Falcon 9 3d print model


Fab365

GOODesign is a design studio established in Seoul, Korea by a representative who has been active in product design and 3D CG field for 20 years. As a design company that pursues a reasonable and differentiated digital design, it has always presented a new direction through working with clients such as Hyundai Motor, Siemens Korea and beiersdorf.   This time, we have put out the life product for 3D printing by utilizing various technique design based on the shape of the Class-A surface. These products are especially the result of deep research on the 3D printing dominant shape that can not be mass-produced using a mold.

+ more- less

The dragon capsule and trunk of the Space X project were loved by many 3D printer users.
Download Crew Dragon Capsule and Trunk STL- https://fab365.net/items/197
Download Dragon capsule and trunk ➪

Along with this, many 3D printer users have requested to make a Falcon 9 rocket with a dragon capsule up to the orbit. So I made the Falcon 9 rocket at the request of my clients.
This Falcon 9 rocket was intended to be able to connect to the previously created dragon capsule and trunk. So, it is the largest I have ever designed. So, I designed it to be printed in many parts.
In this design project, the landing leg was the biggest problem to be solved, but the piston structure was changed to a folding method because it was impossible to print in a slim shape in desktop 3D printing.
But with these changes
1. This Falcon 9 rocket can fold and unfold its landing legs and stand safely.
2. The wings can also be spread and folded.

The assembly process of this Falcon 9 rocket is as follows.
1. Fold the 4 landing legs first.
2. Connect the pipe (folding structure) that connects the landing legs and the body.
3. Glue the landing legs.
4. Attach the landing leg to the body and connect the folding pipe. When connecting pipes, connect them by pushing them at an angle perpendicular to the body.
5. Connect the landing legs to the body and fold them into the body.
6. Glue the nozzle to the bottom.
7. Attach the bodies in order. It is recommended to use adhesive.
8. Attach the cables to the body in order. We recommend using glue.
9. Put the dragon capsule and the trunk on the top to finish.

See the video for the above process.

※ Dragon capsule and trunk are not included.

Congratulations on the success of Space X, and hope that the era of the commercial space industry opens as soon as possible.

Scale 1 : 66
Size, when all parts are fitted X 232mm, Y 232mm, Z 897mm

Additions Raft : OK / Brim : NO / Support : NO
Infill Interlor Fill Percentage : 15% / Outline Overlap : 30~40%
First Layer Settings First Layer Height : 120% / First Layer Width : 150% / First Layer Speed : 50%
Layer Settings Layer Height : 0.1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 4.2mm
Ender Slicing Settings Simplify 3D
PRUSA MK3 Layer Height : 0.1mm, 0.2mm / Raft : OK / Brim : NO / Support : NO
PRUSA Slicing Settings Slic3r
Additions Raft : OK / Brim : NO / Support : NO
Infill Interlor Fill Percentage : 15% / Outline Overlap : 30%
First Layer Settings First Layer Height : 100% / First Layer Width : 100% / First Layer Speed : 80%
Layer Settings Layer Height : 0. 1mm, 0.2mm / Top Solid : 8 / Bottom Solid : 6 / Outline : 2
Extuder Nozzle Diameter : 0.4mm / Retraction Distance : 2.4mm
PRUSA Slicing Settings Simplify 3D
File
File 31.1 MB
Average Time
[0.1mm] Landing Leg : 4h
[0.1mm] Landing Leg Bar : 1h 30m
[0.1mm] Merlin Engines : 4h 10m
[0.1mm] P1 : 15h 30m
[0.1mm] P2 : 14h 40m
[0.1mm] P3 : 18h 20m
[0.1mm] P4 : 18h 30m
[0.1mm] P5 : 14h 30m
[0.1mm] P6 : 17h
[0.1mm] Side Cable : 4h
