BIG-60 V3 PRINTER ASSEMBLY KIT

• See a full packing list here.
• Modix Griffin Print Head
• Modix Clog Detector
• Modix Z Crash Detector
•  Modix PT-1000 High-Temperature Sensor

ACCESSORIES

• Allen Key Set
• 7mm Nozzle Wrench
• Thin Oil - 20cc
• Zip Ties (100)

Modix BIG-60 V3 Kit Technical Specifications

What are the Dimensions for the BIG-60 V3?

• Build Volume: 600mm x 600mm x 660mm / ~23in x 23in x 25in

• Assembled Dimensions (with enclosure): 906mm x 1,060mm x 1,356 mm / 35.6in x 41.7in x 53.4 inch

• Shipping Weight: 120 kg (265 lbs)

What are the Modix BIG-60 V3's printer properties?

• Technology FFF: Fused Filament Fabrication

• Assembly: Self-Assembly

• Closed print chamber: Optional add-on

• Enclosure type (Optional): Aluminum composite panels (ACP), 3mm thick. Polycarbonate doors and top lid

• Feet: Articulated leveling feet included (casters optional add-on)

PRINT HEAD:

• Number of print heads: One print head is included, (optional secondary print head add-on)

• Default filament diameter: 1.75mm, can be converted to 3mm by the user

• Extruder brand & model: E3D Aero Extruder (direct drive)

• Hotend brand & model: Modix Griffin Printhead ; Secondary Griffin Printhead (Optional)

• Included nozzles (mm): 0.4mm, 0.6mm, 0.8mm for Primary hotend 0.4 for Secondary hotend

• Hotend max. temperature: 500ºc

• Extruder motors: Motech MT-1703HS168A Direct drive extruders gear reduction of 1:3

• Filament runout sensor: Dedicated sensor per extruder

MOTION:

• X & Y axis linear guides: HIWIN MGW9

• Z axis guides: Smooth Rods included. 2

PRINT BED:

• Bed plate: Alcoa Mic-6, 6.35mm milled cast aluminum plate

• Number of heaters: AC heater, 1,350 Watt , dual zone

• Temperature controller: Autonics TCN4 PID controller

• Maximum bed temperature: 120ºC

• Bed leveling probe: BL touch probe

• Bed leveling: Bed shape is measured by probing 100 different points.

• Bed tilt leveling: Semi-Automatic, guided by an on-screen macro

• Bed motion system: 4 x ball-nut screws. Each screw is mounted to a dedicated stepper motor with a belt gear system

ELECTRONICS:

• Electronic controller: Duet3D: Duet2 Wifi

• User interface: 7” Touch screen – PanelDue from Duet3D

• Remote control (WiFi): Upload Gcode files right from your desktop

• Direct connectivity: SD Card, USB cable

• Ethernet: Optional with Duet3D Ethernet board. Should be purchased and replaced by customer

• Electronics (DC) power: Meanwell 24V/280Watt power supply powering the electronic and motion system. Universal AC input: 110-230V, 50/60 Hz

• Bed heaters (AC) power: Direct AC feed, 1370W Silicone pad heater. Two versions are available: 110V and 230V. We supply according to shipping destination. Power requirement for bed heater in North America is a dedicated 15A outlet.

• AC power cords: We supply the required AC cords for each country

What is the Software for the Modix BIG-60 V3?

• Operating System Compatibility: GNU/Linux, Mac, Windows
• Recommended Software: MatterControl, Cura, PrusaSlicer
• Firmware: RepRapFirmware
• Supported File Types: .stl
• Printable Formats: Gcode

FAQ:

1. How long will it take for my purchase from MatterHackers to be shipped?
   • Items purchased from MatterHackers will be shipped from the manufacturer's US-based warehouse. There may be a lead time on orders, depending on stock availability.
2. Can I return a 3D printer kit if it has been opened?
   • Returns will not be accepted for any opened 3D printer kit. New, unopened 3D printer kits may be returned within 30 days of purchase.
3. What kind of support does MatterHackers provide for warranty replacement components?
   • MatterHackers provides support for warranty replacement components. Assembly instruction, troubleshooting, and technical support are provided directly by the Modix Support team.

Create functional plastic items up to 2.5 meters!

Learn more

Discovery 3D Printer is a range of industrial 3D printers made in Spain for creating large-sized products and prototypes using FFF/FDM technology.

Discovery 3D Printer additive machines produce objects from high-strength thermoplastics and are designed for industries ranging from shipbuilding and automotive to architecture and medicine.

Problems solved

Replacement of spare parts or lost parts in engineering, shipbuilding, oil and gas and energy enterprises

Production of small and medium series of products as an alternative to injection or molding of plastic parts automotive, shipbuilding and oil and gas industries

Creation of objects of exterior and interior design and design products for construction, production of facing materials

Production of functional prototypes for R&D and design bureaus in mechanical engineering, shipbuilding and aircraft construction

Production of large-sized wax or burnt master models for metal casting and metallurgy or trolleys)

Looking for a 3D printer for your needs?

Leave a request for a personal consultation!

Solutions catalog

3D printers

3D printer DISCOVERY 3D Printer 2021

Compact solution for 3D printing of large-sized products

Read more

3D printer Super Discovery Compact

Combination of compactness and high performance of the performance

Learn more

Super Discovery 3D Printer Hybrid

Advantages of granule and filament printing in one machine

More details

Super Discovery 3D Printer 3D Printer

Large build chamber and print speed up to 6 kg/h

More details

Super Discovery 3D Printer Workstation 3D Printer

3D large format printer combination: unique 2 in 1 combination and milling systems

More details

Your unique 3D printer

Do you need to print a product larger than 6 meters?

We will develop an individual solution with any build chamber for your needs. tasks - for printing products of any size!

Choose the right solution for you - compare specifications by model

Compare 3D Printer

Solutions catalog

3D Printing Consumables

Do you have questions about 3D printing media?
Set them to our experts online!

Discovery 3D Printers work with all thermoplastics, including:

PLA / PLA

biodegradable polymer provides a smooth and gliding surface products. Designed to obtain detailed and ready-to-use objects

ABS / acrylonitrile butadiene styrene

impact-resistant material is able to withstand heavy loads and high temperature, resistant to heat, moisture and various alkalis

PET / polyethylene terephthalate

is a hard and strong material with high abrasion resistance. Excellent suitable for making gears, carriages and guides

PA / polyamide

hard engineering plastic with excellent mechanical properties characteristics. Widely used in various industries

ASA / acrylonitrile styrene acrylate plastic

analogue of ABS, characterized by increased weather resistance, minimal shrinkage and high impact strength

Nylon

is elastic, wear-resistant and remarkably durable. Good suitable for printing functional parts and mechanisms

HIPS / polystyrene

Lightweight, alkali and acid resistant polymer. deserved popular in traditional manufacturing due to its impact resistance

Advantages of Discovery 3D Printer Solutions

ISO 9001 certified products

3D printers with the largest build chamber in the world

Ability to design a custom printer

The only 3D printer on the market with an integrated CNC system for finishing milling a part after printing

Accelerate the creation of new products thanks to the dual extrusion system

Repair and replacement of products faster and more economically than contractors

Ability to use a large number of third-party materials

Self-leveling platform function for automatic compensation of irregularities

Case Studies

FDM Airbus Spare Parts 3D Printing

Created a strong mold for autoclave forming parts with a sealed surface and a low thermal expansion coefficient.

3D printed car bumper

Prototype car bumper printed, measuring 1800 x 600 x 4500 mm and weighing 12 kg.

Large format 3D printed chair

Printed design armchair measuring 45 x 50 x 95 cm and weighing 18 kg.

3D printed architectural statue

The solid statue is printed and is 1. 87 m high and 45 kg in weight.

3D printing of railway components

The front part of a tram for CAF was made in one printing session.

Helicopter seat 3D printing

Printed helicopter seat measuring 120 x 70 x 45 cm and weighing 20 kg.

3D printed internal combustion engine

Prototype of an internal combustion engine was created, the dimensions of which were 100 x 60 x 50 cm and the weight was 5. 5 kg.

3D printed exclusive piece of furniture

A custom and exclusive chair created without the need for any further finishing.

Architectural 3D printed in durable ABS with cellulose

A street sculpture has been made that fully implements the initial decorative idea of ​​the project.

Dior boutique window dressing

Huge bottles 3D printed for exclusive display at Dior's flagship stores.

FDM Cap Prototype

Prototype cap printed at 29 x 19 x 4.5 cm and weighing 146 g. Shipbuilding Equipment: Super Discovery 3D Printer Material: fireproof ABS

A prototype of a modular toilet has been printed, measuring 2200 x 1700 x 1200 mm and weighing 250 kg. At the same time, the weight of the product was reduced by almost 50%.

3D printed marine ventilation grille

Ventilation grill printed 59 x 89 x 4. 5 cm and weight 3500 g. Automotive Equipment: Discovery 3D Printer 2021 Material: PACF

Printed motorcycle part measuring 42.5 x 16.5 x 4.5 cm and weighing 165 g. Instrumentation Equipment: Discovery 3D Printer 2021 Material: ABS HI

Prototype printed with support measuring 10 x 9 x 2.5 cm and weighing 18 g. Instrumentation Equipment: Discovery 3D Printer 2021 Material: fireproof ABS

Created a square mold that measures 10 x 10 x 2 cm and weighs 67 g. Automotive Equipment: Discovery 3D Printer 2021 Material: E.P.

Printed fender for a wheel measuring 55 x 16 x 20 cm and weighing 645 g. Energy Equipment: Super Discovery 3D Printer Workstation Material: ABS with carbon fiber

3D printed and post-processed high-strength mold for wind turbine blades.

3D printed car wheel

A wheel for a car was made, the diameter of which was 440 mm, and the weight of the product was 5 kg.

3D printed designer vase

Printed vase in ABS for excellent interlayer adhesion and minimal warping.

Geometric 3D printing

Pyramid printed with an 8mm extruder with a smooth surface thanks to the built-in milling system.

More projects and examples of 3D printing in production - in the blog 3D experts

Go to blog

Useful materials

Webinar on 3D printing large objects with complex geometry

• How can 3D printing help you optimize production?
• Features FDM-technology for printing products up to 2. 5 meters
• Benefits of using 3D plastic printing
• Real cases

Large Format Plastic 3D Industrial Printing Brochure

Benefits of FDM Technology, Overview of Equipment and Consumables, industries and implementation examples - this and much more in one material!

About the manufacturer

CNC Barcenas / Spain

is one of the leaders in the European market for large format 3D printing.

The company specializes in the production of industrial 3D printers Discovery 3D Printer for printing large-sized products and prototypes based on FFF/FDM technology.

discovery3dprinter.com

Take a closer look at Discovery 3D Printer solutions - take a virtual tour of companies!

3D TOUR OF COMPANY

About us

iQB Technologies is a Russian distributor of 3D printers, consumables, 3D scanners and software from the world's leading manufacturers.

We develop complete 3D solutions, provide printing services and scanning, as well as training specialists in the use of 3D technologies in their work.

iQB Technologies is the exclusive distributor of Discovery 3D Printer solutions in Russia.
3D printers are available for order
in this section .

iqb.ru

Why order a 3D printer from iQB Technology?

The best prices for this class of equipment

Training on how to use 3D printers

A wide range of integrated solutions: 3D printer + 3D scanner + software

Provision of services for the implementation, maintenance and repair of 3D equipment throughout Russia

Participation in public procurement and tenders

Still have questions?

Our experts will advise you free of charge on Discovery 3D Printer solutions

Frequently Asked Questions

Which technology to choose: the method of fusing granules (FGF) or polymer filaments (FFF / FDM)?

What are the kinematics and mechanics of the Discovery equipment?

In this respect, all Discovery equipment differs from budget additive solutions. The products are based on the kinematic diagram of a CNC machine. Gears, pulleys, lead screws, no belts. HIVIN rail guides are used. The entire structure is made with European quality from advanced products in the machine tool industry.

What consumables can be used with Discovery products?

Any material (other than PEEK and PEKK) sold in bars or pellets. First of all, thanks to the heating of the table to 175 ° C and vacuum fixation, as well as due to the installed nozzles made of hardened steel.

How is such a large print platform heated?

A matrix of separate equidistant heaters is built into the platform from the bottom side; these modules provide uniform heating of the surface of the printing platform. The maximum recorded temperature difference over the entire area is 3°C.

How to speed up printing on such large dimensions?

There is a special method for properly emptying the internal volume, which you can learn more about from our technical experts. This procedure will have very little effect on the strength and elasticity of the print object, but will still reduce the time by up to 60%.
It is important to consider that with a large range of large-sized products, it is better to consider Super Discovery 3D Printer or Super Discovery 3D Printer Workstation with a capacity of up to 11 kg / h (depending on the material used).

Is it possible to upgrade this equipment for a specific enterprise?

Yes. Most of the Discovery machines can be upgraded for a specific production project. This is possible, since the equipment was designed for the tasks of Production 4.0, and our specialists will help to integrate it correctly.

What is the warranty for this equipment?

24 months, which is 1.5 - 2 times more than analogues from Europe, Russia and China. Permanent customer support is provided directly by the vendor or iQB Technologies specialists.

How to get a high quality product so that it can be handed over as a final product?

3D printing is basically a high quality preform process. If you need to get the final product, it is suggested to use milling or turning equipment, manual machining, priming, painting or varnishing.
This is often not necessary as the product is not visible.

full name *

Company *

E-mail *

Telephone *

Message

Large format FDM printers Discovery 3D Printer

Rapid prototyping

Experts recommend

3D printers

Author: Semyon Popadiuk

Author: Semyon Popadiuk

Key Benefits of Discovery 3D Printer | Technology and features of the 3D printing process | Applications | Equipment line | Implementation History: FDM Printing for the Navy | Results: briefly

We are already seeing real examples incredible flexibility and efficiency of additive manufacturing in the context of the global economic crisis. Experts argue that the pandemic will bring the Fourth Industrial Revolution closer, and many businesses today see digital technologies as a means of survival, and not just to increase competitiveness in the market.

iQB Technologies continues to expand its product portfolio: in April 2020, our company became the exclusive distributor in Russia of Discovery 3D Printer industrial 3D printers from the Spanish manufacturer CNC Barcenas. For the first time, we present equipment for 3D printing of large-sized products and prototypes based on FFF/FDM technology.

CNC Barcenas is a rather young business: it is a little over ten years old. Since 2009, the company has been specializing in the production of CNC machines (milling, engraving and laser cutting), and in 2014 it expanded its capacity by starting the development, design and production of unique industrial 3D printers.

Bumper
Equipment: Super Discovery 3D Printer, material: ABS with carbon fiber, dimensions: 1800 x 600 x 4500 mm, weight: 12 kg

The first solution for the 3D printing market was the Discovery 3D Printer, followed by the even more innovative and large-format Super Discovery 3D Printer, based on the direct extrusion of polymer pellets. In 2019, the Super Discovery 3D Printer Workstation, an industrial 3D printing and post-processing system, was introduced. In 2021, an updated and improved modification of the Discovery 3D Printer 2021 was released, as well as the Super Discovery 3D Printer Compact and Hybrid models.

CNC Barcenas continues its pioneering work and is today one of the leaders in the European large format 3D printing market with many large scale projects to its credit.

Main advantages of Discovery 3D Printer

1. Much lower cost printers than competitors offering the same technology and quality.

2. Constant development of technologies and expansion of experience in the areas of 3D printing and machine tool building.

3. All equipment is completely designed and manufactured at CNC Barcenas facilities in Spain.

4. The ability to customize the printer for the tasks of each individual client.

5. The best drive and motor components for quality and fast printing.

6. Correction of irregularities during printing (calibration of nozzles and platform).

7. Debugging equipment up to 100% result.

8. The open material system allows a significant reduction in operating costs.

9. Internal cameras in printers that provide remote monitoring of the production process from any device.

10. Easy to operate hardware and intuitive Simplify 3D software.

Cover prototype
Equipment: Discovery 3D Printer, material: 3D850, dimensions: 29 x 19 x 4. 5 cm, weight: 146 g

Technology and features of the 3D printing process

The FFF (Fused Filament Fabrication) technology used in Discovery 3D Printers is a complete analogue of FDM (Fused Deposition Modeling - layer-by-layer deposition modeling). This is the most accessible and popular additive technology, it is familiar to all users of home 3D printers, but it is also widely used to solve serious production problems. Its undoubted advantages include high productivity, the ability to produce large-sized products and the relatively low cost of equipment and consumables.

The disadvantages of this method are the highest degree of surface roughness among all additive technologies (the quality depends on the nozzle diameter and materials), the risk of plastic spreading and increased sensitivity to temperature changes. Note that the Super Discovery 3D Printer model equipped with a cutter will immediately correct the roughness and post-process the product right in the printer chamber.

As consumables, thermoplastics or composites are used in the form of threads wound on spools (so-called filaments), or granules. Their range is very diverse and allows you to choose the most suitable materials for the tasks to be solved in terms of physical and mechanical properties - ABS, PLA, nylon, polycarbonates, polyamides, polystyrene, polyethylene and many others.

Building an object in Discovery 3D Printer

The process of creating a product using FDM/FFF technology includes the following steps:

1. Export 3D model to 3D printer software in .stl format.

2. Preparation for printing: division of the model into layers and orientation on the construction platform, if necessary, the creation of supports. The result is a G-code containing all print settings.

3. Printing process by layer-by-layer extrusion (extrusion) of molten material. The extruder (print head) moves from bottom to top along the X and Y axes, the working platform moves along the Z axis.

4. Extraction of the printed object from the 3D printer, removal of supports, post-processing.

The filament printing method is used in the junior model of the Discovery 3D Printer line. The Super Discovery 3D Printer and Super Discovery 3D Printer Workstation implement the innovative Direct Extrusion of Pellet technology. The difference from standard FDM is that the consumables are in the form of granules rather than filaments. This method makes it possible to speed up and make more economical the production of large objects.

Helicopter seat
Equipment: Super Discovery 3D Printer, material: ABS with carbon fiber, dimensions: 120 x 70 x 45 cm, weight: 20 kg

Statue
Equipment: Super Discovery 3D Printer, material: ABS with cellulose fiber, height: 1.87 m, weight: 45 kg

Applications Discovery 3D Printer

Every industry is different, which is why CNC Barcenas tailors the 3D printers it produces to the requirements of specific applications and projects that require rapid prototyping or rapid production of end products. Discovery 3D Printer can be successfully used in the following industries:

• automotive industry;

• aerospace industry;

• shipbuilding;

• defense sector;

• railway industry;

• household goods and equipment;

• furniture industry;

• architecture;

• the medicine;

• education;

• Industrial Design;

• 3D printing services.

We printed large-sized parts and saved about 70% of the costs that are usually spent on prototyping by subcontractors

Juan Galindo Perez, Prototyping Manager, BSH Spain

Equipment line

The industrial 3D printer based on FFF technology is designed for the production of large parts from technical plastics within the framework of complex and long-term projects. As consumables, all filaments available on the market that conform to the standard 1.75 mm format can be used. The printer is equipped with a built-in dual extrusion system that can be used to create supports and parts from different materials in different colors. Discovery 3D Printer is one of the most attractive solutions on the market in terms of price and quality, given the dimensions of the printed products.

• Works with ULTEM, PLA, ASA, ABS, PA, HIPS, 3D850, PETG, ABS Medical, ABS Hi and many more

• Fully enclosed chamber and heated bed (up to 175°C) with auto leveling function that automatically compensates for minor unevenness during printing

• Build Chamber Size (W x D x H): 1150 x 800 x 500 mm

• Printer size: 1150 x 800 x 500 mm

• Weight: 300 kg

• Extruder (max. temperature): 450 °C

• Working load: 80-140g/h

• Print speed: up to 400 mm/s

• Layer thickness (minimum): 0. 1 mm

• Software: Simplify 3D

The machine was designed as a one-stop solution for Industry 4.0 to produce large-format parts up to 2.5 m in size. general expenses. Individual configuration is possible for any needs of large industry.

• Works with all thermoplastics e.g. ABS, ABS CF, PC CF, PPE CF, 3D850, ASA

• Fully enclosed chamber and heated platform (up to 175°C) with automatic leveling function for the most demanding materials

• Automatic supply of granules, no restrictions on the amount of material and, as a result, on the weight of the product.

• Build Chamber Size (W x D x H): factory standard 1300 x 2500 x 1000 mm, custom configuration available

• Printer dimensions with feed funnel and electrical cabinet: 2000 x 3590 x 3000 mm

• Weight: 1200 kg

• Extruder (max. temperature): 450 °C

• Working load: <6kg/h

• Print speed: up to 200 mm/s

• Layer thickness (minimum): 0.5mm

• Software: Simplify 3D

Compact and high performance industrial grade 3D printer for pellet extrusion printing. The machine is designed to create small and medium-sized products up to 1100 x 800 x 500 mm, and at the same time has all the advantages of the previous model Super Discovery 3D Printer, allowing you to reduce costs and increase print speed.

• Fully enclosed chamber and heated platform (up to 150°C)

• Works with all thermoplastics including ABS, ABS CF, PC CF, PPE CF, 3D850, ASA

• Polymer Granule Direct Extrusion Technology

• Build chamber size: 1100 x 800 x 500 mm (modifiable)

• Automatic feeding of granules and no restrictions on the amount of material

• Weight: 450 kg

• Extruder (max. temperature): 410 °C

• Working load: 2 kg/h

• Print speed: up to 100 mm/s

• Layer thickness (minimum): 0.5mm

• Software: Simplify 3D

A combined solution that implements two additive technologies at once - the filament printing method and direct extrusion of polymer granules, which can also be used separately. The innovative 3D printer works with any thermoplastics and has a build chamber up to 1100 x 800 x 500 mm, which can be modified to suit your individual needs if desired.

• Combined solution for printing with filaments and polymer granule extrusion technology

• Fully enclosed chamber and heated platform (up to 150°C)

• Works with all thermoplastics including ABS, ABS CF, PC CF, PPE CF, 3D850, ASA

• Build chamber size: 1100 x 800 x 500 mm

• Automatic feeding of granules and no restrictions on the amount of material

• Weight: 300 kg

• Extruder (max. temperature): 410 °C

• Working load: granules - 2 kg/h, filaments - 80-100 g/h

• Print speed: granules - up to 100 mm/s, filaments - up to 400 mm/s

• Layer thickness (minimum): granules - 0.5 mm, filaments - 0.1 mm

• Software: Simplify 3D

The perfect combination of a large format industrial 3D printer and a milling system. The plant is designed for the production of large batches of large parts and prototypes. The principle of operation, just like that of the Super Discovery 3D Printer model, is based on the direct extrusion of granules. The special design allows the entire production process to be carried out, including post-processing, since both the extruder and the milling motor are present on the working platform. The Super Discovery 3D Printer Workstation is capable of performing large-scale post-processing jobs, as well as cutting, punching or 3D engraving on plastic, photopolymer, foam, wood and other materials.

• Works with all thermoplastics including ABS, ABS CF, PC CF, PPE CF, 3D850, ASA

• Fully enclosed chamber and heated platform (up to 175°C) with automatic leveling function for the most demanding materials

• Automatic feeding of granules, no restrictions on the amount of material and, as a result, on the weight of the product

• Build Chamber Size (W x D x H): factory standard 1500 x 2000 x 1000 mm, custom configuration available

• Printer size: 2000 x 3590 x 3000 mm

• Weight: 1500 kg

• Extruder (max. temperature): 450 °C

• Working load: <6kg/h

• Speed: up to 200 mm/s

• Layer thickness (minimum): 0.5mm

• Milling motor: high-frequency brushless motor with air-cooled ceramic bearings, speed 4500-18000 rpm.

• Software: Simplify 3D + CNC software

Case History: FDM Printing for the Navy

By order of the Spanish Navy, the state-owned shipbuilding company Navantia has developed and implemented the Shipyard 4. 0 strategy (“Shipyard 4.0”). The goal of the new business model is to optimize the production process using Industry 4.0 technologies, including 3D printing, robotization, digital twins, big data, artificial intelligence, the Internet of Things, etc. Read more about Shipyard 4.0 in the article.

CNC Barcenas has been involved in two R&D projects for additive manufacturing. The first of these is called 3DCABINS and involves the production of fully equipped ship cabins through research and selection of the most suitable materials. For example, on the Discovery 3D Printer and Super Discovery 3D Printer installations, prototypes of a modular toilet for a naval ship were made. Compared to traditional production methods, the weight of the products has been reduced by almost 50% and their cost has been significantly reduced. The second project, ADIBUQUE, uses 3D printers to manufacture complex components for the navy sector, which are installed and tested on ships under construction.

Objects printed on the Super Discovery 3D Printer for the 3DCABINS project:

- modular toilet, material: flame retardant ABS, dimensions: 2200 x 1700 x 1200 mm, weight: 250 kg
– ventilation grille, material: ABS with carbon fibre, dimensions: 59 x 89 x 4.5 cm, weight: 3500 g

Using the Discovery 3D Printer enabled Navantia to:

• modernize the production process and increase productivity;

• reduce production and assembly time;

• reduce labor costs;

• reduce the amount of work on processing and painting;

• increase the energy efficiency of production;

• improve product quality.

Summary: briefly

The Discovery 3D Printer is a Spanish-made range of additive machines with an excellent price/performance ratio for creating large-sized products and prototypes.

Learn more

•
  3D printing polymer materials
•
  Northeastern 3d printing
•
  3D printer cafe
•
  Faro 3d scanner preis
•
  3D print snake
•
  Best 3d print websites
•
  Best paint for pla 3d prints
•
  Maker select 3d printer v2 review
•
  What can you print on a 3d printer
•
  Convert 3d printer to cnc router
•
  Website for 3d printing
