Creaform portable 3d scanner price


Creaform launches the HandySCAN Silver Series 3D scanner - technical specifications and pricing

0Shares

3D measurement system manufacturer Creaform has announced the launch of its latest handheld 3D scanner.

The HandySCAN 3D Silver Series is available in two models: the HandySCAN 307 at $19,990 and the higher-performance HandySCAN 700 at $29,900. Aimed at professional engineers and technology companies, the device is intended to provide repeatable metrology-grade 3D measurements for product development and reverse engineering applications.

“For the professionals who need to adapt quickly to their customers’ needs and provide better answers to their inquiries, a reliable 3D scanning solution is indispensable,” states Simon Côté, Product Manager at Creaform. “The possibilities presented by gathering such precise data can open doors to new projects and strengthen the partnerships with existing clients. It cannot be overstated how 3D scanning and 3D printing technologies have become vital for any small-to-medium sized company. ”

The HandySCAN 3D Silver Series. Photo via Creaform.

Professional 3D scanning with Creaform

Based in Québec, Creaform already has an extensive portfolio of professional 3D scanning devices. Go!SCAN, the company’s most affordable line, is capable of capturing full color 3D models with a setup time of just five minutes. With a focus on accessibility and ease-of-use, the entry-level range is designed to be usable by individuals of any background in a pick up-and-play manner.

For those looking for more in the way of performance, the HandySCAN and MetraSCAN ranges might be a little more suitable. Built for manufacturing and metrology professionals working in dynamic manufacturing environments, these premium 3D scanner lines offer high-precision measurements for engineering projects.

Scanning a Koenigsegg with the HandySCAN Silver Series. Photo via Creaform.

The HandySCAN 3D Silver Series

The latest addition to the HandySCAN range is characterized by its precision and versatility. Operating on seven red laser crosses, the Silver Series provides users with a scan area measuring 275 x 250mm, an accuracy of up to 0.03mm, and a measurement resolution of up to 0.05mm. With a recommended part size ranging from 0.1 – 4m, the device is reportedly compatible with a whole host of object types, regardless of complexity, surface finish, or color.

At 0.85kg, the Silver Series is lightweight and portable. Designed for both in-house and on-site use, the scanner fits comfortably in a small suitcase and can be set up in around two minutes. It triangulates its own relative position using in-built optical reflectors, meaning it can be used as a standalone device with no tripod or external tracking equipment. Featuring a simple UI and real-time visualization functionality, Creaform’s Silver Series boasts a “shallow learning curve” regardless of the user’s experience level.

The new Silver Series 3D scanning a helmet. Photo via Creaform.

Technical specifications and pricing

Below are the technical specifications for the HandySCAN 3D Silver Series. The 3D scanner is available to order now, starting at $19,990.

HandySCAN 307HandySCAN 700
AccuracyUp to 0.04mmUp to 0.03mm
Volumetric accuracy0.02mm + 0.1mm/m0.02mm + 0.06mm/m
Measurement resolution0.1mm0.05mm
Mesh resolution0.2mm0.2mm
Measurement rate480,000/s480,000/s
Light source7 red laser crosses7 red laser crosses + extra line
Laser class2M2M
Scanning area275 x 250mm275 x 250mm
Stand-off distance300mm300mm
Depth of field250mm250mm
Part size range0. 1 – 4m0.1 – 4m
Weight0.85kg0.85kg
Dimensions77 x 122 x 294mm77 x 122 x 294mm

Subscribe to the 3D Printing Industry newsletter for the latest news in additive manufacturing. You can also stay connected by following us on Twitter and liking us on Facebook.

Looking for a career in additive manufacturing? Visit 3D Printing Jobs for a selection of roles in the industry.

Featured image shows the new Silver Series 3D scanning a helmet. Photo via Creaform.

Tags Creaform HandySCAN 3D Silver Series Simon Côté

Kubi Sertoglu

Kubi Sertoglu holds a degree in Mechanical Engineering, combining an affinity for writing with a technical background to deliver the latest news and reviews in additive manufacturing.

Creaform 3D Scanners - Portable 3D Scanning Technologies

800-688-3234

Fast and Versatile 3D Scanners

Together with Creaform, GoEngineer offers a variety of portable 3D scanning technologies that have been developed to meet the specific needs of a wide range of applications including aerospace, automotive, and oil & gas industries. From professional-grade to metrology-grade, they provide users with highly accurate, portable, and easy-to-use solutions.

Creaform 3D Scanners deliver accurate, high-resolution, and repeatable results, regardless of the measurement setup quality or user experience. Featuring dynamic referencing, both the scanner and part can move during measurement and still provide an accurate and high‑quality scan.



don't miss this upcoming webinar!

Solving Productivity Issues Through 3D Scanning - Deciding between Handheld and Automated 3D Scanning
April 13, 2022 at 10am PT

In webinar Jerome-Alexandre Lavoie, Product Manager at Creaform, will present tools that will help manufacturing companies analyze whether automation is more suitable for their activities than handheld 3D scanning. To better understand the potential of transitioning to automation and show how robot programming is accessible to everyone, Olivier Plamondon, Technical Product Manager at Creaform, will go through a complete automated quality control project in a live demonstration. To round off this webinar, Kyle Shannon, Business Development Manager A-QC at Creaform, will discuss the cost-benefit of transitioning to automation, and the expected return on investment.

Join Creaform’s experts and discover which handheld or automated 3D scanning solution is right for YOUR workflow.





Very simple 3D scanning process

The straightforward data acquisition process generates extra fast results, with real-time visualization and direct mesh output. These 3D scanners are up and running in less than five minutes and require no rigid setup or prior experience from the user. You can scan parts in virtually any size, material, or color.

3D scanning where you need to go

Our 3D scanners are handheld, light, and they fit into a small suitcase. Because they have no mechanical constraint, they allow total freedom of movement and can be brought and used virtually anywhere.

Accurate measurements in real-life conditions

Creaform 3D Scanners ensure highly-accurate measurements, regardless of the environment (instability, vibrations, thermal variation, etc.) or operator skills. Our scanners use software algorithms that simplify the measurement process and greatly increase data accuracy.



GO!SCAN 3D

Accuracy:
0.050 mm (0.0020 in)

Resolution:
0. 100 mm (0.0039 in)

Go!SCAN 3D

Structured White LED Light

LEARN MORE

HandySCAN 3D

Accuracy:
0. 025 mm (0.0009 in)

Resolution:
0.025 mm (0.0009 in)

HandySCAN 3D

Blue & Red Laser High Resolution

LEARN MORE

MetraSCAN 3D

Accuracy:
0. 044 mm (0.0017 in)*

Resolution:
0.050 mm (0.0020 in)

MetraSCAN 3D

Red Laser Light Technology

LEARN MORE

HandyPROBE

Accuracy:
0. 025 mm (0.0009 in)

Part size range:
0.2-6 m (0.7-20 ft)

HandyPROBE

Portable CMM

LEARN MORE

MetraSCAN 3D R-Series

Accuracy:
0. 025 mm (0.0009 in)

Resolution:
0.025 mm (0.0009 in)

R-Series

Robot Mounted Automation

LEARN MORE



Add-On Hardware

MaxSHOT 3d
Large-scale metrology projects
  • Automatic feedback on measurement quality
  • Designed specifically for photogrammetric applications
  • 50% lighter than traditional photogrammetric devices

AADS specializes in the design, manufacturing of specialized Jeep vehicles for governmental organizations. AADS uses their Go!Scan Spark scanner to reverse engineer and validate custom parts.

Download The AADS Creaform Case Study

Creaform 3D scanners are handheld and are non-contact. This versatility enables 3D technology to support four preservation categories: 3D archives, virtual museums, restoration, and preservation.

READ MORE

Plastic blow molding company Blowtech reduced their process time by 50% with 3D scanning. Originally t he company had to ship the parts to an external service partner for inspections.

Download The Blowtech Creaform Case Study

Request More Information on Creaform 3D Scanners

VXELEMENTS

3D SCANNING SOFTWARE PLATFORM

Creaform’s VXelements provides a fully integrated 3D software platform that powers the entire fleet of 3D scanning and measurement technologies. It gathers all the essential elements (VXscan, VXprobe, VXshot) and tools into a user-friendly, simple and sleek working environment.

Request More Information on the VXELEMENTS 3D Scanning Software Platform





ADDITIONAL Software
REVERSE ENGINEERING

Creaform VXModel
GeoMagic Design X
GeoMagic for SOLIDWORKS
GeoMagic Wrap

INSPECTION

Creaform VX Inspect
GeoMagic Control X

Additional Resources

Take Advantage of GoEngineer’s Extensive Knowledge Base and Resources

Find a Solution

Our robust Knowledge Base contains over 12,000 resources to help answer your product design questions. From basic CAD questions to in-depth guides and tutorials, find your solution here. Find a Solution

PROFESSIONAL TRAINING

Improve your skills with professional training and certifications in SOLIDWORKS, CAM, 3D Printing, and 3D Scanning offered four ways: self-paced, online, on-site, or in-classroom. Certified Training Courses

BLOG

#1 Technical Resource Worldwide - Right at your fingertips. Search or browse through hundreds of SOLIDWORKS tips & tricks, additive manufacturing product developments, announcements, how-to guides, and tutorials. Blog

YouTube Channel

Our YouTube channel hosts hundreds of educational tutorials, product demonstrations, recorded webinars, and best practices for all of our products and services. GoEngineer's YouTube Channel

ONLINE STORE

Order 3D printing materials and consumables, enroll in SOLIDWORKS training classes, and buy official GoEngineer gear directly from our online store. Online Store

FREE SOLIDWORKS Tools

Enjoy this collection of small ‘macros’ that were tailored to help our customers. These free SOLIDWORKS tools are for you to use, review, and modify. SOLIDWORKS Automation Tools

WEBINARS

Our engineering webinars are hosted by some of the top experts in the industry. They are always recorded, always free, and always offer a live Q&A. WEBINARS

3D Printing Services

Need to 3D print a part? Our Additive Manufacturing experts will 3D print your part and deliver it to you using the latest technology on one of our professional FDM, PolyJet, SL, or Metal 3D printers. 3D Printing Services

Creaform 3d scanners at factory price with delivery

Industrial 3D printers

Professional 3D printers

Post-processing of finished products

Production and processing of metal powder

3D scanners

Materials

  • Standard equipment

3D scanner Creaform Academia 10 9Creaform measurements/sec: 550 000

  • Measurement type: Non-contact
  • Scanning accuracy, mm: 0. 25

    • Get price

    • Standard equipment

    3D scanner Creaform Academia 50

    Article creaf-ac-50

    • Manufacturer: Creaform
    • Object size range, m: 0.3-3
    • Scan area, mm: 380x380
    • Resolution ,5
    • Measuring speed, measurements/sec: 550 000
    • Measuring type: Non-contact

    Ask price

    • Standard equipment

    3D scanner Creaform MetraScan 350

    Article craf-ms-350

    • Manufacturer: Creaform
    • Object size range, m: 0.1-4
    • Scan area, mm: 225x250 ,05
    • Measurement speed, measurements/sec: 205 000
    • Measurement type: Non-contact
    • Scanning accuracy, mm: 0. 04

    Get price

    • Standard equipment

    3D scanner Creaform MetraScan 750

    Article craf-ms-750

    • Manufacturer: Creaform
    • Object size range, m: 0.1-4
    • Scan area, mm: 275x256 Resolution: 901 ,05
    • Measurement speed, measurements/sec: 480,000
    • Measurement type: Non-contact
    • Scanning accuracy, mm: 0.03

    Ask for price

    • Standard equipment

    SISTEMENT OF Automated 3D scanning Creform Metrascan 750-R

    Article Creaf-MS-750R

    • Manufacturer: CreaForm
    • Square area, mm: 275x250
    • Resolution, mm: 0.05
      • 9001 sec: 480 000
    • Measuring type: Non-contact

    Ask for price

    • Standard equipment

    Automated 3D scanning system Creaform Cube-R

    Article craf-cube-r

    • Manufacturer: Creaform
    • Object size range, m: 0. 3-3
    • Scanning area, mm: 9015 9015 mm: 0.5
    • Measuring speed, samples/sec: 480 000
    • Measuring type: Non-contact

    Call for price

    • Standard equipment

    3D scanner Creaform Go!Scan Spark

    Creaf-go-spark article

    • Manufacturer: Creaform
    • Object size range, m: 0.1-4
    • Scan area, mm: 390x390
    • Resolution, mm: 0.1
    • Measurement speed, measurements/sec: 1,500,000
    • Measurement type: Non-contact
    • Scanning accuracy, mm: 0.05

    Get price

    • Standard equipment

    3D scanner Creaform HandyScan 307

    Article creaf-hs-307

    • Manufacturer: Creaform
    • Object size range, m: 0. 05-4
    • Scanning area, mm: 225x250
    • Resolution, mm: 0.1
    • Measurement speed, measurements/sec: 480,000
    • Measurement type: Non-contact
    • Scanning accuracy, mm: 0.04

    Get price

    • Standard equipment

    3D scanner Creaform HandyScan Black

    Article creaf-hs-blck

    • Manufacturer: Creaform
    • Object size range, m: 0.05-4
    • Scanning area, mm: 310x350
    • Measurement resolution, mm: 0.025
    • measurements sec: HandySCAN BLACK 800 000, HandySCAN BLACK|Elite 1 300 000
    • Measuring type: Non-contact

    Call for price

    • Standard equipment

    Portable CMM Creaform HandyPROBE Next

    Article craf-hp-nxt

    • Manufacturer: Creaform
    • Object size range, m: 0. 1-4
    • Measurement type: Contact
      • , HandyPROBE:
    • , HandyPROBE Next Elite 0.020

    Ask price

    • Standard equipment

    Photogrammetry Creaform MaxSHOT Next

    Article creaf-ms-nxt

    • Manufacturer: Creaform
    • Object size range, m: 2-10
    • Measurement type: Contactless
    • Standard equipment

    3D scanner Creaform MetraScan 350 Elite

    Article creaf-ms-350e

    • Producer: Creaform
    • Object size range, m: 0.1-4
    • Scanning area, mm: 225x250
    • Resolution, mm: 0.05
    • Measurement speed, measurements/sec: 9015 000
    • Measurement type: Non-contact
    • Scanning accuracy, mm: 0. 04

    Ask for price

    • Standard equipment

    3D scanner Creaform MetraScan 750 Elite

    Article craf-ms-750e

    • Manufacturer: Creaform
    • Object size range, m: 0.1-4
    • Scan area, mm:
      • 0.05
    • Measuring speed, measurements/sec: 480 000
    • Measuring type: Non-contact
    • Scanning accuracy, mm: 0.03

    Get price

    • Standard equipment

    SISTEMENT OF Automated 3D scanning CRAFORM METRASCAN 750-R ELITE

    Creaf-MS-7502 Article

    • Manufacturer: Creaform
    • Scan Square, mm: 275x250
    • Resolution, speed, mm: 0.0.05
      • , mm: 0. /sec: 480 000

    Ask price

    • Standard equipment

    3D scanner Creaform HandyScan Black Elite

    Article creaf-hs-blcke

    • Manufacturer: Creaform
    • Object size range, m: 0. 05-4
    • Scanning area, mm: 310х3150 0.025
    • Measurement speed, samples/sec: HandySCAN BLACK 800,000, HandySCAN BLACK|Elite 1,300,000
    • Measuring type: Non-contact

    Ask for price

    • Standard equipment

    Portable CMM Creaform HandyPROBE Next Elite

    Article craf-hp-nxte

    • Manufacturer: Creaform
    • Object size range, m: 0.1-4
    • Measurement type: Contact 900 HandyPROBE scanning, mm 0.025, HandyPROBE Next Elite 0.020

    Ask for price

    • Standard equipment

    3D scanner Creaform Peel 1

    Article 111216

    • Manufacturer: CREAFORM
    • Scanning area, mm: 380x380
    • Resolution, mm: 0. 5
    • Type of Measurement: non -contact
    • Precisuation, mm: 0, mm: 0 50

    Get a price

    • Standard equipment

    3D scanner Creaform Peeform 2

    Article 111217

    • Manufacturer: CreaForm
    • Scanning area, mm: 380x380
    • Resolution, mm: 0.5
    • Type of measurement: non -contact
    • accommodation: 0, mm: 0 25

    Ask for a price

    HandySCAN 3D laser scanners | Creaform

    HandySCAN 3D handheld scanners are optimized for the needs of pipeline integrity engineers and provide the most efficient and reliable way to obtain 3D measurements of physical objects.

    Creaform's flagship metrology scanners have been redesigned. They're lighter and deliver high-resolution 3D scans faster, while still being just as easy to use.

    The Creaform Pipecheck system offers a choice of two models of 3D laser scanners depending on the required level of accuracy.

    A COMBINATION OF PRECISION AND PORTABILITY. INTRODUCING HANDYSCAN 3D SCANNERS.

    Are you looking for the most efficient way to accurately quantify material loss and mechanical damage? HandySCAN 300 is a reliable tool that will solve this problem.

    HandySCAN 700 provides high accuracy and resolution. It is the most versatile 3D scanner for inspections available on the market. The data collection speed of the HandySCAN 700 will pleasantly surprise you.

    • Benefits
    • Operating sequence
    • Applications
    • Accessories
    • specifications

    TRUaccuracy (True Accuracy)
    • Dynamic coupling between tube and scanner maintains accuracy and resolution in all conditions, including high vibration conditions.
    • The system generates accurate, reproducible high resolution 3D data (0.040-0.050 mm).
    • Improved virtual level gauge capabilities. The transmitter is configured to provide the most accurate measurements close to welds.
    • Comparison of Internal Pipe Condition Data : Access inspection results by comparing internal pipe inspection data and data from tools with data from the Pipecheck system. This helps operators to more accurately identify areas where earthworks need to be done.
    • Depth of Corrosion within a Mechanical Fault : Unique and innovative tools for determining the depth of corrosion within a mechanical fault.

    TRUsimplicity : A very simple 3D scanning process
    • Scanning and analysis are accurate, intuitive to use and independent of operator skill.
    • Very fast learning, regardless of user experience.
    • Launch and start in less than 2 minutes.
    • Simplicity: simple and fast learning.
    • The ability to change the working distance allows access to isolated areas.
    • Visualization of the scanned surface in real time.

    TRUportability : 3D scanning where you need it
    • Portable from place to place and used both indoors and outdoors.
    • Weight 0.85 kg; possibility of use in limited spaces. Fits in a portable case.
    • The mass of the scanner is about 1 kg.

    Pipecheck: Your best ally in every step of your pipeline integrity program

    SCAN

    • Corrosion
      • High definition image capture for all areas showing signs of corrosion
      • Fast surface imaging for increased efficiency
      • Improved scanning of fine details such as pitting
    • Mechanical damage
      • High resolution mesh files for analysis optimization
      • Quick measurements to check any surface finish
    • Comparison of pipe internal inspection data
      • High-precision, skill-independent measurements for improved matching data
      • Improved performance to cover more area and get more accurate statistical trends

    ANALYSIS

    • Corrosion
      • Troubleshooting using real pipeline geometry
      • Automatic application of interaction rules
      • Estimated Burst Pressure Calculation
      • Improved virtual level gauge for working near welds and obstacles
    • Mechanical damage
      • Automatic maximum depth detection
      • Automatic creation of a 2D cross profile in both directions at maximum depth
      • Measuring the maximum depth in both directions with straightedge
      • Ledge section available
    • Comparison of pipe internal inspection data
      • Automatic detection of coincidences when overlapping surfaces
      • Manual match function
      • Axial and circular offset function for optimum overlap

    REPORT

    • Corrosion
      • Excel report including worst case profile and predicted fault evolution
      • Ability to export to CSV format for further analysis
      • Ability to export coordinate grid
      • Custom Pass/Fail criteria
      • Photographic device for 3D report
    • Mechanical damage
      • Excel report with ovality measurements
      • Cross section details (axial and cylindrical)
      • Depth mesh export to CSV format
      • Ability to export coordinate grid
      • Excel report with ovality measurement results (diameter measurement with caliper)
        • Dat, maximum depth point
        • Dat, 90° from maximum depth point
        • Dmax
    • Comparison of pipe internal inspection data
      • Visual overlay of pipe internal inspection data and faults detected by scan
      • General Graph for Evaluating the Performance of Sizing, Maximum Depth and Estimated Burst Pressure Tools
      • List of harmonized and non-harmonized functions
    • Piping corrosion assessment
    • Assessment of mechanical damage to pipelines
    • Estimation of hail damage to aircraft
    • 3D simulation for phased array inspection - Aerospace
    • 3D Simulation for Phased Array Inspection - Energy

    Rugged field kit with wireless tablet

    For companies looking for optimal performance in the field, Creaform has developed a complete set of accessories. Our rugged field kit includes a wireless tablet for real-time visualization of scanned surfaces.

    It also offers a choice of three compatible power sources: Creaform battery with charger*, 110/220V direct input or car battery.

    Package includes:

    • Wireless tablet powered by VXremote
    • Pelican rugged laptop case
    • Creaform battery with charger
    • Magnetic support for scanner
    • Magnetic tablet support
    • USB 3.0 cable, 8m

    Accessories:

    • Emergency power cables for car battery

    *When used with a Creaform battery, the rugged field kit provides 8 hours of battery life.

    3D Scanner Power Bank: Takes portability to a whole new level

    Lightweight 3D scanner power bank with three hours of battery life improves data acquisition efficiency. Ideal for short term projects and applications where the object is accessed with a tether and provides complete freedom of movement. Combined with HandySCAN 3D, you can use the scanner wherever you are. The small weight and size guarantee a new level of portability! Offered at a reasonable and affordable price, the rechargeable battery is ideal for working in confined spaces as well as outdoors!

    • Autonomy: 3 hours continuous scan
    • Dimensions: 180x110x20 mm / 7.1x4.3x0.8 in.
    • Weight: 0.52 kg / 1.14 lb
    • Charging time: 4 hours

    VXremote™: Remote Access Software

    VXremote improves field efficiency by providing quick and easy remote access to Pipecheck. This software guarantees fast start-up and configuration without any hardware. All 3D scanner functions are at your disposal... Only available with Creaform Certified Rugged Tablets!

    Complete solution includes:
