3D printed mp5
A 3D Printed MP5 by IvanPrintsGunsThe Firearm Blog
- [SHOT 2022] Magpul MP5 Stock And Drum Mag
- [SHOT 2022] QC10 MP5 Style YKMF-5
- TFB Review: HK SP5L – Modern Day HK94
Posted in Daily News, Submachine Guns/Pistol Caliber Carbines by Luke C. with No Comments
Tags: 3d printing, DIY guns, homemade firearms, IvanPrintsGuns, KF5, Kleiner Freund, mp5
The 3D printing community continues to impress me by finding ways of making reliable, durable, and interesting homemade guns. IvanPrintsGuns is one of my favorite YouTube channels that focuses on 3D-printed firearms and in early March, Ivan showcased his latest working prototype – the Kleiner Freund or KF5. The KF5 is a 3D-printed MP5 that makes use of only the core of an MP5 and then combines it with improved 3D-printed parts to make the world’s most affordable MP5.
More Roller Delayed Blowback Goodness @ TFB:
This is the Kleiner Freund (KF5) – a 3D printable MP5 build that uses AR15 fire control parts.
This build is much cheaper than an MP5 (or even the knockoffs/clones), since it only uses the core parts of an MP5 and substitutes better, more reliable (and cheaper) parts for the rest.
The scope used is a course far too large for an MP5, but all my red dots are tied up on other builds.
Anyway, in this initial testing, I’m using a 3D printed ejector – while it does work with OEM ones, OEM ejectors are very expensive and hard to find – I’m working to get steel ones made, but in the mean time, a 3D printed one does the trick.
Obviously, development is still ongoing – the magazine well needs tweaked, and the ejection port is massively oversized so that it can act as an inspection port (so that I can see the inner workings without taking the gun apart).
Right now you’d be hard-pressed to pick up any type of MP5 regardless of the manufacturer for much less than $1,800. However, by using a commonly available and affordable complete MP5 bolt group (about $400), a roughly $50 AR-15 lower parts kit, and the cost of some relatively inexpensive hardware and 3D printing filament, you can probably make one of these KF5s for about $500 to $600 without breaking a sweat.
As seen in the video and mentioned above, the KF5 is still in its testing phase and during the video, we saw one malfunction which isn’t all that surprising given the complexity of manufacturing something like an MP5 at home.
As always, I’d like to hear your thoughts on this. Do you think Ivan will be able to get his KF5 working as well as a regular HK MP5 works? What potential improvements or drawbacks can you see between the two different platforms? Let us know your thoughts down in the comments!
Luke C.
• Reloader
• SCSA Competitor
• Certified Pilot
• Currently able to pass himself off as the second cousin twice removed of Joe Flanigan.
• Instagram: https://www.instagram.com/ballisticaviation/
KF5 3D Printed MP5 | 3D Gun Builder
KF5 3D Printable MP5 Details
Infamous 3D printed gun designer Ivan the Troll has done it again with the Kleiner Freund 5, aka the KF5 3D printed MP5 sub-machine gun.
Regularly costing upwards of $7,000, the H&K MP5 is often out of reach for most gun enthusiasts.
With the KF5, you can get the MP5 experience for a fraction of the cost.
The KF5 is a 3D printed clone of the MP5 that fires 9mm rounds.
It was designed by Ivan the Troll (builder of the Plastikov) using an open-source CAD program and is available for anyone to download and print
What is the Kleiner Freund 5 3D Printable MP5 build
The KF5 is available for anyone to download and 3D print from their own homes.
The 3D-printed MP5 is chambered in 9mm, making ammunition accessible and cost-effective for firearms lovers.
The KF5 is a 3D printed clone of the German MP5 and is probably the most popular series of submachine guns worldwide; it functions according to the proven roller-delayed blowback principle.
Tremendously reliable, with maximum safety for the user, easy to handle, modular, highly accurate, and extraordinarily easy to control when firing – HK features that are particularly appreciated by security forces and military users worldwide.
Unlike the classic version of the MP5, the Kleiner Freund 3D version tolerates brass and steel-cased ammo.
The KF5 again proves that 3D gun designers can push what is thought possible in the DIY firearms hobby.
KF5 3D Printable MP5 in the Wild
Photos
Videos
https://www.youtube.com/watch?v=_dBJUifMtTA
KF5 3D Printable MP5 Test Firing MontageKF5 (3D Printed MP5) Mag DumpKF5 MP5 History
The Amigo Grande, a CETME-based design by IvanPrintsGuns and Matt from Fudbusters, was the predecessor of the FP5 design. The modifications to that design for the KF5 3D printed MP5 by IvantheTroll, aka Ivan Prints Guns, have seen even more success.
Ivan has put several thousand rounds through his KF5 prototype.
We can expect that it would work fine as a casual shooter or range toy to explore 3D printed tech in a platform we know pretty well.
The MP5’s fame through modern film and video games like CounterStrike make this a highly sought-after 3D printable weapon.
KF5 3D Printable MP5 Tech Specs
What inspired the creation of the KF5? It started as a smaller version of the Amigo Grande, says KF5 designer Ivan the Troll.
Additionally, it uses AR15(not the full auto Yankee Boogle Swift Link) fire control groups instead of MP5 triggers (which are more expensive and are a bit harder to get ahold of)
The KF5 weighs around 4.5lbs with a fully loaded magazine and without a brace.
With being chambered in 9mm, the ease and fun of shooting this 3D printed MP5 are excellent.
Required Parts for the KF5 3D Printable MP5 Build
The KF5 is one of the most solid out-of-the-box STL files we have seen for a 3D-printed gun.
The print orientation and design specs are dead on for reliability and longevity.
You will only need the following parts kit(note: piecing this individually is quite tricky and nearly impossible due to importation regulations:
- Buy a clone for the parts kit i.e., Century Arms AP5 (from Turkey)
- Buy a wind chimes kit (parts kit) from the premier 3D printed gun parts kit provider MAF arms
Frequently Asked Questions
Can you 3D print an MP5?
You can 3D print an MP5, i.e., the KF5, Amigo Grande, or FP5, by downloading the files from 3dgunbuilder.com or deterrencedispensed.com.
How much does 3D printing an MP5 cost?
On average, a 3D-printed MP5 costs $700 to $1200 from a parts kit online, and a 3D printer is as cheap as $200.
Are 3D printing MP5s legal?
In the United States, building a 3D-printed MP5 is legal.
There are now some current restrictions on unserialized firearms coming into play. Read up on our 3D printed gun laws article to check your local rules.
