RAPTOR 3DX provides new convenience for your precise scanning measurement.
In the past, only skilled and professional engineers could skillfully operate 3D scanners. Nowadays, fully automatic scanning methods are redefined, and hybrid 3D scanners that do not require fixed objects are also redefined.
The current automatic measurement scanning platform adopts a plane horizontal rotation method, only the object is placed on the scanning platform, and no additional steps such as fixing the object to be measured are required.
RAPTOR 3DX uses the scanning engine to move up and down, without additional operations to fix the object under test. It is a new concept 3D scanner.
Auto x manual mode
When you need to perform more free and diverse scanning operations, you can remove the scanning engine to perform 3D scanning at any time .
When scanning in manual mode, the maximum measuring range at one time is 600mm, so it can be used for scanning products with a size of more than 1 meter.
When using automatic mode
• One click to complete the 3D scan.
• The scanning engine moves up and down to perform a 360-degree measurement of the measured object.
• In the absence of a fixed device, the object can be started after being placed on a horizontal platform,
• Automatically capture the part that needs supplementary scanning and perform supplementary scanning.
When using manual mode
• Can scan objects larger than the object size that can be scanned by the automatic platform.
• The scan range at most once is 600mm.
One click can automatically obtain 3D data of the appearance size of the object, thereby saving more work time.
3DX scanning software (included)
• specially developed for scanning depth RAPTOR 3DX, the base hardware formed to an optimum combination.
• Designed on the basis of a 64-bit operating system, using a new algorithm that is most suitable for processing high-definition scan data.
• Choose a user-friendly operation interface, which is also very easy for beginners to use.
• Use intelligent data sorting, no manual sorting is required.
• Provide automatic data recovery function to prevent accidental data loss.
• Based on point cloud data, generate a mesh STL file.
RAPTOR 3DX scanner
• Integrated optical system optimized for ultra-precision scanning.
• You can use 3 sets of scanning areas just by changing the lens.
• According to the surface texture of the measured object, the measurement brightness and noise level can be automatically adjusted to provide higher quality data.
• It can intercept the real material information of the surface of the object and generate data suitable for 3D printing.
Robot arm + RAPTOR 3DX scanner
• RAPTOR 3DX can be installed on the robotic arm to create a customized scanning system.
The main advantages of RAPTOR 3DX
Hybrid
• Choose a 3-axis drive platform, no need to manually move the object, can be completely automatic scanning.
• Choose automatic platform, all scanning processes are carried out automatically.
• Equipped with a high-resolution camera to obtain accurate 3D data of each small part of the object.
Stable Scan Stage (SSS) technology
• Using self-developed SSS patent (US Patent) technology, no fixtures are needed to fix the scanned object.
• Change the scanning angle limit due to the use of object fixing devices, scanning with more angles, and obtaining more perfect data.
• No need to swing, prevent embarrassing phenomena such as objects slipping off the scanning platform from the source.
Rich scanning area (FOV)
• 1 scanner can use 3 sets of scanning areas.
• RAPTOR 3DX scanner can not only 3D scan large objects, but also small objects easily.
Gigabit Ethernet interface
• Choose a Gigabit Ethernet interface that is more suitable for high-resolution image transmission.
• No need to install a separate driver on the computer, just use a network cable to connect to the computer.
Scan the QR code to read on your phone
We could not find any corresponding parameters, please add them to the properties table
The main advantages of Raptor3DX
Hybrid
• Choose a 3-axis drive platform, no need to manually move the object, can be completely automatic scanning.
• Choose automatic platform, all scanning processes are carried out automatically.
• Equipped with a high-resolution camera to obtain accurate 3D data of each small part of the object.
Stable Scan Stage (SSS) technology
• Using self-developed SSS patent (US Patent) technology, no fixtures are needed to fix the scanned object.
• Change the scanning angle limit due to the use of object fixing devices, scanning with more angles, and obtaining more perfect data.
• No need to swing, prevent embarrassing phenomena such as objects slipping off the scanning platform from the source.
Rich scanning area (FOV)
• 1 scanner can use 3 sets of scanning areas.
• The Raptor3DX scanner can not only perform 3D scanning of large objects, but also small objects.
Gigabit Ethernet interface
• Choose a Gigabit Ethernet interface that is more suitable for high-resolution image transmission.
• No need to install a separate driver on the computer, just use a network cable to connect to the computer.
classification
Non-contact optical 3D scanner
Resolution
2MP / 5MP (dual lens)
Scanning area (FOV)
2MP 120 x 90 x 90 mm (FOV150) 270 x 200 x 200 mm (FOV330) 400 x 300 x 300 mm (FOV500)
5MP 110 x 85 x 85 mm (FOV140) 230 x 180 x 180 mm (FOV300) 500 x 350 x 350 mm (FOV600)
Precision
±15μm per 100mm area
Dot pitch
0. 07 mm (FOV150) 0.16 mm (FOV330) 0.25 mm (FOV500)
0.04 mm (FOV140) 0.09 mm (FOV300) 0.18 (FOV600)
Scanning distance
450mm
platform
Automatic 3-axis (360°rotating turntable/ -5° to 90° arm/±45°scanner) with SSS patented technology
size
320 x 220 x 140mm (scanner) / 930 x 700 x 250mm (platform)
