Relativity's proprietary Factory of the Future centers on Stargate, the world’s largest metal 3D printers, that create Terran 1, the world’s first 3D printed rocket, and the first fully reusable, entirely 3D printed rocket, Terran R, from raw material to flight in 60 days. Relativity’s Stargate printers’ patented technology enables an entirely new value chain and innovative structural designs that make Terran 1 and Terran R possible. By developing its Factory of the Future and rockets together, Relativity accelerates its ability to improve design, production, quality, and speed.

Zero fixed tooling and radical part count reduction

LEARN ABOUT TERRAN

POWERING THE STARGATE PRINTER

METALLURGY

Relativity developed multiple proprietary alloys custom designed for 3D printing to meet mission-critical performance.

UNIFORMITY

Parts are inspected during and after printing to ensure they meet the highest standards of uniformity and quality.

THE FUTURE IS 3D PRINTED

For 60 years, aerospace manufacturing has relied on large factories, fixed tooling, complex supply chains, and extensive manual labor to build costly rockets comprised of 100,000+ parts in 2 years or longer.
