3D printer spool dimensions
3D Printer Filament - Spool Comparison Guide
3D printer filament spools come in many different styles and sizes. Most 3D printers will accept spools that fall within a set of industry accepted standards. Our spools are designed to fit most 3D printers that accept a standard spool size.
Why You May Need a Larger 3D Printer Filament Spool
Larger filament spools allow for continuous 3D printing without having to change out the spool and interrupt prints. A bigger spool is ideal for a larger build that required more 3D printer filament. This may even be ideal for smaller prints if you are tired of having to change out spools so often.
MakeShaper Spools for 3D Printing
We have small 220g filament spools and large filament spools that contain 5kg all the way up to 25kg depending on the material and diameter. Browse our products online or reach out to us today if you are unsure which filament spool would be right for your 3D printer application.
| Spool Size | Spool Weight (lbs) |
|---|---|
| 220g | 0.25 |
| 650g | 0.50 |
| 900g / Makerbot® | 0.55 |
| 1 kg | 0.75 |
| 2.25 kg | 2.10 |
| 5 kg | 2.9 |
| Spool Size | 220 Grams | ||
| Amount of Filament approx. | Material | 1.75mm | 2.85mm |
| ABS | 283ft | 110ft | |
| PLA | 234ft | 92ft | |
| PETG | NA | NA | |
| PLA/PHA | NA | NA | |
| TPU | 253ft | 77ft | |
| PVA | NA | NA | |
| HIPS | NA | NA | |
| Hub Diameter | 54. 102mm | ||
| Hub Counterbore Diameter | 86.868mm | ||
| Spool Diameter | 152.4mm | ||
| Spool Thickness | 35.306mm | ||
| Spool Size | 650 Grams | ||
| Amount of Filament approx. | Material | 1.75mm | 2.85mm |
| ABS | 833ft | 325ft | |
| PLA | 692ft | 271ft | |
| PETG | NA | NA | |
| PLA/PHA | NA | NA | |
| TPU | 747ft | 264ft | |
| PVA | NA | NA | |
| HIPS | NA | NA | |
| Hub Diameter | 52. 832mm | ||
| Hub Counterbore Diameter | NA | ||
| Spool Diameter | 212.09mm | ||
| Spool Thickness | 40.132mm | ||
| Spool Size | 1 Kilogram | ||
| Amount of Filament approx. | Material | 1.75mm | 2.85mm |
| ABS | 1282ft | 500ft | |
| PLA | 1064ft | 417ft | |
| PETG | NA | NA | |
| PLA/PHA | NA | NA | |
| TPU | 1150ft | 470ft | |
| PVA | NA | NA | |
| HIPS | NA | NA | |
| Hub Diameter | 52. 832mm | ||
| Hub Counterbore Diameter | 88.9mm | ||
| Spool Diameter | 203.2mm | ||
| Spool Thickness | 73.152mm | ||
| Spool Size | 2.25 Kilograms | ||
| Amount of Filament approx. | Material | 1.75mm | 2.85mm |
| ABS | 2884.5ft | 1125ft | |
| PLA | 2394ft | 938.25ft | |
| PETG | NA | NA | |
| PLA/PHA | NA | NA | |
| TPU | NA | NA | |
| PVA | NA | NA | |
| HIPS | NA | NA | |
| Hub Diameter | 52. 07mm | ||
| Hub Counterbore Diameter | NA | ||
| Spool Diameter | 298.45mm | ||
| Spool Thickness | 101.6mm | ||
| Spool Size | 5 Kilograms | ||
| Amount of Filament approx. | Material | 1.75mm | 2.85mm |
| ABS | 6410ft | 2500ft | |
| PLA | 5320ft | 2085ft | |
| PETG | NA | NA | |
| PLA/PHA | NA | NA | |
| TPU | NA | NA | |
| PVA | NA | NA | |
| HIPS | NA | NA | |
| Hub Diameter | 50. 8mm | ||
| Hub Counterbore Diameter | NA | ||
| Spool Diameter | 304.8mm | ||
| Spool Thickness | 184.15mm | ||
3D printer filament spool sizes
Whilst filament spool dimensions appear to be converging on a standard, there is still not complete uniformity so please take a look at the below table to ensure that the filament brand will work with your 3D printer.
We often get contacted by people looking to find filament that can be used with their 3D printer, the common issues are filament diameter and spool size. So as a result we have started to put together a list of different manufacturers filament specifications. Filament print settings are usually listed on a filaments product listing page so we are not going to repeat those here.
Table of 3D printer filament Spool dimensions
| Manufacturer | Outer Diameter (cm) | Inner Diameter (cm) | Depth (cm) | Weight (kg) | Filament Diameter (mm) |
|---|---|---|---|---|---|
| 3Dom/3D fuel | 20. 3 | 5.0 | 7.3 | 1 | 1.75 & 3.00 |
| ColorFabb | 20 | 5.2 | 5.5 | 0.75 | 1.75 & 3.00 |
| iDig3Dprinting | 20 | 5.3 | 7.0 | 1 | 1.75 & 3.00 |
| Makerbot | 20.3 | 5.08 | 7.62 | 0.9 | 1.75 |
| NinjaFlex | 20 | 5.2 | 5.4 | 0.5 | 1.75 & 3.00 |
| PP3DP/Tiertime | 20 | 5.2 | 5.6 | 0.5 | 1.75 |
| Robox | 17.2 | 2.5 | 8.0 | 0.6 | 1.75 |
| XYZ Da Vinci | 16.5 | 5.0 | 5.3 | 0.6 | 1.75 |
| XYZ Junior | 17 | 5.3 | 5.5 | 0.6 | 1.75 |
| Hatchbox | 20 | 5.6 | 6.8 | 1 | |
| Funflag | 19.7 | 5.5 | 6. 6 | 1 | |
| Filamex | 16.2 | 3.05 | 5.75 | 0.5 | |
| Prusament | 19 | 5.3 | 7.7 | 1 | 1.75mm |
| Goedis | 20 | 5.3 | 6.7 | 1 | 1.75mm |
| inland | 20 | 5.35 | 6.6 | 1 |
We would be really grateful if you can provide information on other filament manufacturers spools sizes or tell us if some of our data is inaccurate. So feel free to get in contact with us.
Testimonials
Was having problems calibrating my printer until I contacted iDig3DPrinting. They responded quickly and provided great technical documentation that I couldn’t find anywhere else. Thanks!!
Allen
Fantastic service. Goods received within 24 hours of placing order. Will be purchasing more stuff.
Would definitely recommend.
Janice
Great service, very quick to answer queries and resolve any problems. Reliable and affordable
.
Adam
First class service and support, purchased some spare parts for my printer and they were glad to help with an unrelated problem I was having with the printer, even though it was not supplied by iDig , I would recommend them without hesitation.
Ed
Have had a lot a of problems setting up a 3d printer at our school, idig3d printing contacted me through a forum and have been brilliant ,giving advice and guidance. Thank you
Claudia
All filament spools. Weight, size, 3D model
MirFDM
Loading
10/19/2020
12459
Consumables
Experienced 3D printers probably determine by eye whether there is enough filament for this part or not) Of course, it is better to know exactly how much filament is left on the coil, but for this you need to know how much each coil weighs.
Or you are modeling your 3D printer and so that the plastic absorbs less moisture, of course, you decided to place the coil mount inside the printer. It remains to understand what width and height the coils are, and ideally it is better to have a 3D model in general in order to lay the optimal mount.
Wow... this is where the fun begins) There are a lot of types of coils, they all weigh differently, have different diameters, widths, and even a mounting hole. And how is it to be here?
I didn’t think of anything better than how to assemble all the coils of Russian filament manufacturers. Weigh them, measure them, make a 3D model and write it all down in a table:
More details about each coil, and about the table as a whole, I tell here:
I tried to combine all the coils known to me into one table. Most likely, I forgot about some Russian manufacturer or did not add some kind of coil.
I would like to sincerely believe that experienced 3D printers will correct me and tell me. And together we will finish this Table to the end)
P.S. Link to the Table with all the characteristics and 3D models in the description on YouTube
Article comments
Even more interesting articles
Sergey
Loading
11/25/2022
3487
twenty
Subscribe to the author
Subscribe
Don't want to
After reading several reviews from Ilya and Alexander on the budget composite rPETG GF from REC, I decided to personally...
Read more
eleven
Subscribe to the author
Subscribe
Don't want
Good day everyone!
Got a new product from Eryone - photopolymer resin for 3D printing.
..
Read more
114
Subscribe to the author
Subscribe
Don't want to
Yes, this is not a joke, the vases in the photo are really printed on the printer. In this master class just...
Read more
MakerBot 3D Printer Reel Specifications
Dimensions and weight:
| Parameters\Size of reels | SMALL | LARGE | XL | XXL | 1 kg |
| Bobbin diameter | 15 cm | 25 cm | 21.59 cm | 21.59 cm | 20.32 cm |
| Bobbin Width | 4 cm | 4 cm | 8.89 cm | 17.78 cm | 7.62 cm |
| Attachment inner diameter | 5.08 cm | 5. 08 cm | 2.54 cm | 2.54 cm | 5.08 |
| plastic diameter | 1.75mm | 1.75mm | 1.75mm | 1.75mm | 1.75mm |
| Shipping weight with reel | 0.45 kg | 1.36 kg | 2.72 kg | 4.99 kg | 1.36 kg |
| pla plastic weight | 0.22 kg | 0.9kg | 2.26 kg | 4.53 kg | 1 kg |
Compatible:
| 3D printer\Reel size | SMALL | LARGE | XL | XXL | 1 kg |
| Replicator 2/2X | + | + | + | ||
| Replicator Mini | + | ||||
| Replicator (5th generation) 5TH GENERATION MODEL | + | + | |||
| Replicator Z18 | + | + | + | + |
Temperature rating:
Solidification temperature -60-65°C
Melting point -150-160°C
Extruder temperature - 203°C
Pictures of various spools for MakerBot 3D printers:
1Kg format spool suitable for MakerBot Replicator 2/2X 3D printer and previous models.
