing technologies including SLM, SLS, and DED making it very versatile so that you can apply its products to various industries.

After an intellectual property dispute, the initial Aurora Labs Kickstarter project fell through and they began development of a 3D printer that would be even faster. They also offer an affordable product for their class with the S-Titanium that features a 300W laser and allows you to print more metal materials than its competitors including:

• Stainless Steel 316
• Stainless Steel 420
• Inconel 625
• Inconel 718
• Hastelloy C276
• Stellite 1
• Stellite 6
• Stellite 21
• NiBSi + WC60%

Eventually, it has plans to include materials like:

• Titanium Grade 1
• Titanium Grade 2
• Titanium Grade 4
• Titanium Grade 6
• Titanium Grade 12
• Bronze, Brass
• Gold
• Silver
• Aluminium AlSi7Mg
• Aluminium AlSi10Mg

It is also compatible with some third-party metal powders as long as they follow their specific purity and size requirements. Each machine is basically three printers in one that can print in one of three modes:

• Selective laser sintering (SLS)
• Selective laser melting (SLM)
• Directed energy deposition (DED)

You can also do on the fly alloying in DED mode, as well as pseudo-alloying due to three independently controllable powder hoppers.

Aurora Labs has received a lot of interest and is in full production to keep producing their machines. With their incredible versatility and use of multiple metals, Aurora Labs S-Titanium Pros is a less expensive and popular model that is helping to take metal 3D printing to the next affordable level.

8. Xact Metal XM200

In contrast to the other 3D metal printers, the Xact Metal XM200 uses a chamber that is flooded with Argon gas plus high power laser beams and powders on a conveyer belt to create objects. It has a little smaller build volume, but it is still an affordable metal 3D printer by a US-based manufacturer. The XM200’s beam has is consistently orthogonal across the entire surface of powder that helps it to consistently produce the right fusing properties throughout the entire build area.

Xact Metal XM200 features:

• Uses a 250 W fiber laser that builds layers that are as thin as 20-100 microns with a spot size greater than 10 microns that allow a high level of precision.
• Utilizes cloud connectivity for one or more 3D printers that provide remote monitoring of the entire 3D printing process.
• Easy access to the build area that allows for convenient cleaning and quick set up.

The Xact Metal is compatible with several metals including:

• Xact proprietary powder 316L
• Stainless Steel and the proprietary powders
• Inconel 718 Superalloy
• Titanium 6Al 4V
• Aluminum Si10Mg
• Maraging Steel

The Xact Metal utilizes a traditional and laser powder bed system that allows you to create elaborate metal prints. By using a laser, the printer can fire right onto the material while it is on the platform and it can then use a high-speed scanner while the powder shapes leading to a consistent power level across all the different areas.

The unique build chamber system is a little on the small side, but it is needed because of the controlled gas system that lets out all of the oxygen to fill up with argon instead. Depending on the type of company you work for, it may not fit with your model due to its small build volume, plus it requires a special power system that you may have to invest in.

9. M400 by EOS

Designed by German manufacturer EOS, the EOS M 400 is an industrial 3D printer that is based on the DMLS (Direct Metal Laser Sintering) 3D printing technology that was developed by EOS. This printing technique utilizes fiber lasers to melt and fuse fine metal powder creating a series of layers as the object is built. With this method, you can create 3D printed products using complex geometry elements like deep slots, freeform surfaces, and/or coolant ducts.

The EOS line of industrial metal 3D printers uses the following metals:

• Titanium
• Cobalt chrome alloys
• Aluminum
• High-grade steel
• Nickel
• Maraging steel

The EOS M 400 includes additive manufacturing system produces of high-quality large metal parts with a building volume of 400 x 400 x 400 mm. The EOS M 400 allows for the production of an industrial scale of large metal parts without any need for tools directly from CAD data. It includes the following features:

• High productivity with proven quality
• Due to 1kWlaser, it has increased productivity
• Reduces non-productive time by recoating both sides
• Reduces filter costs with a new recirculating filter system that has an automatic cleaning function

With a modular platform, the EOS M 400 contains a setup station and a process station, plus for future innovation, it facilitates easy integration. It also includes an extensive monitoring feature that takes quality management to the next level and sophisticated software that separates job preparation and calculation from the actual building process.

Improved usability makes the EOS M 400 very user-friendly as it supports the production of complex metal parts with its fast and easy touch screen operation with a broad material portfolio. EOS also offers a large number of metal materials to meet your individual requirements.

10. ALUNAR Metal 3D Printer Fully Assembled High Precision Auto-Leveling FDM Desktop 3D Printing Machine

The Alunar 3D printer allows you to discover a new hobby or take one you already have to the next level. With 3D printing, you are opening yourself up to tons of new possibilities, basically, if you can dream it, you can make it. With the Alunar 3D printer, you can customize and personalize items creating endless products for your business.

The Alunar 3D printer also allows you to foster new learning experiences through experimentation, and through problem solving and critical thinking, you can turn your dreams into actual sellable objects. With 3D printing you can print individual objects, parts for a larger project, or complex objects that move. You can even expand your creation by using other tools along with the Alunar 3D Printer to create multi-material projects.

The Alunar 3D Printer R200 is a small to medium sized high-performance printer that is affordable and accurate, plus it is easy to setup and use. Featuring a flexible and user friendly software system, the Alunar 3D printer is quick and convenient to install, plus you can get simple-combined and colorful printing by just changing out the filament while the printer is working. You can also outfit it with a small 0.4mm extruder to guarantee its accuracy and quality.

The Alunar 3D printer also features all metal frames that are easy to put together, plus it is not necessary to set up heating beds as the print is started right on the On Patent Print Plate with strong filament bonding. The Color Touch Screen Control makes it easy to control and operate while printing, plus it makes it expandable with more functions.

Other features include a support 1.75mm ABS/PLA filament, an Auto Install and Uninstall filament function, and a memory function allowing you to print from a stop point. This also means it is possible to print several colors since you can stop printing to replace the filament. Of all the metal 3D printers on this list, the Alunar 3D printer has the most possibilities for the average person and is worth checking out.

Metal Filament Reviews

1. 3D Solutech Silver Metal 1.75mm 3D Printer PLA Filament
Professional grade 3D printer filament by 3D Solutech can provide printed objects in various materials and colors. Each spool is hand checked and vacuumed seal to ensure high-quality levels, and the 3D Solutech PLA filament is consistent in its printing experience and in maintaining a smooth product.

You will find that 3D Solutech 3D Printer filament is always round and you won’t find any bubbles, residue, breaks, or kinks. Using their ultra-smooth technology, Solutech filaments are able to product smoothly and beautifully to create delicate objects. These filaments are also tested on various models of 3D printer to make sure consistent quality throughout the market.

Pros:

• Consistent and spooled well
• Good quality, prints smoothly
• Has a bit of shine to it

Cons:

• Has a tendency to jam

2. Gizmo Dorks 1.75mm Metal Copper Fill Filament

For a different look, Gizmo Dorks metal copper fill filament lets you make unique products with a metallic finish and look. With a unique mix of real copper powder with PLA filament, you will get prints that are similar to regular PLA, and it can be printed on build plates that are either heated or non-heated.

When using metal copper fill, make sure to consider heat migration as heat will move faster through filament than normal. Metal copper filled prints can also be post-processed by using coarse steel wool to polish your surface.

Pros:

• Good quality, great adhesion
• Great color, easy to print
• A lot brighter than other coppers

Cons:

• Not easy to polish

3. SainSmart Copper Metal 1.75mm Filament
If you are looking for vibrant color, the SainSmart 3D Printer Filament provides quality filament that will allow you to bring your ideas to life. This professional grade filament is good quality filament that is always round with no air bubbles, breaks, kinks, or oil residue.

SainSmart Copper Metal is used throughout eduction, building, electronics, health care, toys, automobile, and anime fields. It also works common 3D printers like FlashForge, MakerGear, Reprap, MakerBot, and Solidoodle.

Pros:

• Prints well, very consistent
• Good strength and rigidity
• Prints really well, good adhesion

Cons:

• Pretty brittle right off the spool

4. MeltInk3d Silver 1.75mm PLA 3D Printer Filament

Made with 100% raw materials. MeltInk3D is made with high-quality standards and all of their filaments are guaranteed to be 1.75mm in diameter. All filaments are vacuum packed to guarantee all of your printing projects will be of the highest quality.

Pros:

• Great color quality, metallic look
• Easy to print, high-quality results
• Nice flow and adhesion

Cons:

• Color is too dark for some people

5. Proto-pasta SSP11701 Polishable Stainless Steel Loose Coil

A dense material that prints easily, the Proto-pasta SSP11701 makes heavy cast metal looking prints that can be sanded, brushed, or polished making it perfect for costumes, jewelry, props, and figurines. Proto-pasta does not require a heated bed, and it uses a direct-drive system with 0.4mm nozzles although a larger, wear resistant nozzle is suggested for more service intervals.

Pros:

• Nice heavy material
• Easy to print
• Sands down smooth with very little effort

Cons:

• Extruder doesn’t keep up very well

Final Thoughts

The last few years has seen amazing progress in the metal 3D printing industry. Each material has a unique set of properties that can suit a wide range of products including jewelry, medical and dental products, and prototypes. As the technology has developed, it has shown to be in some cases better than what is manufactured by traditional methods and keep in mind it is just getting started.

[mc4wp_form]

Industrial metal 3D printers

Technology | Benefits | Usage examples | Equipment selection

Metal 3D printing is rightfully considered one of the most promising technologies that can replace traditional production methods in the near future. metal 3D printers are already appearing today in industrial plants, construction sites, design offices and other industries.

Industrial Metal 3D Printers are the product of the most technologically sophisticated Additive Manufacturing business . Attempts to 3D print metal were made in the early stages of 3D printing, and over the past decade have made a tremendous leap in this direction.

Technologies

With the advent of metal 3D printers , the hegemony of traditional technologies was somewhat shaken, but a decade ago, few believed in the possibility of printing, and few imagined that the question of a comprehensive replacement of technologies and means of creating products in metallurgical production would arise .

Today the situation has changed radically. The technology used in the best 3D metal printers has already proven its effectiveness.

Selective Laser Melting (SLM)

This technology allows you to create objects of any geometric shape from metal powder. The principle is based on the ability to create metal models by layer-by-layer melting of powders of various metals and alloys. Such materials include titanium, stainless and tool steels, chromium and alloys, as well as other raw materials.

Machines using SLM technology, such as SLM 280HL and Realizer SLM 250, allow you to create high-precision metal parts of any complexity and geometry directly from a digital model. This technology is excellent for manufacturing high-precision parts and assemblies of various designs. At the same time, 3D printers based on SLM technology provide a huge performance and cost advantage over traditional metal fabrication technologies.

Benefits of

Talking about the prospects of 3D printing with metal can take a long time, but initially it is worth considering in more detail what a modern metal 3D printer is like. Until two decades ago, mold casting was seen as the only cost-effective way to make 3D products. Years passed before the metal 3D printer appeared, capable of competing with, and in the future, replacing traditional methods of metal production.

So, what are the advantages of 3D printing with metal compared to standard production methods?

1. More complex shapes and designs.

Additive technologies give you more design freedom. 3D printing is able to produce much more complex products than the longer standard process can offer. metal 3D printers can create components with pits, cavities, thin walls and closed objects.

2. Low cost.

3D Printer metal printing process does not require any additional tools. Therefore, it is easy to replace the complex and expensive processes of stamping, mold casting. This will not only reduce costs, but also free up funds for the further development of the enterprise.

industrial metal 3D printers create products using less kW of energy and generating much less waste. It also reduces costs and eliminates the need to install environmentally friendly equipment.

3. Any combination of materials.

Metal printing technologies allow the use of any combination of powder materials for the needs of the automotive and aircraft industries, the space industry, as well as other types of production. Mixing of various materials based on titanium, nickel and aluminum, as well as various alloys, makes it possible to obtain new components and assemblies in terms of their thermal conductivity, electrical conductivity and other characteristics.

Application examples

Enhancement 9The 0007 industrial metal 3D printer has enabled these machines to replace entire sectors of traditional manufacturing.

For example, thanks to the SLM 500 HL 3D printer, NASA specialists successfully tested titanium nozzles for rocket engines, and a few weeks ago, Elon Musk, the head of the private space company SpaceX, presented the new Dragon v2 orbiter, which also uses engines with 3D printed parts.

What if a tragedy happened to a person and some tissues cannot be restored? 3D printing can carry out prosthetic surgery. For example, the Swedish company Acam, using a Realizer SLM 250 metal 3D printer, creates monolithic metal products, including titanium. Titanium orthopedic prostheses have become one of the most sought-after products, and their number has already exceeded thirty thousand copies.

In addition, 3D printed limbs can compete with high-tech designs, but cost ten times less.

Selection of equipment

Globatek.3D is the official dealer in Russia of the best manufacturers of 3D equipment. The company represents world famous brands: 3DSystems, SLM Solutions, Realizer, Artec, Creaform, Solutionix. The equipment of these manufacturers reliably serves in various areas of human activity: from medical laboratories to industrial production.

Globatek.3D provides delivery, setup and efficient operation of equipment. If you need advice on choosing a 3D printer, call +7 (495) 646-15-33 and our experts will answer all your questions.

how metal printing works on a 3D printer

Content:

1. Metal printing on a 3D printer
2. How 3D technologies work
3. Two basic methods
4. Video

Metal printing on a 3D printer (two main technologies)

The introduction of innovative technologies opens up new opportunities in various fields of human activity. A modern 3D printer for printing on metal allows you to print high-precision structural elements that are in demand in the space, engineering, and aviation industries.

How 3D technology works

3D parts are produced using different metal powder melting methods (using a laser). But the basic principle of operation remains unchanged, so any 3D printer prints with metal in several stages, these are:

• filling the build chamber with an inert gas to minimize the oxidation of the starting material;
• heating to the temperature required for the production process.
• distribution of powder over the surface of the build platform;
• 3D scanning of the cross section of the starting material with a laser beam;
• melting and sintering of particles, which allows to obtain a hard layer;
• shift of the platform by the value of the obtained layer for applying the next one (until the object formation is completed).

The moment the metal laser 3D printer completes the process, the product is completely covered in powder. Therefore, until the chamber cools down completely (to avoid deformations), the object on the platform is fixed by the support area.

Two basic methods

A modern metal 3D printer can use one of the two most common technologies - selective laser beam melting (SLM) or direct laser sintering (DMLS). Among the main differences between the methods, the principle of gluing the component should be mentioned:

• SLM - occurs as a result of complete melting of the powder;
• DMLS - individual particles are sintered (at lower temperatures compared to SLM) without passing into a liquid substance.

Unlike traditional casting or stamping, DMLS allows you to print objects without internal stress. This ensures good technical characteristics of the parts. Today, manufacturers offer models that can use several melting options at once.

Among other techniques for bonding powder particles, mention should be made of the UAM (additive ultrasonic) or EBM (electron beam) melting process.

---

Learn more

•
  3D printer 2 colors
•
  Best cheap 3d printer 2023
•
  Toothless dragon 3d print
•
  3D printed lamps
•
  The 3d printing handbook epub
•
  Silver surfer 3d print
•
  3D printer lower
•
  3D food printer youtube
•
  Easythreed 3d printer
•
  Mandalorian 3d print model
•
  3D print ghost
