print your photos in 3D! - qbed

Detailed instructions for 3D printing of lithophanes

3D printed lithophane from kraftly.com

Modern 3D printers allow you to create many original and unique things, and one of them is 3D photo-lithophanes, which are gaining more and more popularity as a customized gift for loved ones or just an original product for sale. Let's take a look at what linophane is and how to print it.

Article content:

What is lithophane?
Designing a lithophane
Selecting a photo
Converting a photo into a 3D model
Creating and printing a 3D model of a lithophane in Photoshop
How to slice a lithophane?
Seal of lithophane

What is lithophane?

Classic lithophane is a three-dimensional image on thin translucent porcelain that can only be seen when illuminated from behind by a bright light source (such as the sun or an ordinary light bulb). The image will appear in gray tones. Traditionally, lithophanes were created in several stages: first, the image was cut out of wax, then, based on the wax model, a mold was created from plaster, into which porcelain was cast, after which the image was fired.

German lithophane of the 19th century, on the left - without illumination, on the right - with illumination. Photo — Diego Verger

The first lithophanes appeared almost simultaneously in several cities of Europe — France, Germany, Prussia and England — at the end of 1820s and their three-dimensionality was strikingly different from the two-dimensional engravings popular at that time and daguerreotypes . The fact is that the quality and quantity of light interacting with lithophane significantly changes the characteristics of the image itself - such dynamism arouses great interest in the viewer. For example, lithophane inserts in windows change their appearance throughout the day depending on the quality and intensity of the sun's rays.

Modern 3D printers allow you to print lithophane from any high contrast photo. How? Varying the thickness of different sections of the 3D model to render different shades of gray when the lithophane is backlit: thin sections let in more light and look brighter, while dense parts of the print let in little light and create dark details in the image. Don't panic, you don't have to manually calculate the thickness of various sections of the digital model - there are many programs that create 3D models for lithophanes automatically and for free! Let's get down to business!

Back to Contents

Designing the Litophane

First we need to create a digital model of the lithophane.

Choosing a photo

The first step to a great printout is choosing a suitable photo , because not all images will look good in the form of a lithophane.

Firstly, the finished lithophane will be displayed in grayscale, so images where color plays an important role or where there is a lot of color detail will not work. You can try to convert the photo to b / w in Photoshop or any other program to make sure that you like the picture even if there are no colors.
Secondly, it is better to give preference to contrasting photos - so the printed linofan will look more interesting (unlike the image, where adjacent details will merge due to lack of contrast). Again, you can add contrast to the selected photo in Photoshop or any other program.

An example of a low-contrast image, not quite suitable for lithophane printing. Photo — Christina Ryumina

Thirdly, avoid photos consisting only of small details , it can be difficult for the printer to print them. For lithophanes, images with large contrasting details, such as portraits, are more suitable. Images with a single-color background without details are also good, for example, portraits against a backdrop or against a clear sky. You can clean up the background or create a color fill instead of an existing background in Photoshop or any other program.

Contrast photo on a plain background is ideal for printing lithophane. You can further clean up the background and add photo contrast in any post-processing program. Photo — Christina Ryumina

An example photo with lots of detail is not the best choice for creating a lithophane. Photo — Christina Ryumina

Of course, you don't have to follow these tips. If you print on a high-quality printer with high resolution, then you can handle any details! For example, SLA printers allow you to print smaller details than their FDM counterparts (read more about 3D printing methods here), so a photo for printing on an SLA printer may contain small elements.

Convert photo to 3D model

0011

You can convert photo with free online Image to Litophane converter.
Models for lithophanes can be created in Photoshop CC by downloading a special Operation (Action) from the official website (read detailed instructions below), or in Blender: these programs have more options to edit the model. It is worth considering that a subscription to Photoshop CC is paid.
Cura software (version 13.11 and higher) from Ultimaker will also work. The program is easy to use and allows you to smooth the model, but it does not have the ability to edit the image and create a frame around it.
You can use the Customizable Lithopane from printer manufacturer MakerBot on Thingeverse. Here you can add a hole in the frame of the lithophane so you can hang your masterpiece, but in this application your photo resolution will be compressed to 100x100 pixels. Another disadvantage: the application can be quite slow, because the Thingeverse website Customizer creates a model and STL file instead of your computer.
There is also a free 2D to STL converter for Windows. There are options for smoothing the model, but no way to edit the image.
You can create a model for lithophane in a paid Photo to Stereolithographic file converter. This program allows you to create lithophanes on spheres, cubes and other shapes, but the interface here is not the most understandable.
There is a nice free Portuguese converter where the language can be changed to English after installation by going to the Iniciar menu, then Idioma and finally selecting English. Here is a link to download the program. In this converter, you can create a frame for the image, edit it before creating a 3D model, and also enlarge / reduce the image. The converter generates models quite quickly, so you can experiment with 3D model settings until you are completely satisfied with the result.

The list of programs, of course, is not exhaustive. You can use any converters of 2D files to 3D models that support export to STL. In this article, we will be using Photoshop CC to create a 3D model from a photo.

Create and print a 3D model of Lithophan in Photoshop

Attention! The operation only works if the interface language in your Photoshop CC is English. You can change the language by going to menu Photoshop CC → Preferences → Interface.

To add an action in Photoshop, go to the program, go to the top menu in Window → Actions or click the icon Play in the side menu (see screenshot below).

Going into the Actions panel in Photoshop

Opening the operations panel, click on the menu icon (see screenshot below) and select the command "Load Actions. .." . We go to the location where your downloaded Lithophane folder and the operation "Make Lithophane.atn" are located and select it. The operation is now available in your Photoshop.

Loading the operation "Make Lithophane.atn"

Operation "Make Lithophane.atn" is ready to go

Open the image you are about to print. You can convert it to black and white, add contrast and make any changes, then print the visible layers into one by pressing Ctrl + Shift + Alt + E (English), or simply merge the layers through the menu Layers (in any case , you will be prompted to merge layers when starting the operation). In the layers panel (marked in blue in the screenshot below), select the layer with the final version of your image and name it Background (or select the Background itself directly if you haven't changed anything). Then open the "Make Lithophane" operation folder, select "Make 100mm x 6.25mm Lithophane" (marked in red in the screenshot), press Play (marked in green in the screenshot). The operation automatically converts the 2D image into a 3D printable object: Photoshop converts the image to Grayscale, inverts the tones, creates a 3D depth map, as well as a frame and a flat surface on the back of the image.

Starting the operation of creating a digital model of lithophane

Litophane in Photoshop CC

To print a 3D object, click on the top menu 3D → 3D Print (marked in red in the screenshot below) or click on the print icon (marked in pink). Next, you will see the 3D printing settings panel (see screenshot below). Select a printer (or specify Printer: STL File if you want to export the model as STL), set Printer Units , Detail Level . Determine the size of the model by setting the X / Y / Z values. Option Scale to Print Volume will create the largest printout that will fit in your printer's camera.

Click on the icon marked in green in the screenshot below to have Photoshop prepare your model for printing. Photoshop will analyze the object and show you a print preview with supports in a new window (supports are turned on and off by ticking Scaffolding ). From the same window, we can print or export the model.

Preparing the model for printing/exporting

Model

print/export window

Do not forget that the size and thickness of the lithophane, as well as the amount of detail in the photo and model, affect the printing time. Depending on these settings, it may take 30 minutes or 5 hours to print.

How to slice lithophane?

The slicer will help convert our model into a printer-friendly G-code (read more here). To open a 3D model in a slicer, you need to export it as a STL file. To do this, in the Photoshop 3D printing settings panel, select Printer: STL File , export the model as described above, and open it in your slicer to set up the location of the model on the platform and set other parameters. You can also export photos to STL from any of the other converters mentioned above and then open the file in a slicer.

To achieve optimal printing results, it is recommended to slice the lithophanes as follows:

Set straight infill to 100% at an angle of 30-35°. 100% infill will provide the best quality lithophane, as there will be no honeycomb inside the layers, which will spoil the tones in the printout.
Set the minimum layer height that your printer supports. This way you will ensure high resolution details and the maximum number of shades of gray in your lithophane.
Print as slowly as possible. Speaking of FDM, slow printing will help you avoid retraction problems, because most of the print is created with little extrusion, which can provoke a huge amount of retraction. To prevent your printer from smearing your printouts with unwanted material smudges and your extruder from clogging due to fast retractions, it is best to print as slowly as possible.
Select the optimal lithophane slicing parameters available in your slicer. Different slicers provide different options. Choose the slicer you like, however, be aware that some slicers take longer to layer the model than others, for example, Cura usually slices faster than Slic3r. Experiment!
Do not scale the model in the slicer. The model should be scaled in Photoshop or other converters mentioned so as not to lose resolution when printing.

Litophane Printing

Now it's to load our STL file into the printer via USB or SD card (or whatever methods are available on your printer). The faster the connection, the better, since lithophanes can contain a lot of detail, and some types of connection may not be fast enough to send the entire G-code to the printer, and the printer will begin to slow down and smear material on the printout.

Make sure your printer platform is in good condition to avoid warping your printout. Be sure to check the printer calibration and set the correct print temperature to match the melting temperature of the selected material.

It is best to use white material for printing, as colored materials will not give the same strong lithophane effect. Printing lithophane is best with ABS or HIPS, avoiding PLA : If you are going to put lithophane on a window, then PLA can melt in the sun.

Soft light is ideal for illuminating lithophane. Lithophanes make excellent lamps and even lanterns.

Lithophane lamp. Original photo here

Lantern-lithophane. Original photo here

Back to Contents

Gallery

What 3D Printing Can Do

WATCH

Glossary

3D Modeling and Additive Manufacturing Terms

WATCH

DIYK. May 11, 2018 10 Comments

0 Likes

Lithophany: what is it and how to make it with 3D printing

This strange name hides a very beautiful way of depicting art. In , lithophany is gaining more and more followers of in the world of fabricators and 3D printing. With it, you can print all sorts of scenes, personal photos, drawings, shapes, and whatever comes to mind.

If you are interested in learning more about this method of creating art with lithography, in this article you will learn what it is, how it differs from other techniques such as lithography, and how you can start creating your own designs with Print 3D.

Index

1 What is lithophany?
- 1.1 Lithophany vs. lithography: the differences
2 How to make lithophany with a 3D printer

What is lithophany?

La lithophany is a type of projection of images and forms using light. Previously, the light of fire, sunlight or candles was used. Light bulbs are currently being used. In either case, the light source will pass through the sheet with a series of translucent silkscreens to form the image.

The idea is to have different thicknesses of foil so that the light varies in opacity, making some areas darker and others more original. The result is really beautiful, especially when used as four to decorate a room, or as a lamp for a bedroom, children's room, etc.

Originally this engraving is it was modeled in wax . Then other materials began to be used, for example, porcelain. Many other materials can now be used, such as polyamide resins or 3D printer plastics.

In the nineteenth century This method became popular in countries such as Germany and France, and later spread throughout Europe. Many point to Baron Burging as its creator, and if you want to know more about his history, you should know that there is an entire museum dedicated to this art in Toledo, Ohio (USA), the Blair Lithophany Museum.

Lithophany vs. lithography: differences

Some people confuse lithophany with lithography , but they are not the same. Lithography is an old form of printing (still in use today) that allows shapes or images to be printed on stones or other types of materials in a flat form. Actually, its name came from there, starting with lithos (stone) and graphe (drawing).

With this technique, you could duplicate art pieces and also had a wide range of applications in the world of printing, where lithographs are still used for printing.

Instead, lithography uses lithography or 3D printing of to be able to create the thickest and most opaque areas, as well as the thinnest and most translucent. But to achieve the result, this technique needs light.

How to make a lithophany with a 3D printer

To be able to create your own lithophany, you do not need to have any skills in art or drawing, you only need one 3D printer, filament, PC with appropriate software and image. you want to represent. Not much more...

As for the software for to generate lithophany , you can use several of them to convert the image into a lithophany-friendly design and into a 3D printing stratifier. For example, you can use a web application that can be used on any operating system with a compatible web browser.

This application is called 3Dp and you can access this link. Once you have accessed this web application, you must follow these steps:

Click on Photos and select the image you want to convert to lithophany.
Once the image is uploaded, now in Model select the model you like best and click "Update" to update it.
Now go to tab Settings . You will see several options:
- Model Settings : Set the model to your liking.
  - Maximum size (mm) : will be the size of the lithophany.
  - Thickness (mm): with this parameter you play with the sheet thickness. Don't make it too thin or it will be too brittle.
  - Border (MM): the ability to create a border on a sheet or in a frame. If you do not want, set the value to 0.
  - Thinnest layer (mm): you play with the pixel thickness of the photo so that more or less light passes through the thinnest areas.
  - Vector per pixel: The higher it is, the better the resolution, but there is a risk that if it is too high, the detail will fail. You can leave this after about 5.
  - Base/Stand Depth: It creates a base in sheet for support, although if you are making a different shape, such as a round sheet, you don't need that base to stand.
  - Curve: this will create more curvature in the sheet. You can even set it to 360º to make it cylindrical. Ideal choice for lamps.
- Image settings : Adjust the image according to the model.
  - Positive Image/Negative Image: It is used to make the photo stand out or face inward as you wish. That is the direction of the relief.
  - Mirror off / Mirror on: Creates a mirror effect.
  - Flip image off / Flip image on: you can flip the image.
  - Manual update / image click update: If you check it when you go to the model tab, it will update automatically.
  - Repeat X count: makes horizontal copies.
  - Repeat & Count: makes vertical copies.
  - Mirror Repeat Off / Mirror Repeat On: Apply a mirror effect.
  - Repeat Reflection Off / Repeat Reflection On: apply flip effect .
- Boot settings : where to configure the boot file.
  - Binary STL / ASCII STL: how the STL file is saved. You should choose the best binary.
  - Manual / Update : To download manually or every update. Personally, it's preferable to do it manually so that you download it when it's ready.
Edit with them your design until it is what you really want, depending on your case.
When everything is ready, click the Download button to download the STL.

Once you're done with that, it's time to import the STL for 3D Printer .
