Desktop 3D Printed Mold Enables Delicate Concrete Furniture - 3DPrint.com

There are countless applications for products and parts made with 3D printed molds, such as prosthetic aligners, microneedles and organ-on-a-chip devices, and even building restoration. Experimental design studio Slicelab, remotely based out of Denver and New York, specializes in digital fabrication, and offers design services in architecture and product/furniture design. Founded in 2012 by Arthur Azoulai and Diego Taccioli, the studio says that it operates “between the disciplines of art and architecture,” and has recently been researching the use of 3D printing in fabricating molds for complex concrete forms. This work resulted in a truly lovely piece of furniture called the Delicate Density Table.

Slicelab was attracted to 3D printing for this project because the technology has fewer limitations in terms of cost and time to design and create complex forms.

“A concrete exploration using 3D printed molds with a goal to see how delicate, detailed, and finite concrete can get while still being structurally rigid,” the studio wrote. “Using 3D printing as a new way to realize concrete through its ability to make molds, we have been interested in pushing the concretes’ natural limitation through fine geometries.”

Slicelab’s co-founders Arthur Azoulai and Diego Taccioli sitting at the Delicate Density Table

Concrete features a very compressive strength, but is more brittle when it’s used to create shapes with fine geometries that create a lot of tension loads. Additionally, the material also has the unique ability to take on any shape, while 3D printing has the ability to create complex geometries, and Slicelab saw the potential in combining the two to create a piece of furniture that had both density in material and a delicate form, while still maintaining the strength of the concrete. The studio partnered with Concreteworks and Hummingbird 3D for this project, which resulted in multiple unique molds that were then put together and used to make an 86 kg white concrete table with 152.5 x 45.5 x 38 cm dimensions.

The studio figured out the overall structure of the model ahead of time, through the use of digital simulation and optimization. This is when they realized that, due to the size of the table design and the build volume constraints of the LulzBot TAZ 3D printers they would be using, they would need to break the model down into 23 separate pieces.

Each of the 23 parts were oriented and optimized in a certain order so the least amount of supports would have to be used, which would help speed up assembly. The pieces were 3D printed out of recycled PLA, and then fastened together to make a single 5 ft. investment mold, which weighed about 66 lbs and was able to hold up under 200 lbs of non-reinforced super high-performance concrete.

“The order of which the pieces were assembled played a huge roll in how well the pieces aggregated together,” Slicelab explained. “Even with absolute printing precision, the plastic can crack, warp and often create uneven surfaces that require a lot of post-process work to fully function as a watertight mold for concrete especially when put onto a vibration surface. ”

The team created the mold with a built-in, leveled diamond platform on top, so it could be positioned upside down and flat when the concrete was poured inside, to ensure that most air bubbles would be on the bottom of the table and not visible from the top. This reinforcing platform also helped to keep the center of gravity low during pouring, and was also designed to be the only part released from the concrete in a single piece. Speaking of pouring concrete, the voids at the bottom of the mold were used to pour concrete into three major access points, down through the ten legs, and into the main cavity of the bench.

Once the concrete had completely cured inside, the mold was literally broken off piece by piece to reveal the final Delicate Density Table. Slicelab then used diamond pad wet sanding to get a mirror-like finish, which also really emphasized the fluid form of the top of the table—a major contrast to the porous texturing on the table legs.

Since we’re all about sustainability here in the AM industry, it’s nice to know that the team also saved as many of the broken pieces of the mold as possible, so they can be used at a later date for a different project.

(Source/Images: Slicelab)

Stay up-to-date on all the latest news from the 3D printing industry and receive information and offers from third party vendors.

Tagged with: 3d printed furniture • 3d printed mold • 3d printed table • 3d printing molds • concrete • concrete furniture • design studio • Investment Molding • Lulzbot TAZ 3D printer • mold making • pla • Slicelab

Please enable JavaScript to view the comments powered by Disqus.

Printing molds for concrete - 3D Printing - Talk Manufacturing

aaronpaulsmith

#1

Hello

I’m looking at doing a few concrete home projects, i’ll like to get some molds printed that can be used to cast concrete and be re-used multiple times.

I would like the finish of the concrete casts to be smooth and potentially quite detailed, i’m looking at producing things like, pendants, vases, bowls, plates etc.

i’m guessing it should be some sort of rubber/silicone but not sure of the type of printers I should be looking for.

Preferably a printer in the london area would be best but happy to use any location really providing delivery is offered.

Thanks

5 Likes

metaobjects

#2

Hi Aaron, we’re based in London and able to create high detail RTV silicon molds. We’ve not tried casting concrete ourselves but we’ve read it works well https://www.youtube.com/watch?v=TYhOso98N_k

We can also supply 3D printed templates if you’d prefer to pour the silicon yourself.

What size molds are you looking to create?

aaronpaulsmith

#3

My model size is

The 3d model i have made is actually a mold and made of 3 pieces, you mention a template above what exactly do you mean by this, would that actually require me to model the actual object rather than the mold?

I uploaded my model to 3dhubs to today to get a idea of prices, i have either misjudged 3d printing costs or my model is incorrect getting prices in excess of €10000 does that seem right?

metaobjects

#4

The dimensions haven’t come through, if you can give a rough width / height / depth then I can tell you if it’ll be possible for us to print, as if it’s within our max. printable size then it’ll cost a lot less than that! We can supply silicon molds of the exact models you provide so don’t worry about having to adjust the model. Thanks, Andrew

aaronpaulsmith

#5

the object is around 25 cm high, 15 cm wide and deep, what would be the limits I should keep within to keep costs down?

metaobjects

#6

Yeah that’s likely too big for our printer as the largest single piece we can create is 16x12x12 cm, and even then the resin material we use is more expensive than FDM so large parts get expensive quickly.

It might be possible to optimise the mold, if you’re able to send the original shape to us then I can have a look at it and let you know how feasible it is

flowalistik

#7

Yesterday I talked with a friend about concrete casting, and today I see this post. Any info or progress please share it!

I know Vangrei, tthey do concrete objects, but I don’t know if they cast it using 3D printers in the process or if it’s just a different method.

aaronpaulsmith

#8

Hi andrew, been busy ilk try and get that model to you later in the week. Thanks

Gaffanon

#9

Having cast concrete while silicone molds are great they are expensive you might want to consider a Urethane mold rubber instead less cost and some are made with mold release in the rubber already such as Renyolds Reoflex 30 or 40 wet. they will last a very long time and at a third the cost of silicone

aaronpaulsmith

#10

Thanks for the tip
