3D printed subwoofer box
Powerful 3D printed 5 inch subwoofer - SW2
A 3D printed passive subwoofer using 5″ Tang Band driver.
Subwoofer Concept
Our previous 3d printed subwoofer, the SW1, is a 13 liter subwoofer with a 6.5″ driver, a matching passive radiator and a plate amp. We wanted to develop something smaller that would still offer the bass extension that satellite speakers so badly need. The result is the SW2 using a Tang Band W5-1138 5″ long-throw driver and the same Dayton Audio DSA175 passive radiator as in the SW1. The enclosure is now only 5 liters and much easier to fit on a desktop. The passive resonator allows tuning the resonance frequency to avoid overlap with room modes, for example. The spherical shape is optimal for material use and stiffness. Combined with the small diameter driver with large surrounds, the appearance is quite unique. If a traditional box is what you want, then this build is not for you.
Measurements
The measured resonance frequency of the passive radiator indicates that some air-coupling occurs due to the downward firing placement. Simulated resonance frequency matches the measured value (53 Hz) when 16 grams of added mass is used. Mass can be further added using washers to tune the response. In practice, the frequency response starts to drop below 50 Hz. The Arylic amplifier offers DSP capabilites and using a computer as the source allows unlimited DSP with zero cost. Therefore, frequency response in not that meaningful especially when considering the room effects, but we have included some measurements to give an idea of the natural response especially around the lower cut-off.
3D printing
The enclosure is printed in one part (234 mm diameter) and takes approximately 1.5 kg of filament. Print time is about 48 hours. The mass can be increased by lining the walls with sound deadening mat. Although the external wall is spherical, there is a cylindrical inner wall that braces the woofer to the passive resonator and, thanks to a single curvature surface, allows easy installment of thick sound deadening mat.
The drivers are fastened using 4.2 mm wood screws. There is a geometry file for a gasket for the woofer which can be printed from TPU. Traditional gasketing methods will work, but the 3D printed gasket is seamless and has the screw hole pattern accurately incorporated. The binding posts are recessed deep into the enclosure and only accept banana plugs in that configuration. An O-ring under the binding post washer is recommended and there is a chamfer for it. 3D printing using a wood-filled filament allows easy sanding for a smooth surface finish. The photos show 15 minutes worth of post-processing making this a very easy and fast build without compromising in function and looks.
Images
Sound quality
The subwoofer was compared to the much larger, THX certified Logitech Z623 subwoofer. The sound is very similar, but in a much smaller package. The SW2 is a great companion for small satellite speakers and brings fullness to the bass. Electronic music will benefit from the “boom” offered by this small unit, while other types of music may require turning down the level a bit for a tighter bass.
Links and video
The 3D files can be found in Etsy store:
https://www.etsy.com/shop/RDPhysics
Please support us by using the affiliate link below just before ordering the components:
TangBand W5-1138 on SoundImports.eu
Dayton Audio DSA175-PR on SoundImports.eu
Arylic 2.1 BT amp on SoundImports.eu
