CNC plastic lathe and lathe chuck......... Almost real.
RepRap
Follow author
Follow
Don't want to
73
And then the smallest lathe with a caliper costs some kind of "horse" money, but it has a bunch of negative reviews.
If you do it right and do not save on plastic, then everything works fine.
It all started with printing a 2.5" (63 mm) lathe chuck from a finished Twingi model.
There are two models
I printed and the chuck does not hold the workpiece - in the steel chuck
there is such a part
And it works fine when it is not made of steel, but it is made of plastic.
I printed such a ring on the screws
And the cartridge began to clamp normally. I remade the model for an 8mm axle - there are pulleys for the GT2 ring belt for this diameter. I had these parts.
Well, this .........probably ..
And we look at these toy machines .... People most often change cartridges and engines ....
So you need to the engine is more powerful .... in the nearest DIY store there was one model with a 5 mm shaft - the rest with 3.175 mm shafts .... and my pulley is only 5 mm, and it is more expensive to make an adapter sleeve than to buy an engine with a 5 mm shaft .
I purchased this motor with a 5 mm shaft.
As a result,
turned out to be such a front grandmother
caliper - we put a proven version from the freester ....... and
9000
and from what to make cutters - drill for ceramic tiles they have hard alloy overlays - they cost little compared to cutters and are suitable in size for a very small machine ..... And as a "cutting cutter" we use a replaceable blade from a clerical knife
And the first chip.
X - caliper stroke 100 mm, and the cutter stroke in the current version (the chuck can be machined) - from the chuck jaws to the stroke limit - 60 mm .
.... but if you move the cutter holder to another mount, then all 100 mm to choose but you need to do the tailstock.
According to Y - carriage travel 90 mm - that is, the travel is greater than the distance from the center to the axes - the restriction is only on the diameter of the clamp. Why is such a big move made - so that you can install a milling electric spindle - I just have two different pieces - you can make a dividing head or install a stepper instead of a DC drive motor - the possibility is structurally provided ..
He processes plastic.... And what if you try to grind a nail - weaving?
And it sharpens - extremely slowly, with very little removal, but sharpens.
True, it would have come out faster with a file .... but you can’t do it exactly with a file ... But you can also use a file on the machine - on a clamped workpiece in the chuck .....
CNC-control reflashed an autonomous block from the router ....
But all that remains is to master the program for preparing control codes .....
Block - Arduino NANO 3.0 + shield "Control by GRBL 111330" + MKS TFT2.4 with firmware for CNC (for 3-axis CNC) + power key ....
Here is such a small the lathe turned out .....
Health and good luck to everyone.
