Can the final product (device) be printed on a 3D printer?
This year, using a 3D printer in an apartment, I designed a device (mechanism) for attaching a cable to a cable by wrapping it with wire.
This device is necessary for laying cables through large spans "by air". You can learn more about this mechanism in a series of videos:
SteelWorm (Part 1 - Business Case)
SteelWorm (Part 2 - Design and Features)
SteelWorm (Part 3 - Usage Example)
This article, as you might have guessed from the title, is not about that. Here I want to try to break the stereotype that 3D printed products cannot be reliable and usable by the end user. I will start with common questions that I get asked about my mechanism:
1. Plastic housing? It is fragile, the mechanism will quickly break.
Of course, on average plastic is less durable than metal. Although it is immediately worth noting here that there are a lot of types of plastics and metals! If, for example, we compare ABS plastic and steel grade Ct. 3, then steel will be about 5 times stronger, but 8 times heavier, so the simplest answer to this question is a counter-question:
Do you have an electric screwdriver, grinder or drill? What material is their body made of?
Of course it's plastic! No major manufacturer of tools and household appliances can do without plastic products.
I remind you that there are a lot of types of plastics! Each has its own physical and chemical properties, so for each specific case, the manufacturer chooses his own.
As a rule, 90% of ordinary people are eliminated after this question, but more knowledgeable ones make the following argument:
2. 3D printed plastic is less durable than the injection molded plastic used by most manufacturers!
Indeed, products printed on an FDM 3D printer without additional processing are less durable in one of the directions, unlike injection molded plastic.
I won’t write about 3D printing using the SLS method now, because it is not so common, and practically devoid of this drawback.
The diagram above shows the breaking strength of 3D printed hooks depending on the direction of the layers and the thickness of the printed layers. Test results taken from the CNC Kitchen channel (full video available at: https://youtu.be/fbSQvJJjw2Q)
It can be seen from the diagram that plastic can withstand 3 times less load across the layers.
In scientific terms, a product printed on a 3D printer is an anisotropic material, but this is not a reason to give up on it.
Wood is also an anisotropic material, but to this day houses are built from it, moreover, as part of the elements of load-bearing structures. Therefore, a design engineer who develops a mechanism must perform strength calculations and make sure that there is a sufficient margin of safety in all nodes. You also need to study the features of the material in advance and arrange the layers so that the loads act along them. If this is not possible, then it is necessary to use additional reinforcement with fiberglass or, as in my case, metal tubes.
It is important to note that at temperatures above 50℃, most plastics begin to lose their strength properties drastically; in the sun, black elements can easily heat up to this temperature, the calculations must be rechecked. Thin body elements first of all begin to deform from the effects of temperature, therefore it is better not to make walls thinner than 1.
6 mm, or it is necessary to strengthen them with stiffeners. If the device is used outdoors, attention should be paid to UV resistance and hygroscopicity so that the case does not become brittle under the influence of the sun and the shape of the product does not lead to moisture. In my project, I used PETG plastic, which is devoid of these shortcomings and can be used in the temperature range from -40 to +70℃.
As a result, if all the strength conditions are met and tests are carried out, then nothing prevents the use of products printed on a 3D printer in the final device.
3. If the parts on a 3D printer are strong enough and stable, why do large manufacturers still use casting or stamping?
Economic feasibility! It all depends on the circulation of products. If you need more than 100 cases, then it will be more profitable to make a mold and quickly cast a batch, and if less, then you already need to calculate the economy. Moreover, each product (detail) separately, because The cost of 3D printing, mold making and casting can vary greatly depending on the size and geometry of the part, as well as surface requirements and manufacturing precision.
I won't go into details of economic analysis now, and sometimes Customers don't need it. It is enough to request a quotation for the manufacture of parts in various organizations involved in casting or 3D printing. Good specialists will quickly estimate the cost of the product according to your 3D model and its circulation, all that remains is to choose the most profitable option.
4. Plastic gears wear out quickly and become unusable.
Another stereotype that leads to confusion. As I noted above, any node of the mechanism is subject to calculation: both strength and work resource. In household appliances, you can often find both plastic gears and metal gears, and even a combination of them. For example, in the figure below, the plastic gear of the Bosch MFM-45020 meat grinder.
Naturally, the greater the load on the gear (speed and torque) and the longer the duration of the load, the faster wear will occur. Accordingly, to reduce wear, the gear must be made larger, or rather, the engagement area should be increased, or a more durable material should be used.
The engagement area can be increased by:
- tooth modulus increase;
- gear width increase;
- helical gear application.
Unfortunately, there are no simplified methods for calculating the resource of plastic gears. In my model, I only performed a static strength analysis. When starting, the maximum force of 2.1 kg acts on the teeth for a short time, but even with this load, the safety margin for PETG plastic is 38 times!
Further, 99% of the operating time occurs with a load 12 times less, solely to overcome the friction force in the bearings, while the maximum rotation speed is 480 rpm. Therefore, we can say with confidence that under such loads, the gear train will last a very long time.
Nylon is considered the best material for plastic gear due to its strength and low surface friction.
From personal experience, if the operating temperature is not more than 50℃, then PLA gears perform well: it also has a low surface friction coefficient and high abrasion resistance.
Try to take a file and grind off a part of the PLA part and everything will immediately become clear.
5. Is the 3D printed case waterproof?
There is a standard for protecting the device against water and dust - IP. The case printed on a 3D printer can easily provide the maximum degree of protection of the IP69 standard, i.e. prevent dust from entering the case completely, ensure immersion in water to a depth of more than 1 meter for more than 30 minutes, and also withstand high pressure and high temperature water jets. You can get acquainted with the detailed decoding of the standard at the link: https://ru.wikipedia.org/wiki/IP_(envelope_protection_degree).
In many ways, the result depends on the literacy of the designer. For example, if you print the body of the product in 1 layer, then there can be no talk of any water permeability. And if you print a hollow cube 100x100mm with a 5mm wall thickness of nylon, it will provide IP69, but how do you put useful stuffing inside? Of course, the body must be collapsible! And this is how the parts of the body will be joined and fastened together - the task of the designer, and here I will share my experience:
I usually use screws and bolts to fasten the body parts together.
For reliable fixation, I developed the following rules:
1. Bolts and screws are used only with a flat head, i.e. not with a hidden head! Especially if the hole is made along the layers. Otherwise, when you tighten the hardware, the part may simply crack.
2. The holes for the screws must be made smaller than diameter D to engage the thread with the plastic:
If perpendicular to the layers - 0.89*D;
If parallel to the layers - 0.95*D;
If you do less, the screw will be hard to screw in and the plastic may break.
3. Holes for self-tapping screws must be made smaller than diameter D to engage the thread with plastic:
If perpendicular to layers 0.83*D
If parallel to layers 0.87*D
4. If you need a simple and strong connection of 2 large parts with a tight compression between them, then use the connection on bolts and flanges.
For free play of the bolt, the hole diameter must be increased by 0.
2mm.
5. To ensure that parts fit into each other, I use the following rule:
Fits (gaps) for "Plastic-Plastic" in 3D model:
• Loose (walks easily, dangles) - 0.3 mm;
• Medium (with little effort) - 0.2 mm;
• Thick (forced in) - 0.1 mm.
If the parts are large and the area of their contact is large (>5cm2), then it is desirable to increase the gaps.
"Plastic-metal", the same, just the gaps are 2 times smaller.
Unlike metal, plastic has large tolerances. As can be seen from the diagram above, this is due to the influx of layers. Therefore, in order to achieve the IP65 standard for a prefabricated printed case, it will be necessary to use rubber washers and gaskets, which can also be printed on a 3D printer from elastic filaments.
Conclusion
I hope the article turned out to be equally useful for Contractors and Customers. I tried to dispel the fears of Customers about products printed on a 3D printer, and I also shared my personal experience in designing cases, which means that this article should be useful for beginners in 3D printing.
Dear readers - Customers, I wish high-quality and responsible Contractors, whose products will be manufactured and reliably designed on time, and to Contractors - solvent and adequate Customers who have an idea about the pros and cons of 3D printing!
